LC-12

Magnetic Contact Part No. LC-12 Description Magnetic contact is a proximity switch what is used magnetic field of magnet to actuate Reed Switch. Because of design in Reed Switch, low cost and simple using-way is major characteristics of magnetic contact. Application ‧Security equipment ‧domestic appliances ‧automation machines Feature ‧New design – perfect for all small application ‧Removable flange for limited space installation ‧Hermetically sealed ‧Screw mount or self- stick – both options provided for ‧Available in closed loop and open loop Outline dimensions 1 Letex Technology Corp. Magnetic Contact Part No. LC-12 Switch Contact arrangement Switching voltage (Max.) Switching current (Max.) Contact capacity (Max.) Initial contact (Max.) Carry current (Max.) Breakdown voltage Insulation resistance (Min.) Switch cycle Closed loop 100v AC / DC 0.5 A 10 VA 0.2 Ohm 1A 200 VDC 100 Mohm 5 × 10 cycle at 30.V 0.1 ADC 7 Magnet Material Residual flux density (Br) Maximun energy product (BH) max. Curie temperature (Tc) NdFeB rare earth 11.8~12.5 KGauss 33~36 MG.Oe 310℃ Gap Sense gap (Min.) 16mm Physical characteristic Temperature Vibration Shock Heat shock Package drop Humidity -20℃~+60℃ 20 G(10~55 HZ) 30 G (11 msec) -25℃~+65℃ (30min) (30min) 100 cycle Drop height 80 cm 80℃ 95﹪ RH 72 hrs 2 Letex Technology Corp.
