RS-MK-X2010

High Integrity FM Transceiver RS-MK-X2010 Features • • • • • • • • • • • Operation on 434.075, 868.40 and 914.5 MHz X2011 version includes integrated pcb loop antenna (434 & 868 MHz versions) Double RF filtering = High Reliability RF Link Data rates to 20 kbps (Wide-band 64 kbps version available to order) -112 dBm receiver sensitivity (434 version) CD and RSSI outputs Crystal stabilised accurate RF Hence narrower BW filter utilised Results in over 300m range EN 300 220-1, 300 683 & FCC compliant Immune to Tetra and High power Radio Amateur Repeater Stations Applications • • • • EPOS TERMINALS REMOTE TELEMETRY & TELECOMMAND REMOTE METER READING DOMESTIC AND COMERCIAL SECURITY General Description The WP-MK-X2010 radio transceiver module was designed to provide reliable wireless operation at moderate data rates for use throughout the world. Its unique features of narrower RF channel bandwidths and hence high interference rejection capability at SAW module prices make the X2010 the ideal choice for next generation applications. Available for operation at the major frequency allocations world-wide in the same package, these modules have been designed to provide a reliable wire free link for the next century, accounting for the increased traffic from other legal users of the radio spectrum. The transmitter section uses a PLL design that utilises a highly stable and accurate reference crystal oscillator. This results in a RF transmission tightly controlled in its frequency spread and over its operating temperature range. This is exploited in the receiver design. The receiver section uses a single conversion super-het design, again using PLL technology. Hence narrower bandwidth RF filters are utilised which result in superior rejection of interference as well as providing good receiver sensitivity and hence range. Page 1 of 7 High Integrity FM Transceiver RS-MK-X2010 Absolute Maximum Ratings: Receiver Operating temperature: Storage temperature: Supply Voltage Data Input: RF Input -20° C to +55° C -40° C to +100° C 6V Vcc + 0,3v 0 dBm Electrical Characteristics: Performance data measured at 20° C and +5 volt supply and RF = 434,075 MHz pin DC LEVELS Supply voltage Supply current (receiver enabled) Supply current (transmitter enabled) Leakege current with Vcc connected Data input/output high Data input/output low RF Receiver sensitivity (12 dB SINAD on AF output) Image rejection RF power out (transmitter) FM Deviation Initial frequency accuracy Overall frequency accuracy Max RF input to receiver E.M.C. Spurious responses upto 1GHz LO leakage, conducted LO leakage, radiated DYNAMIC TIMING RX enable to valid RSSI / CD RX enable to stable receiver data out TX enable to full RF out Minimum data pulse width Data Bit rate Notes 1) 2) Over full operating temperature range 1 Hz = 2 bps 17 17 17 12,14 12,14 min. 4,5 typ. 5 7 8 max. 5,5 units V mA mA uA V V notes 0,7xVcc 0 1 Vcc 0,0xVcc 13 -112 50 1 +/-10 ± 100 +/-2 0 dBm dB mW KHz Hz KHz dBm
