16080-00

PACIFIC DISPLAY DEVICES LCD Component Data Sheet Model Number: 16080-00 160 x 80 Dot Graphic LCD Assembly With LC7981 Sanyo Graphic LCD Controller EL Panel / LED Backlight Options CONTENTS 1. GENERAL INFORMATION 1.1 Product Overview 1.2 Part Options and Numbering System 1.3 Absolute Maximum Ratings 1.4 Circuit Block Diagram 1.5 Mechanical Characteristics 1.6 Input Signal Function 1.7 LCM Power, Contrast Control and Bias 1.8 LCD Dimensions ELECTRICAL / OPTICAL CHARACTERISTICS 2.1 DC Electrical Characteristics 2.2 AC Electrical Characteristics 2.3 Optical Characteristics 2.4 LED Backlight Characteristics 2.5 EL Panel Backlight Characteristics LCD CONTROLLER CHARACTERISTICS 3.1 LCD Controller Display and Control Functions (LC7981) 3.2 LCD Controller Character Code map RELIABILITY PRECAUTIONS FOR USING LCD MODULES 139 Avenida Victoria – Suite 100 – San Clemente, CA – 92672 Tel: 949-361-8957 – Fax: 949-361-9158 – Web: www.pacificdisplay.com 2 2 3 3 3 4 4 5 6 7 8 10 10 11 17 18 19 2. 3. 4. 5. SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 1. 1. GENERAL INFORMATION 1.1 1.1 Product Overview • 160 x 80 dot matrix LCD • STN (Super Twisted Nematic) Technology • LC7981 (or equivalent) Graphics Controller IC w/ 8K SRAM. • Multiplex drive : 1/80 duty, 1/10 bias • LCD Module Service Life: 100,000 hours minimum 1.2 1.2 Part Options and Numbering System 16080 16080 -00 -00 -SL -SL -F -F -ST -ST -LED -LED -GY -GY -6 -6 -V -V Custom Option Designator: • Internal LC7981 Controller Operating Mode: • (-SL) STN Silver / Gray • (-GR) STN Green • (-BN) STN Blue Negative Image • (-FC) FSTN Black & White Image Rear Polarizer Options: • (-F) Transflective • (-M) Transmissive • (-R) Reflective (No Backlight) Operating Temperature: • (-ST) Standard (0 to +50 ºC) • (-ET) Extended (-20 to +70 ºC) Backlight Options: • (-LED) Array Lit LED Backlight • (-ELP) EL Panel Backlight Backlight Coloration Options: • (-WH) ELP – White • (-GY) LED - Green/Yellow • (-AM) LED - Amber • (-BG) ELP – Blue Green Viewing Angle: • (-6) 6 o’clock • (-12) 12 0’clock Additional options: • (-V) Internal -10V Vee Generator (Standard) • (-AF) Anti-Glare film on the front of the display • (-10.2) 10.2V LED backlight Option PACIFIC DISPLAY DEVICES 04.28.2005 2 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 1.3 1.3 Absolute Maximum Ratings Parameter Parameter Supply voltage for logic Supply voltage for LCD Input voltage Standard Operating temperature Standard Storage temperature Extended Operating temperature Extended Storage temperature Soldering Temp Symbol Symbol VDD VDD – V0 VI TOP (-ST) TST (-ST) TOP (-ET) TST (-ET) Tsolder Min Min -0.3 -0.3 -0.3 0 -10 -20 -30 260 Max Max 7.0 10.0 VDD +0.3 50 60 70 80 Unit Unit V V V ºC ºC ºC ºC ºC 1.4 Circuit Block Diagram D0 – D7 /WR /RD /CE C/D /RST FS VDD VSS Vee Anode Cathode DF GND Display Frame Ground Controller LSI LC7981 2K SRAM 160 Line SEG Driver S160 Bias Circuitry To LSI 80 Line COM. Driver C80 LCD Panel 160 x 80 Dots ELP / LED Backlight 1.5 Mechanical Characteristics Item Module size (W×H×T) Viewing area (W×H) Active area (W×H) Number of dots Dot size (W×H) Dot pitch (W×H) Contents 100.0 x 54.0 x 15.3 Max (LED Backlight) 100.0 x 54.0 x 11.3 Max (No LED / ELP Backlight) 72.0 x 37.8 67.17 x 33.57 160 x 80 0.39 x 0.39 0.42 x 0.42 Unit mm mm mm mm dots mm mm PACIFIC DISPLAY DEVICES 04.28.2005 3 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 1.6 1.6 Input Signal Function Pin No. Pin 1 2 3 4 5 6 7-14 15 16 17 18 19 20 Symbol Symbol VSS VDD VO RS R/W E DB0-DB7 /CS /RST VEE NC LED-A LED-K Level Level 0V +5.0V -H/L H/L H/L H/L H/L L -10V --4.2V* 0V Description Description Ground Supply voltage for logic Contrast bias voltage for LCD Register select: H:Instruction, L:Data Controller read/write; H:Data Read, L:Data Write Controller Access Enable Bidirectional Data Bus Lines Controller Chip Select: Active “L” Reset: Active “L” Negative Voltage Output (-10V) Not Used LED Backlight Anode LED Backlight Cathode Note: 1.7 LCM Power, Contrast Control and Bias VDD VDD VO VEE VSS VR: 20Kohm LCM A LED Backlight K Backlight Power Note : DC-to-DC Converter Built In PACIFIC DISPLAY DEVICES 04.28.2005 4 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 1.8 LCM Dimensions ■ Module Dimensions PACIFIC DISPLAY DEVICES 04.28.2005 5 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 2. 2. ELECTRICAL / OPTICAL CHARACTERISTICS 2.1 DC Electrical Characteristics (VDD = +5V±10% , VSS = 0V, Ta = 25°C ) Parameter Parameter Symbol Symbol Condition Condition Min Min Typ Typ Supply voltage for logic Supply current for logic Operating voltage for LCD Input voltage ' H ' level Input voltage ' L ' level VDD IDD VDD- Vee VIH VIL --VDD = 5V 0°C 25°C 50°C ----4.75 -----0.8 VDD 0 --15 12.5 12.0 11.4 ----- Max Max 5.25 22 ---VDD 0.2 VDD Unit Unit V mA V V V V V ■ TIMING OF POWER SUPPLY VDD GND 4.75V 0~50ms 0~50ms SIGNAL GND ≥ 0ms GND ≥ 0ms VEE POWER ON Note : The missing pixels may occur when the LCM is driven except above power supply timing sequence. POWER OFF PACIFIC DISPLAY DEVICES 04.28.2005 6 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 2.2 AC Electrical Characteristics Sanyo LC-7981 Graphic Controller IC AC Waveform Interface Parameter Enable Cycle Time Enable Pulse High Level Width Enable Pulse Low Level Width Enable Rise Time Enable Fall Time Setup Time Data Setup Time Data Delay Time Data Hold Time Address Hold Time Output Data Hold Time Timing Chart Symbol tCYC tWEH tWEL tER tEF tAS tDSW tDDR tDHW tAH tDH Min 1.0 0.45 0.45 ----90 220 --10 10 20 Typ ----------------------Max ------25 25 ----140 ------Unit µs µs µs ns ns ns ns ns ns ns ns PACIFIC DISPLAY DEVICES 04.28.2005 7 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 2.3 Optical Characteristics (VOP = 4.7V, Ta = 25°C ) Item Contrast ratio (STN) Contrast ratio (FSTN) Frame Frequency Viewing angle range Response time Symbol Cr Cr fFRM θ1 θ2 Ton Toff Condition θ=0° φ=0° θ=0° φ=0° --25°C 25°C Min ----32 50 ------- Typ 3.7 9.2 64 --40 100 170 Max ----150 130 ------- Unit ----Hz deg deg ms ms Definition of angles ∅ and θ: PACIFIC DISPLAY DEVICES 04.28.2005 8 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 PACIFIC DISPLAY DEVICES 04.28.2005 9 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 2.4 LED Backlight Characteristics ■ Yellow-Green LED Operating Characteristics (4.1V - Array Lit) Item Forward voltage Forward Current Reverse Voltage Peak Emission Wavelength Symbol Vf IF VR λP Conditions ------If=360mA Yel/Grn Min. 3.9 ------Standard Typ. 4.1 360 --570 Max. 4.3 720 8 --Unit VDC mA V nm ■ Yellow-Green LED Operating Characteristics (10.2V - Array Lit) Item Forward voltage Forward Current Reverse Voltage Peak Emission Wavelength Symbol Vf IF VR λP Conditions ------If=150mA Yel/Grn Min. 3.7 ------Standard Typ. 10.2 150 --570 Max. 10.7 300 20 --Unit VDC mA V nm ■ Life Item Life Conditions Ta= 25 °C Standard Min. Max. 100,000 --Unit hrs 2.5 EL Panel Backlight Characteristics (Blue-Green) ■ Blue-Green EL Panel Operating Characteristics: Item Current Consumption Conditions Min. Standard Typ. 10 100 400 ----60 --Max. 20 150 1000 +50°C +60°C ----Unit mA VAC RMS Hz °C °C cd/m2 Hrs 100VAC RMS, 400Hz --Ta: 25°C EL Drive Voltage ----EL Drive Frequency ----Operating Temperature ---35°C Storage Temperature ---40°C 100VAC RMS, 400Hz Luminance 48 Ta: 25°C Luminance Half-Life 3500 *Note: half life is defined as Luminance being reduced by 50% PACIFIC DISPLAY DEVICES 04.28.2005 10 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 3. OPERATING PRINCIPALS AND METHODS 3.1 LCD Controller Display and Control Functions (Sanyo LC-7981 Controller) PACIFIC DISPLAY DEVICES 04.28.2005 11 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 PACIFIC DISPLAY DEVICES 04.28.2005 12 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 PACIFIC DISPLAY DEVICES 04.28.2005 13 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 PACIFIC DISPLAY DEVICES 04.28.2005 14 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 PACIFIC DISPLAY DEVICES 04.28.2005 15 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 PACIFIC DISPLAY DEVICES 04.28.2005 16 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 3.2 LCD Controller Character Code Map PACIFIC DISPLAY DEVICES 04.28.2005 17 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 4. 4. RELIABILITY No . 1 2 3 4 5 6 7 Test Item High temperature storage Low temperature storage High temperature operation Low temperature operation High temperature / Humidity storage High temperature / Humidity operation Temperature cycle Environmental Test Content of Test Endurance test applying the high storage temperature for a long time. Endurance test applying the low storage temperature for a long time. Endurance test applying the electric stress (Voltage & Current) and the thermal stress to the element for a long time. Endurance test applying the electric stress under low temperature for a long time. Endurance test applying the high temperature and high humidity storage for a long time. Endurance test applying the electric stress (Voltage & Current) and temperature / humidity stress to the element for a long time. Endurance test applying the low and high temperature cycle. -20°C 70°C 25°C 30min 30min 5min. 1 cycle Test Condition 6 0 °C 200 hrs -10 °C 200 hrs 5 0 °C 200 hrs 0 °C 200 hrs 60 °C , 90 %RH 96 hrs 40 °C , 90 %RH 96 hrs -10°C / 60°C 10 cycles Applicable Standard --------------------MIL-202E-103B JIS-C5023 MIL-202E-103B JIS-C5023 ------ Mechanical Test 8 Vibration test Endurance test applying the vibration during transportation and using. Constructional and mechanical endurance test applying the shock during transportation. Endurance test applying the atmospheric pressure during transportation by air. 10∼22Hz → 1.5mmp-p 22∼500Hz → 1.5G Total 0.5hrs 50G Half sign wave 1l msedc 3 times of each direction 115 mbar 40 hrs MIL-202E-201A JIS-C5025 JIS-C7022-A-10 MIL-202E-213B MIL-202E-105C 9 10 Shock test Atmospheric pressure test Static electricity test Others Endurance test applying the electric stress to the VS=800V , RS=1.5 kΩ terminal. CS=100 pF 1 time ∗∗∗ Supply voltage for logic system = VDD. Supply voltage for LCD system = Operating voltage at 25°C 11 MIL-883B3015.1 ■ LCD Panel Service Life Definition of panel service life • • • • • 100,000 hours minimum at 25° C ±10% Contrast becomes 30% of initial value Current consumption becomes three times higher than initial value Remarkable alignment deterioration occurs in LCD cell layer Unusual operation occurs in display functions PACIFIC DISPLAY DEVICES 04.28.2005 18 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 5. PRECAUTIONS FOR USING LCD MODULES Installing LCD Modules The hole in the printed circuit board is used to fix LCM as shown in the picture below. Attend to the following items when installing the LCM. 1) Cover the surface with a transparent protective plate to protect the polarizer and LC cell. 2) When assembling the LCM into other equipment, the spacer to the bit between the LCM and the fitting plate should have enough height to avoid causing stress to the module surface, refer to the individual specifications for measurements. The measurement tolerance should be ±0.1mm. Precaution for Handing LCD Modules Since LCM has been assembled and adjusted with a high degree of precision, avoid applying excessive shocks to the module or making any alterations or modifications to it. 1) Cover the surface with a transparent protective plate to protect the polarizer and LC cell. 2) Do not alter, modify or change the shape of the tab on the metal frame. 3) Do not make extra holes on the printed circuit board, modify its shape or change the positions of components to be attached. 4) Do not damage or modify the pattern writing on the printed circuit board. 5) Absolutely do not modify the zebra rubber strip (conductive rubber) or heat seal connector. 6) Except for soldering the interface, do not make any alterations or modifications with a soldering iron. 7) Do not drop, bend or twist LCM. Electro-Static Discharge Control Since this module uses a CMOS LSI, the same careful attention should be paid to electrostatic discharge as for an ordinary CMOS IC. 1) Make certain that you are grounded when handing LCM. 2) Before remove LCM from its packing case or incorporating it into a set, be sure the module and your body have the same electric potential. 3) When soldering the terminal of LCM, make certain the AC power source for the soldering iron does not leak. 4) When using an electric screwdriver to attach LCM, the screwdriver should be of ground potentiality to minimize as much as possible any transmission of electromagnetic waves produced sparks coming from the commutator of the motor. 5) As far as possible make the electric potential of your work clothes and that of the work bench the ground potential. 6) To reduce the generation of static electricity be careful that the air in the work is not too dried. A relative humidity of 50%-60% is recommended. Precaution for soldering to the LCM 1) Observe the following when soldering lead wire, connector cable and etc. to the LCM. a) Soldering iron temperature : 280°C ± 10°C. b) Soldering time : 3-4 sec. 2) Solder : eutectic solder. PACIFIC DISPLAY DEVICES 04.28.2005 19 SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 3) If soldering flux is used, be sure to remove any remaining flux after finishing to soldering operation. (This does not apply in the case of a non-halogen type of flux.) It is recommended that you protect the LCD surface with a cover during soldering to prevent any damage due to flux spatters. 4) When soldering the electroluminescent panel and PC board, the panel and board should not be detached more than three times. This maximum number is determined by the temperature and time conditions mentioned above, though there may be some variance depending on the temperature of the soldering iron. 5) When remove the electroluminescent panel from the PC board, be sure the solder has completely melted, the soldered pad on the PC board could be damaged. Precautions for Operation 1) Viewing angle varies with the change of liquid crystal driving voltage (VO). Adjust VO to show the best contrast. 2) Driving the LCD in the voltage above the limit shortens its life. 3) Response time is greatly delayed at temperature below the operating temperature range. However, this does not mean the LCD will be out of the order. It will recover when it returns to the specified temperature range. 4) If the display area is pushed hard during operation, the display will become abnormal. However, it will return to normal if it is turned off and then back on. 5) Condensation on terminals can cause an electrochemical reaction disrupting the terminal circuit. Therefore, it must be used under the relative condition of 40°C , 50% RH. 6) When turning the power on, input each signal after the positive/negative voltage becomes stable. Safety • If the LCD panel breaks, be careful not to get the liquid crystal in your mouth. If the liquid crystal touches your skin or clothes, wash it off immediately using soap and plenty of water. Handling • • • • • The display panel is made of glass. Do not subject it to a mechanical shock by dropping it or impact. If the display panel is damaged and the liquid crystal substance leaks out, be sure not to get any in your mouth. If the substance contacts your skin or clothes, wash it off using soap and water. Do not apply excessive force to the display surface or the adjoining areas since this may cause the color tone to vary. The polarizer covering the display surface of the LCD module is soft and easily scratched. Handle this polarizer carefully. If the display surface becomes contaminated, breathe on the surface and gently wipe it with a soft dry cloth. If it is heavily contaminated, moisten cloth with one of the following solvents : o Isopropyl alcohol o Ethyl alcohol Solvents other than those above-mentioned may damage the polarizer. Especially, do not use the following. o Water o Ketone o Aromatic solvents Exercise care to minimize corrosion of the electrode. Corrosion of the electrodes is accelerated by water droplets, moisture condensation or a current flow in a high-humidity environment. Install the LCD Module by using the mounting holes. When mounting the LCD module make sure it is free of twisting, warping and distortion. In particular, do not forcibly pull or bend the I/O cable or the backlight cable. Do not attempt to disassemble or process the LCD module. NC terminal should be open. Do not connect anything. If the logic circuit power is off, do not apply the input signals. PACIFIC DISPLAY DEVICES 04.28.2005 20 • • • • • • SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE MODEL NO: 16080-00 • To prevent destruction of the elements by static electricity, be careful to maintain an optimum work environment. o Be sure to ground the body when handling the LCD modules. o Tools required for assembling, such as soldering irons, must be properly grounded. o To reduce the amount of static electricity generated, do not conduct assembling and other work under dry conditions. o The LCD module is coated with a film to protect the display surface. Exercise care when peeling off this protective film since static electricity may be generated. Storage • • • • When storing the LCD modules, avoid exposure to direct sunlight or to the light of fluorescent lamps Store the module in a dark place where the temperature is 25 oC ±10 oC and the humidity below 65% RH. Do not store the module near organic solvents or corrosive gases. Do not crush, shake, or jolt the module (including accessories). Cleaning • • • Do not wipe the polarizing plate with a dry cloth, as it may scratch the surface. Wipe the module gently with soft cloth soaked with a petroleum benzene. Do not use ketonic solvents (ketone and acetone) or aromatic solvents (toluene and xylene), as they may damage the polarizing plate. Others: • • Liquid crystals solidify under low temperature (below the storage temperature range) leading to defective orientation or the generation of air bubbles (black or white). Air bubbles may also be generated if the module is subject to a low temperature. If the LCD modules have been operating for a long time showing the same display patterns, the display patterns may remain on the screen as ghost images and a slight contrast irregularity may also appear. A normal operating status can be regained by suspending use for some time. It should be noted that this phenomenon does not adversely affect performance reliability. To minimize the performance degradation of the LCD modules resulting from destruction caused by static electricity etc., exercise care to avoid holding the following sections when handling the modules. - Exposed area of the printed circuit board. - Terminal electrode sections. • PACIFIC DISPLAY DEVICES 04.28.2005 21
