6-132-031200

HIGH PERFORMANCE PRESSURE SENSOR MODEL 6-13 WWW.VSENSORS.COM The Model 6-13 is uniquely designed for use in a broad variety of applications where accurate, reliable, high performance pressure measurement is required. The Model 6-13 utilizes a micro-machined silicon pressure sensor that is isolated for all media by a 316L stainless steel diaphragm and high performance digital temperature compensation ASIC. This translates into excellent linearity, increased long-term stability & reliability. Micro-machined silicon pressure sensors provide accuracies down to ±0.20% with effectively no hysterisis and a long-term drift of less that 0.15% FSO for one (1) year & proof pressures greater than 3X the rated pressure. All Model 6-13 configurations have extremely robust EMI/RFI protection. The Model 6-13 will not shift, drift, or fail in an EMI/RFI environment of greater than 10 volts/meter up to 1.0GHz. The Model 6-13 is hermetically sealed by welding & conforms to NEMA 4 & 4X enclosure requirements. (Except for vented gage configurations.) Wide Choice of Pressure Ranges & Fittings Highly Corrosion Resistant Exceptional Long-term Stability FOR ACTUAL DIMENSIONS SEE OUTLINE DRAWING .75 [19.05] HEX ACROSS FLATS (Ø.75 [19.05]) (.25 [6.35]) (1.49 [37.85]) (1.74 [44.20]) CONNECTOR TYPICAL OVERALL DIMENSIONS INCHES [mm] • • • • Process Control Systems Natural Gas Production Liquid Level Measurement Gas Compressors • • • • Chemical Processing Systems Wastewater Treatment Chemical Processing Systems Pulp & Paper Processing -- An Electromotive Solutions Company – 2800 ANVIL STREET NORTH ● ST. PETERSBURG, FL 33710 USA ● PHONE: (727) 347-2181 ● Fax: (727) 347-7520 MODEL 6-13 HIGH PERFORMANCE PRESSURE TRANSDUCER Ordering Information Product Specifications Performance Output Signal Accuracy L, R & H Zero Offset Long-term Stability Compensated Temperature Temperature Effect Operating Input Power Insulation Resistance Reverse Polarity Proof Pressure Burst Pressure Weight Environmental Max Operating Temperature EMI/RFI Wetted Parts Vibration Shock Enclosure Life -40°C to 125°C (-40°F to 257°F) 10volts/meter up to 1.0GHz 316L SST 15 G’s, 10-2000Hz 100 G’s for 11ms, Half-sine NEMA 4 & 4X 100 MM Full Scale Cycles 8 - 30 VDC (@ 25mA Max) 100 megohms @ 50 VDC Protected 150% of Rated Range 200% of Rated Range 72g (2.5oz) 4 - 20mADC ±0.35%FSO (BFSL) ±1.0%FSO ±0.50%FSO/Year 0°C to 85°C (32°F to 185°F) Zero: ±2.0% FSO Span: ±2.0% FSO Instrument Family 6 - 13 X - X X X X - X X 6 = Micro-machined Silicon Sensor Type 13 = Pressure Transmitter Reference Pressure 0 = Absolute 1 = Vented Gage 2 = Sealed Gage Pressure Ranges ** 00 = 3 PSI # 01 = 5 PSI # 02 = 15 PSI # 03 = 20 PSI # 04 = 25 PSI # 05 = 30 PSI # 06 = 50 PSI # 07 = 60 PSI # 08 = 100 PSI # 09 = 150 PSI # 10 = 200 PSI # 11 = 250 PSI # 12 = 300 PSI # 13 = 500 PSI * 14 = 1000 PSI * 15 = 1500 PSI * * Sealed Gage Only 16 = 2000 PSI * 17 = 3000 PSI * 18 = 5000 PSI * 19 = 6000 PSI * 20 = 7500PSI * 21 = 10, 000 PSI * # Absolute & Vented Gage ** Calibration in bars available, consult factory for details Pressure Fittings 0 = MS33656-E4 Male 1 = 7/16-20 Straight, Male 2 = 1/4-18 NPT, Male 3 = 1/8-27 NPT, Male 4 = 1/4-18 NPT, Female 5 = 9/16-18 Straight, Male Flush Diaphragm Electrical Connections 0 = PT1H-10-6P 1 = 3-Wire Cable 2 = PT1H-8-4P 3 = 5-Wire Shielded 4 = DIN43650 Form C 5 = Hirschmann ELST 412 Custom Configurations 00 = No Custom Requirements An Electromotive Solutions Company ISO 9001:2000 & AS9100:2004 Certified 2800 ANVIL STREET NORTH ST. PETERSBURG, FL 33710 USA Fax: (727) 347-7520 Email: sales@vsensors.com PHONE: (727) 347-2181 WWW.VSENSORS.COM
