BT-22

Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Product Specification - Preliminary Features Bluetooth Radio Fully embedded Bluetooth v2.0 Serial and OBEX Profiles Class 2 radio Complete RF ready module Wireless data communications 128-bit encryption security Range up to 30m LOS FCC & Bluetooth qualified ST Micro ARM7 microprocessor up to 50MHz Memory 256K bytes flash memory 64K bytes RAM memory Data Rate 2M bps maximum data rate Multipoint capability Serial Interface UART, up to 480K baud (up to 3.25M baud on BT22.2) Buffered SPI interface I2C interface General I/O 4 general purpose I/O 1x12-bit A/D input User Interface AT command set Firmware upgrade over UART 10mm x 13mm Description Our micro-sized Bluetooth module is one of the smallest form factors available. The BT-22 is designed for maximum performance in a minimal space and includes 4 general purpose input/output lines, several serial interface options, analog-to-digital input, and up to 2M bps data throughput. The BT-22 is a surface mount PCB module that provides fully embedded, ready to use Bluetooth wireless technology. The reprogrammable flash memory contains embedded firmware for serial cable replacement using the Bluetooth SPP profile. Other popular Bluetooth profiles, such as OBEX, are also available. Customized firmware for peripheral device interaction, power optimization, security, and other proprietary features may be supported and can be ordered pre-loaded and configured. - Additional Documentation BT HW Design Guide BT Getting Started Guide abSerial User Guide abSerial Reference Guide © 1 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 1 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Software Architecture Upper Layer Stack: Amp’ed UP Lower Layer Stack Full Bluetooth v2.0 data rate (3M bps maximum) Device power modes—active, sleep and deep sleep Wake on Bluetooth feature—optimized power consumption of host CPU Authentication and encryption Encryption key length from 8-bits to 128-bits maximum Persistent FLASH memory—for BD Address and radio parameter storage All ACL (Asynchronous Connection Less) packet types (DM1, DH1, DM3, DH3, DM5, DH5, 2-DH1, 2-DH3, 2-DH5, 3-DH1, 3-DH3, 3-DH5, AUX1) SCO (Synchronous Connection Oriented) packet types (HV1, HV2, HV3) Point to multipoint and scatternet support—3 master and 7 slave links allowed (10 active links simultaneously) Park, sniff, and hold modes—fully supported to maximum allowed intervals Master slave switch—supported during connection and post connection Dedicated Inquiry Access Code—for improved inquiry scan performance Dynamic packet selection—channel quality driven data rate to optimize link performance Dynamic power control—interference reduction and link performance Bluetooth test modes—per Bluetooth v2.0 specification 802.11b co-existence—AWMA and AFH Vendor specific HCI commands—to support device configuration and certification test modes SPP, OBEX, SDAP, GAP, and DUN protocols RFComm, SDP, and L2CAP supported Multipoint with 7 simultaneous slaves HCI Interface Bluetooth v2.0 specification compliant HCI UART transport layer (H4) AT Command Set: abSerial Please see abSerial Reference Guide for details © 2 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 2 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Hardware Specifications General Conditions (VIN= 3.0V and 25°C) Recommended Operating Conditions Rating Operating Temperature Range Supply Voltage VIN Signal Pin Voltage RF Frequency Min -40 2.85 2400 Typical 3.0 3.0 Max 85 3.4 2483.5 Unit °C Volts Volts MHz Absolute Maximum Ratings Rating Storage temperature range Supply voltage, VIN I/O pin voltage, VIO RF input power Min -55 -0.3 -0.3 Typical Max +150 + 3.6 + 4.0 -5 Unit °C Volts Volts dBm Current Consumption Modes Typical Power Consumption ACL data 115K Baud UART at max throughput (Master) ACL data 115K Baud UART at max throughput (Slave) Connection, no data traffic, master Connection, no data traffic, slave Standby, without deep sleep Avg 33.0 34.0 16.0 24.0 14.0 Unit I/O Operating Characteristics mA mA mA mA mA Symbol VIL VIH VOL VOH IOL IOH BT Spec Typical 50 Unit ohm dBm dBm RPU RPD Parameter Low-Level Input Voltage High-Level Input Voltage Low-Level Output Voltage High-Level Output Voltage Low -Level Output Current High-Level Output Current Pull-up Resistor Pull-down Resistor Min 2.1 2.2 80 80 Max 0.9 0.4 4.0 4.0 120 120 Unit Volts Volts Volts Volts mA mA KΩ KΩ Conditions VIN, 3.0V VIN, 3.0V VIN, 3.0V VIN, 3.0V VOL = 0.4 V VOH = 2.2 V Resistor Turned On Resistor Turned On Selected RF Characteristics Parameters Antenna load Radio Receiver Sensitivity level Maximum usable level Input VSWR Radio Transmitter Maximum output power 50 Ω load -6 to +4 ± 75 ≤ 1000 +5 0 932 dBm kHz kHz Initial Carrier Frequency Tolerance 20 dB Bandwidth for modulated carrier BER < .001 with DH5 BER < .001 with DH1 ≤ -70 ≥ -20 -84 -9 2.5:1 Conditions © 3 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 3 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Pin Assignment Name Type UART Interface RXD TXD CTS RTS Antenna ANT STDBYN Vin GND Reset RESETN GPIO [1] GPIO [2] GPIO [3] GPIO [4] I I/O I/O I/O I/O 10 1 2 3 4 Reset input (active low for 5 ms); General Purpose Input/Output General Purpose Input/Output General Purpose Input/Output General Purpose Input/Output SPI MISO SPI MOSI SPI SCLK/ADC 0 SPI SS GPIO – General Purpose Input/Output RF I/O I 6 9 8 5, 7 50Ω Rx/Tx antenna port Standby Vin GND Reserved – Future Boot 0 Power and Ground I O I O Pin # 13 14 11 12 Description Receive data Transmit data Clear to send (active low) Request to send (active low) I2C Data I2C Clock ALT Function © 4 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 4 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Layout Drawing, BT-22 (Standard Size) Size: 10 mm x 13.1 mm x 2.2 mm (heigth) © 5 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 5 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Layout Drawing, BT-22A (Optional Size) Size: 11.6 mm x 13.1 mm x 2.2 mm (heigth) © 6 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 6 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Hardware Block Diagram Battery or supply Regulator Antenna Port 2.75V SPI 2.75V BP Filter STLC2500C RAM ROM UART Reset ARM MCU GPIO BT_W akeU p UART 256K/Flash 64K/RAM 26 MHz Crystal BT stack up to HCI Amp’ed Up - abSerial/App - GAP, SPP, DUN, OBEX - SDP/RFCOMM - L2CAP BT22 Bluetooth Module Block Diagram © 7 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 7 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Hardware Design Amp’ed RF modules support UART, USB, SPI, and GPIO hardware interfaces. This section details typical usage models for these features. Please note that the usage of these interfaces is dependant upon the firmware that is loaded into the module, and is beyond the scope of this document. Notes All unused pins should be left floating; do not ground. All GND pins must be well grounded. The area around the module should be free of any ground planes, power planes, trace routings, or metal for at least 8 mm from the antenna in all directions. Traces should not be routed underneath the module. Module Reflow Installation The BT-21 is a surface mount Bluetooth module supplied on a 24 pin, 6-layer PCB. The final assembly recommended reflow profiles are: For non Pb-free applications, Sn63Pb37 solder is recommended. Maximum peak temperature of 208° - 210°C (below 220°C). Maximum rise and fall slope after liquidous of < 2°C/second. Maximum rise and fall slope after liquidous of < 2°C/second. Maximum time at liquidous of 50 – 90 seconds. For RoHS/Pb-free applications, Sn96.5/Ag3.0/Cu0.5 solder is recommended. Maximum peak temperature of 230° - 240°C (below 250°C). Maximum rise and fall slope after liquidous of < 2°C/second. Maximum rise and fall slope after liquidous of < 3°C/second. Maximum time at liquidous of 40 – 80 seconds. GPIO Interface All GPIOs are capable of sinking and sourcing 4mA of I/O current. GPIO [0] to GPIO [7] are internally pulled down with 100KΩ (nominal) resistors GPIO [8] to GPIO [15] are internally pulled up with 100KΩ (nominal) resistors. © 8 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 8 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 UART Interface The UART is compatible with the 16550 industry standard. Four signals are provided with the UART interface. The TXD and RXD pins are used for data while the CTS and RTS pins are used for flow control. CTS TXD Host RXD RTS RXD RTS CTS TXD Amp’ed RF Module Connection to Host Device © 9 2008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 9 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 Amp’ed RF Module Typical RS232 Circuit ©2 10 008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 10 of 11 Amp’ed RF, Inc. (phone) 408 213-9530 (fax) 408 213-9533 FCC Regulatory Compliance FCC licensing is dependent on final antenna implementation. Many tests do not need to be repeated for final compliance and certification. Some external antennas may be pre-approved – please contact technical support for details Ordering Information Part Name BT-22 BT-22A Description Standard size option PCB size option A Picture Not Available BT-22 BT-22A ©2 11 008 Amp’ed RF Inc 10/07/08 1722 Ringwood Ave, Suite 250, San Jose, CA 95131, USA www.ampedrf.com BT-22 Datasheet Page 11 of 11
