FD7-12

Power Transformer Chassis Mount: Quick Pack FD7-12 Description: The FD7-12 Quick Pack small power transformer offers a significant reduction in size and weight over a standard transformer. This transformer can be used for a wide variety of applications. It is bobbin wound for reduced size and small operating space. Electrical Specifications (@25C): Maximum Power: 56.0VA Input Voltage: Series: 230VAC@50/60Hz Parallel: 115VAC@50/60Hz Output Voltage: 12.6VCT@4.0A Construction: Split bobbing non concentric winding eliminates costly electrostatic shielding. Termination is suitable for quick connects or soldering. Safety: UL Class B E53148 10 E 8 6 Dimensions: A 2.250 B 3.125 C 3.687 D 1.812 E 2.687 F .187 Dia G 1.062 A Notes: 1. Units: inches. 2. Terminal size: .187” X 0.21”. 3. Weight: 1.70 lbs C Schematic: 1 6 2 4 8 G 10 5 Input (115V): Input 1 to 2 Connect 1 to 4, 2 to 5 Input (230V): Input 1 to 5 Connect 2 to 4 Output: 6 to10 B RoHS Compliance: As of manufacturing date February 2005, all standard products meet the requirements of 2002/95/EC, known as the RoHS initiative. * Upon printing, this document is considered “uncontrolled”. Please contact Triad Magnetics’ website for the most current version. Web: www.TriadMagnetics.com Phone 951-277-0757 Fax 951-277-2757 22520B Temescal Canyon Road Corona, California 92883 Publish Date: July 24, 2006 1 F D 2 3 4 5
