GT-100-27

Combo Insides.qxd 11/5/2004 14:33 Page 86 GT-100 SERIES-100W I SO 9001:2000 REGISTERED 100 Watts, Switchmode Power Supply, Single Output, Enclosed, Universal Input ELECTRICAL SPECIFICATIONS: INPUT VOLTAGE: 85 VAC TO 264 VAC SELECTED BY SWITCH INPUT CURRENT: < 1.6 A RMS AT 90 VAC INPUT INPUT FREQUENCY: 47 HZ - 63 HZ OUTPUT CURRENT: NO LOAD TO FULL LOAD, NO MINIMUM LOAD REQUIRED OUTPUT POWER (RATED): 100 WATTS MAX OUTPUT RIPPLE (PEAK TO PEAK): 100 mV (P-P) MODEL DEPENDENT OUTPUT REGULATION (LINE/LOAD): 0.2% - 0.5% MODEL + OUTPUT DEPENDENT LINE REGULATION: TURN ON/ TURN OFF OVERSHOOT: 4% MAX 500uS MAX RECOVERY TIME FOR 25% STEP LOAD TURN-ON DELAY: 1 SEC MAX HOLD-UP TIME: 10 mSEC MIN AT NOMINAL INPUT 115 VAC AND FULL LOAD INRUSH CURRENT: 30 A MAX AT COLD START FOR N.A. (60A FOR EURO), MODEL DEPENDENT EFFICIENCY: 70% - 84 % TYPICAL, MODEL + OUTPUT DEPENDENT SWITCHING FREQUENCY: 100 KHZ TYPICAL OVER-VOLTAGE PROTECTION: VOLTAGE LIMITED LESS 130% OF NOMINAL VOLTAGE FOR MAIN OUTPUT OVER-CURRENT / SHORT CIRCUIT: HICCUP WITH AUTO RECOVERY TO 1.1 - 1.3 IO OTHER PROTECTION: INPUT FUSING SAFETY APPROVALS: UL 1012, UL 60950 / 1950, CUL TO 22.2 # 234, 950, TUV TO EN 60950, CE CLASS I DIELECTRIC WITHSTAND VOLTAGE: 1500VAC PRIMARY-SECONDARY; 1500 VAC PRIMARYGROUND 500 VAC SECONDARY - GROUND LEAKAGE CURRENT: < 1 mA/240VAC LINE SURGE: EN 61000-4-5 LEVEL 4 EMI: COMPLIES WITH EN55022, 1 CLASS B AND FCC PART 15 CLASS B WHEN TESTED WITH A RESISTIVE LOAD, BOTH CONDUCTED AND RADIATED CE MARK: TESTED TO COMPLY WITH EN61000-3-2, EN61000-3-3 AND EN50082-1 INCLUDING EN61000-4-2, EN61000-4-3, EN610004-4, EN61000-4-5, EN61000-4-6, EN61000-4-11 LEVEL 4, UNIT IS ELIGIBLE FOR CE MARK. MTBF: GREATER THAN 50,000 HOURS AT 25°C AMBIENT TEMPERATURE OPERATING TEMPERATURE: 0°C TO 45° C, DERATE LINEARY TO 60% OUTPUT POWER AT 60°C STORAGE TEMPERATURE: -40°C TO 80° C HUMIDITY: 0% TO 90% RELATIVE HUMIDITY OUTPUT VOLTAGE / CURRENT: MODEL NUMBER GT-100-3 GT-100-5 GT-100-7.5 GT-100-10 GT-100-12 GT-100-15 GT-100-18 GT-100-24 GT-100-27 GT-100-48 OUTPUT VOLTAGE (VDC) + 3 +/-2% + 5 +/-2% + 7.5 +/-1% + 10 +/-1% + 12 +/-1% + 15 +/-1% + 18 +/-1% + 24 +/-1% + 27 +/-1% + 48 +/-1% OUTPUT CURRENT (mA) 20 20 13.6 10 8.5 6.7 5.6 4.5 3.7 2 RATED OUTPUT POWER (W) 0 - 100 W 0 - 100 W 0 - 100 W 0 - 100 W 0 - 100 W 0 - 100 W 0 - 100 W 0 - 100 W 0 - 100 W 0 - 100 W SPECIFICATIONS MAY CHANGE WITHOUT PRIOR NOTICE. CONSULT GLOBTEK CUSTOMER SERVICE FOR LATEST SPECIFICATIONS. 86 www.globtek.com +1.201.784.1000 Combo Insides.qxd 11/5/2004 14:35 Page 87 GT-100 SERIES-100W 100 Watts, Switchmode Power Supply, Single Output, Enclosed, Universal Input I SO 9001:2000 REGISTERED ENCLOSURES SIZE: 199 X 98 X 38 + 1 MM CONFIGURATION: ENCLOSED SWITCHING POWER SUPPLY, AL. ALLOY 3003 OR EQUIVALENT, GOLD IRRIDITE, CHEM. TREATED FINISH,, CHASSIS: “U’ CHANNEL, WITH (7) MOUNTING METRIC INSERT M3, AS SHOWN BELOW: (4) BOTTOM; (3) RIGHT SIDE. COVER: “L” SHAPE WITH HOLES SCREENED PATTERN FOR NATURAL CONVECTION COOLING THERMAL TRANSFER. CHARTS OUTPUT DERATING STATIC CHARACTERISTICS 5V 6.5V / 7.5V SPECIFICATIONS MAY CHANGE WITHOUT PRIOR NOTICE. CONSULT GLOBTEK CUSTOMER SERVICE FOR LATEST SPECIFICATIONS. +1.201.784.1000 www.globtek.com 87
