Data Sheet
GT-25 SERIES 25W
Switching Power Supplies
SWITCHING POWER SUPPLY, SINGLE OUTPUT: 25 WATTS, ENCLOSED, UNIVERSAL INPUT
ISO 9001
REGISTERED
1. NOTES: DIMENSIONS ARE IN MM UNLESS SPECIFIED OTHERWISE. 2. ELECTRICAL SPECIFICATIONS: INPUT VOLTAGE: INPUT CURRENT: INPUT FREQUENCY: OUTPUT VOLTAGE / CURRENT: 85 VAC TO 264 VAC 0.35A @ 230V 47 HZ - 63 HZ P/N : GT-25-5 GT-25-12 GT-25-15 GT-25-24
MODEL: S-25-5 S-25-12 S-25-15 S-25-24
OUTPUT: +5 VDC +/-2%, 5A +12 VDC +/-1%, 2.1A +15 VDC +/-1%, 1.7A +24 VDC +/-1%, 1.1A
OUTPUT CURRENT : OUTPUT POWER (RATED): OUTPUT RIPPLE (PEAK TO PEAK): ADJUSTABILITY: OUTPUT REGULATION (LINE): LOAD REGULATION (LINE): TURN ON/ TURN OFF OVERSHOOT: TURN-ON DELAY: HOLD-UP TIME: INRUSH CURRENT: EFFICIENCY: SWITCHING FREQUENCY: OVER-VOLTAGE PROTECTION: OVER-CURRENT / SHORT CIRCUIT: OTHER PROTECTION: SAFETY APPROVALS : DIELECTRIC WITHSTAND VOLTAGE: LEAKAGE CURRENT: LINE SURGE: EMI:
NO LOAD TO FULL LOAD, NO MINIMUM LOAD REQUIRED 25 WATTS MAX 50 mV (P-P) FOR 5V, 100 mV (P-P) FOR ALL OTHER OUTPUTS +10, -5% OUTPUT + 5 % FOR OUTPUT 5V MODEL +/-1%, ± 0.5% FOR ALL OTHER OUTPUTS 4% MAX 500uS MAX RECOVERY TIME FOR 25% STEP LOAD 1 SEC MAX 10 mSEC MIN AT NOMINAL INPUT 115 VAC AND FULL LOAD 15 A MAX AT COLD START FOR N.A. (30A FOR EURO) 75 % TYPICAL 100 KHZ TYPICAL VOLTAGE LIMITED LESS 115% ~ 135% OF NOMINAL VOLTAGE FOR MAIN OUTPUT HICCUP WITH AUTO RECOVERY TO 1.1 - 1.3 IO INPUT FUSING UL1012, UL 60950 / 1950, CUL TO 22.2 # 234, 950, TUV TO EN 60950, CE CLASS I 3000VAC PRIMARY-SECONDARY; 1500 VAC PRIMARY- GROUND < 0.75 mA @ 240 VAC EN 61000-4-5 LEVEL 4 COMPLIES WITH EN55022, 1 CLASS B AND FCC PART 15 CLASS B WHEN TESTED WITH A RESISTIVE LOAD, BOTH CONDUCTED AND RADIATED TESTED TO COMPLY WITH EN61000-3-2, EN61000-3-3 AND EN50082-1 INCLUDING EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11 LEVEL 4, UNIT IS ELIGIBLE FOR CE MARK.
CE MARK :
(201)784-1000
www.globtek.com
Te l . : 2 0 1 - 7 8 4 - 1 0 0 0 F a x : 2 0 1 - 7 8 4 - 0 111
G l o b t e k , I n c . 1 8 6 Ve t e r a n s D r i v e , N o r t h v a l e , N J 0 7 6 4 7 .
1
GT-25 SERIES 25W
Switching Power Supplies
Data Sheet
I SO 9001
REGISTERED
SWITCHING POWER SUPPLY, SINGLE OUTPUT: 25 WATTS, ENCLOSED, UNIVERSAL INPUT
MTBF: OPERATING TEMPERATURE: STORAGE TEMPERATURE: HUMIDITY: WEIGHT: VIBRATION: 3. MECHANICAL: MM
GREATER THAN 50,000 HOURS AT 25°C AMBIENT TEMPERATURE 0°C TO 45° C, DERATE LINEARY TO 60% OUTPUT POWER AT 60°C -40°C TO 80° C 0% TO 90% RELATIVE HUMIDITY 0.37 kg REF. 10-500 Hz 2G 10 MIN/ CYCLE (PERIOD = 60 MINUTES, EACH AXIS)
3.1. CONFIGURATION: ENCLOSED SWITCHING POWER SUPPLY, AL. ALLOY 3003 OR EQUIVALENT, GOLD IRRIDITE, CHEM. TREATEDFINISH,, CHASSIS: “U’ CHANNEL, WITH (5) MOUNTING METRIC INSERT M3, AS SHOWN BELOW: (2) BOTTOM; (3) RIGHT SIDE. COVER: “L” SHAPE WITH HOLES SCREENED PATTERN FOR NATURAL CONVECTION COOLING THERMAL TRANSFER.
3.2. INPUT / OUTPUT CONNECTOR: STRAIGHT MOUNT BARRIER STRIP, 5 POSITIONS, 9.5 MM PITCH FOR LUG/TERMINALS INPUT/OUTPUT HARNESS CONNECTIONS 3.3. WIRING DIAGRAM:
186 Veterans Dr. Northvale, NJ 07647 Tel 201 784 1000 Fax 201 784 0111
2
www.globtek.com
G l o b t e k , I n c . 1 8 6 Ve t e r a n s D r i v e , N o r t h v a l e , N J 0 7 6 4 7 .
(201)784-1000
Te l . : 2 0 1 - 7 8 4 - 1 0 0 0 F a x : 2 0 1 - 7 8 4 - 0 111
Data Sheet
GT-25 SERIES 25W
Switching Power Supplies
SWITCHING POWER SUPPLY, SINGLE OUTPUT: 25 WATTS, ENCLOSED, UNIVERSAL INPUT
ISO 9001
REGISTERED
LABEL: MATERIAL: .007 (0.18) THICK FLAT THERMAL TRANSFER, IMPRINTABLE, WHITE OR GRAY POLYESTER SHEET WITH BLACK NOMENCLATURE. MANUFACTURER: STEVEN LABEL, MATERIAL I.D. NO.3302-33, UL FILE NO. MH12821(N), UL MATERIAL DESIGNATION FILE NO. GHW332RL. OPTIONAL LABEL MATERIAL CAN BE SUBSTITUTED PROVIDING MATERIAL IS UL LISTED AND COMPLIES WITH APPLICABLE SAFETY REQUIREMENTS. 4.1. FIRST LABEL: INSTALLED ON TOP OF T1
ITE POWER SUPPLY P/N: GT-25-XX MODEL: S-25-XX INPUT: 100-240 VAC 50-60 Hz 1.6A OUTPUT: VDC A
XX = O/P V
WWYY MADE IN XXXX
XXXX - USA OR CHINA
DATE CODE WW - WEEK YY - YEAR
4.2. SECOND LABEL: INSTALLED ON COVER FACING TERMINAL BLOCK
LN
FG
COM + V
VERIFY WIRE POSITIONS BEFORE HOOKUP
5. INDIVIDUAL PACKING BOX: MATERIAL: CORRUGATED FIBERBOARD, F-FLUTE 0.8 (2.0) THICK, DOUBLE WALL CONSTRUCTION. EXTERNAL FINISH: WHITE, COATED WITH GLOSS FINISH (AQUEOUS OR VARNISH) STYLE: TUCK SIDES WITH LOCKING TABS ON BOTH SIDES OF BOX. NO PRINTING ON THE OUTSIDE OF BOX.
X = 164 mm Y = 42 mm Z = 101 mm
www.globtek.com
186 Veterans Dr. Northvale, NJ 07647 Tel. 201-784-1000 Fax 201.784.0111
DWG TITLE: MODEL NO: PART NO:
SWITCHING POWER SUPPLY, SINGLE OUTPUT: 25 WATTS, ENCLOSED, UNIVERSAL INPUT S-25-XX GT-25-XX
REV. A SHEET 3 OF
