OC-3.3-1027AT

厂商：
ETC2
封装：
描述：
OC-3.3-1027AT - 5X7X1.6mm / 3.3V / SMD / HCMOS/TTL Oscillator - List of Unclassifed Manufacturers

数据手册：

下载OC-3.3-1027AT.pdf

立即购买

详情介绍
数据手册
价格&库存

OC-3.3-1027AT 数据手册

CALIBER Electronics Inc. PART NUMBERING GUIDE Package OC-3.3 = 5X7X1.6mm / 3.3Vdc / HCMOS-TTL OC-2.5 = 5X7X1.6mm / 2.5Vdc / HCMOS-TTL Lead-Free RoHS Compliant OC-3.3 Series 5X7X1.6mm / 3.3V / SMD / HCMOS/TTL Oscillator Environmental/Mechanical Specifications on page F5 OC-3.3- 100 48 A T - 30.000MHz Pin One Connection T = Tri State Enable High Output Symmetry Blank = 40/60%, A = 45/55% Inclusive Stability 100= +/-100ppm, 50= +/-50ppm, 30= +/-30ppm, 25= +/-25ppm, 20= +/-20ppm, 15= +/-15ppm, 10= ±10ppm (25,20,15,10= 0°C-70°C Only) Operating Temperature Range Blank = -10°C to 70°C, 27 = -20°C to 70°C, 48 = -40°C to 85°C ELECTRICAL SPECIFICATIONS Frequency Range Operating Temperature Range Storage Temperature Range Supply Voltage Input Current 1.544MHz to 36.000MHz 36,001MHz to 70.000MHz 70.001MHz to 185.000MHz Inclusive of Operating Temperature Range, Supply Voltage and Load w/HCMOS or TTL Load wHCMOS or TTL Load Revision: 1996-G 1.544MHz to 185.000MHz -10°C to 70°C / -20°C to 70°C / -40°C to 85°C -55°C to 125°C 2.5Vdc ±10% or 3.3Vdc ±10% 10mA Maximum 18mA Maximum 40mA Maximum ±100ppm, ±50ppm, ±30ppm, ±25ppm, ±20ppm, ±15ppm or ±10ppm (25, 20, 15, 10 = 0°C to 70°C ) 90% of Vdd Min. / Ioh=-8mA 10% of Vdd Max. / Iol=8mA Frequency Tolerance / Stability Output Voltage Logic High (Voh) Output Voltage Logic Low (Vol) Rise / Fall Time Duty Cycle Load Drive Capability 10% to 90% of Waveform w/HCMOS Load; 0.4Vdc to 2.4V w/TTL Load / 5nSec Max. @1.4Vdc w/TTL Load; @50% w/HCMOS Load @1.4Vdc w/TTL Load or w/HCMOS Load 1.544MHz - 36.000MHz 36.0001MHz - 70.000MHz 70.0001MHz - 185.000MHz No Connection VIH VIL 50 ±10% (Standard) 50±5% (Optional) 10TTL Load or 30pF / HCMOS Load Max. 10TTL Load or 15pF / HCMOS Load Max. 15pF / HCMOS Load Max. Enables Output +0.7Vdc Minimum to Enable Output +0.3Vdc Maximum to Disable Output ±5ppm / year Maximum 10mSeconds Maximum 10uA Maximum (Disabled Output, High Imp) 1pSec Maximum / 12kHz to 20.000MHz offset Pin 1 Tristate Input Voltage Aging (@ 25°C) Start Up Time Stand By Current RMS Phase Jitter MECHANICAL DIMENSIONS 5.0 Max Metal 1.4 ±0.2 (X4 plcs.) Marking Guide All Dimensions in mm. 4 1 5.08 ±0.15 3 2 7.0 Max Line 1: 3T- Frequency Line 2: CEI YM 3 = 3.3V designator T = Tristate CEI = Caliber Electronics Inc. YM = Date Code (Year / Month) Pin 3: Output Pin 4: Supply Voltage Ceramic 1.6 ±0.2 2.60 ±0.15 Pin 1: Tri-State Pin 2: Case Ground TEL 949-366-8700 FAX 949-366-8707 WEB http://www.caliberelectronics.com

下载 PDF

OC-3.3-1027AT

1. 物料型号： - OC-3.3系列，包括OC-3.3-10048 AT-30.000MHz，5X7X1.6mm/3.3V/SMD/HCMOS/TTL振荡器。

2. 器件简介： - OC-3.3系列振荡器是一款HCMOS/TTL兼容的振荡器，提供3.3V供电电压，具有不同的温度范围和频率稳定性选项。

3. 引脚分配： - Pin 1: Tri-State输入，用于使能输出。 - Pin 2: 接地。 - Pin 3: 输出。 - Pin 4: 供电电压。

4. 参数特性： - 频率范围：1.544MHz至185.000MHz。 - 工作温度范围：-10℃至70℃，-20℃至70℃，-40℃至85℃。 - 供电电压：2.5Vdc +10%或3.3Vdc +10%。 - 输入电流：1.544MHz至36.000MHz最大10mA，36.001MHz至70.000MHz最大18mA，70.001MHz至185.000MHz最大40mA。 - 频率容差/稳定性：±100ppm，+50ppm，+30ppm，+25ppm，20ppm。

5. 功能详解： - 输出电压逻辑高（Voh）：HCMOS或TTL负载下90%的Vdd最小，逻辑低（Vol）：HCMOS或TTL负载下10%的Vdd最大。 - 上升/下降时间：HCMOS负载下0.4Vdc至2.4Vdc，TTL负载下5ns最大。 - 占空比：HCMOS负载下50±10%（标准），TTL负载下50±5%（可选）。

6. 应用信息： - 该振荡器适用于需要HCMOS或TTL兼容输出的应用场合。

7. 封装信息： - 封装为5X7X1.6mm的SMD封装。
