PE-031-10-13

Specification ： TE -module PE-031-10-13 Issue 2 Issued: 29/05/2008 1/2 SPECIFICATION Product：Thermoelectric module Part Number：PE-031-10-13 1． Scope 1—1 1—2 This specification is applied to Multicomp thermoelectric modules Revision of these specifications is carried out after consent. 2． Specification 2－1 Parameters Parameters Internal resistance Imax. Vmax. Th=25℃ Qmax. ⊿Tmax. solder melting point Maximum. compress. 8.5 W 72℃ 138 ℃ 1MPa Note-4 Note-5 Note-6 Note-7 0.95 Ω ± 10% 3.9 A 3.8 V Remarks Note-1 Note-2 Note-3 Note-1 Measured by AC 4-terminal method at 25℃. Note-2 Maximum current at ⊿Tmax. Note-3 Maximum voltage at ⊿Tmax. Note-4 Maximum cooling capacity at Imax.,Vmax. and ⊿T＝0℃. Note-5 Maximum temperature difference at Imax.,Vmax. and Q＝0W. （Maximum parameters are measured in a vacuum 1.3P） Note-6 The solder melting point of thermoelectric module Note-7 Recommended maximum compression (not destruction limit) 2 -2 Recommendations: - maximum temperature for short time: 110 °С - operation temperature up to 90°С for long lifetime; - good reliability in ON-OFF mode - recommended operation current not higher than 0.7 of Imax ２－3 Performance Graph
