RC12-2.5-01S

marlow industries Subsidiary of II-VI Incorporated a global leader in thermoelectric solutions Thermoelectric Cooler RC12-2.5 Performance Values Hot Side Temperature (°C) ∆ Tmax (°C-dry N2): Qmax (watts): Imax (amps): Vmax (vdc): AC Resistance (ohms): 27°C 66 23 2.5 14.7 4.9 50°C 74 26 2.5 16.4 --- RoHS 2002/95/EC Compliant Mechanical Characteristics 1.181 [29.9] POSITIVE LEAD (WHITE) + MARLOW RC12-2.5 123456 .800±.33 [20.32±8.38] USA 1.181 [29.9] 20 AWG LEADS, TEFLON INSULATION - NEGATIVE LEAD (BLACK) 4.00 ±.50 [101.6 ±12.7] 1.339 [34.0] COLD SIDE, Tc -01, -01S .003 [0.08] .002 [0.05] -01L, -01LS .002 [0.05] .001 [0.03] A .002 [0.05] HOT SIDE, Th -01, -01S .159±.005 [4.03 ± .13] -01L, -01LS .155±.001 [3.93 ± .03] Ceramic Material: Alumina (AC) A .001 [0.03] Dimensions in [ ] are millimeters Ordering Options Model Number RC12-2.5-01 RC12-2.5-01L RC12-2.5-01S RC12-2.5-01LS Description Base Model w/ leads Lapped Model Sealed Model Lapped and Sealed Model Features • • • • • • • • RoHS 2002/95/EC compliant Solid-state reliability. Built with high temperature solder with the ability to withstand higher assembly processing temperatures for short periods of time (
