RC3-6

marlow industries Subsidiary of II-VI Incorporated a global leader in thermoelectric solutions Thermoelectric Cooler RC3-6 Performance Values Hot Side Temperature (°C) ∆ Tmax (°C-dry N2): Qmax (watts): Imax (amps): Vmax (vdc): AC Resistance (ohms): 27°C 65 13 5.6 3.6 0.5 50°C 73 14 5.6 4.1 --- RoHS 2002/95/EC Compliant Mechanical Characteristics .787 [19.9] + MARLOW RC 3-6 L 123456 POSITIVE LEAD (WHITE) .30±.25 [7.62±6.35] 20 AWG LEADS, TEFLON INSULATED NEGATIVE LEAD (BLACK) 4.00 ±.50 [101.6 ± 12.7] .787 [19.9] .965 [24.5] _ COLD SIDE, Tc -01, -01S .003 [0.08] .002 [0.05] -01L, -01LS .002 [0.05] .001 [0.03] A .002 [0.05] HOT SIDE, Th -01 & -01S -01L & -01LS .158±.005[4.01±0.13] .154±.001[3.91±0.03] Ceramic Material: Alumina (AC) A .001 [0.03] Dimensions in [ ] are millimeters Ordering Options Model Number RC3-6-01 RC3-6-01L RC3-6-01S RC3-6-01LS Description Base Model w/ leads Lapped Model Sealed Model Lapped and Sealed Model Features • • • • • • • • RoHS 2002/95/EC compliant Solid-state reliability. Built with high temperature solder with the ability to withstand higher assembly processing temperatures for short periods of time (
