SC-6X

SC-6X FAMILY SPEECH AND MUSIC PROCESSORS Whether you need your product to say a few words or talk for several minutes, Sensory’s SC-6x speech and music processors can deliver a few seconds to several hours of speech. Every Sensory speech product is made with your design in mind. Efficient technology allows you to cut costs and size by using smaller and fewer devices. A complete range of development tools and software helps you get your products to market faster. POWERFUL TECHNOLOGY The SC-6x product family introduces a new world of speech synthesis opportunities. This family is built around a 12.32 million instructions per second (MIPS) Digital Signal Processor (DSP) to enable advanced speech algorithms, yielding speech quality never before obtained at such low data rates. These DSPs provide three low-power modes, two timer interrupts, one DAC interrupt and five general-purpose interrupts. These features increase battery life and speed of response to button and keyboard presses. Sensory SC-6x employs three processing methods - CX, MX, LPC - that produce natural sounding speech while using a relatively small amount of memory. Your product’s quality will speak for itself. If your product needs music, Sensory offers several choices, including simultaneous speech with high quality polyphonic music. A RANGE OF CHOICES Not only can you choose the optimum combination of price and capacity, you can adopt any of these digital storage alternatives: On-chip mask programmable ROM, External memory (SC-614 only). TYPES OF SYNTHESIS Memory Required per Minute of Speech (KB) Data Rate Kbps CX synthesis is your solution for producing long durations of great speech and sound effects at the lowest possible system cost. MX offers data rates as low as 1K bits-persecond, yielding high quality speech with minimal development effort. 3.0~11.2 22.5~84.0 MX synthesis provides optimal speech and sound effects. Its highly sophisticated analysis can reproduce the subtle qualities of a broad range of character voices. CX offers up to six choices of data rates to help you optimize speech quality and memory cost. 1.0~3.5 1.8 7.5~26.2 13.5 LPC is mathematically simpler than MX or CX, requiring less processing power but more editing. Music Synthesis Sensory also provides a way to enhance your products with high quality music synthesis. Sensory’s music synthesizer provides polyphonic music using standard Musical Instrument Digital Interface (MIDI) files that have been converted into compact bitstreams. This gives the ability to play up to 14 channels of music. Music + Speech The music synthesizer can also play polyphonic music simultaneously with speech (MX or CX), adding even more excitement to your products. Product Brief (80-0213-C) SC-6X FAMILY SC-601 The SC-601 has a 1.5 Mb ROM to support up to 24 minutes of internally-stored MX speech or up to 8 minutes of CX speech. SC-604 The SC-604 contains the same powerful core, ROM and RAM as the other SC-6x devices, but has a reduced I/O set and pin count which makes it the most economical of the SC-6x family members. SC-605 The SC-605 has a 2.36Mb (288KB) ROM to support up to 37 minutes of internally-stored MX speech or up to 12 minutes of CX speech. This device is a perfect one-chip system solution, functioning as master controller, speech processor, and data memory. SC-614 The SC-614 expands the capability of the SC-6x family by incorporating 64 I/O pins for interfacing with the outside world. It can also address up to 64Mb of external memory, providing over 18 hours of speech duration! 16-Bit Microprocessor 10-Bit DAC 1280-Bytes RAM TIMER 1 TIMER 2 PLLM 64/192/288-KBytes ROM COMPARATOR 16/32/64 I/O SC-614 only SC-6X BLOCK DIAGRAM SC-604 ROM (bytes) I/O Pins (packaged) I/O Pins (die) Pin Count (package) Pin Count (die) Built-In DAC Built-In Comparator 64K 16 16 64 36 Yes Yes RAM (bits) 10880 SC-605 288K 10880 32 32 100 53 Yes Yes 37 min SC-601 192K 10880 32 32 100 53 Yes Yes SC-614 64K 10880 64 64 100 85 Yes Yes Max Speech Duration 6.5 min (1.0 Kbps internal ROM) 24 min 6.5 min * Sensory SC-6x family of processors * The SC-614 can be interfaced to external memory for longer SC-691 h The SC-691 is a pre-programmed slave synthesizer implemented on the SC-6x family line that accepts commands and compressed speech data from other microprocessors or microcontrollers and converts it to speech output. Since no SC-6x programming knowledge is needed, this is the simplest SC-6x family member to develop with. SPEECH SYNTHESIS DURATION FOR SC-6X DEVICES 1 Single-Chip Speech Duration (8 KHz Sampling Rate) Speech Algorithm Compression Rate (bps ) SC-605 SC-601 1000 37min 24min MX 2400 15min 10min 2,40 min 29min 58min 1hr 56min 3hr 53min 3000 12min 7min 45sec 2 min 23min 46min 1hr 33min 3hr 6min 3700 9min 50sec 6min 20sec 1,35min 18min 37min 1hr 15min 2hr 31min 4500 8min 5sec 1min 20sec 15min 31min 1hr 2min 2hr 4min CX 6200 7700 3min 45sec 9min 18min 36min 1hr 12min 11200 3min 15sec 2min 5sec 30sec 6min 10sec 12min 24min 49min 5min 50sec 4min 45sec 55sec 11min 22min 45min 1hr 30min 5min 10sec 3min 45sec SC-604/614 6min 30sec 4 Mb ROM or flash 8 Mb ROM or flash 16 Mb ROM or flash 64 Mb ROM or flash 1 Additional Duration Available by Adding External Memory (8 KHz Sampling Rate) 1hr 9min 2hr 19min 4hr 39min 9hr 19min These times are examples which assume a small (2Kw) control code, the exact speech duration depends on the size of the control code. 1991 Russell Avenue Tel 408.327.9000 www.sensoryinc.com ● ● ● Santa Clara, CA 95054 Fax 408.727.4748 sales@sensoryinc.com
