TS-RDS1

TS-RDS1 Description TS-RDS1 is a USB 2.0 Compact Card Reader. It is a small device specifically designed for fast, easy data transfer and exchange using multiple types of Memory Cards. The Card Reader accepts the direct insertion of; Secure Digital (SD™), Secure Digital High Capacity (SDHC™), miniSD™(SD™), miniSDHC™, MultiMediaCard (MMC™), MMCplus™, RS-MMC, and MMCmobile™ Memory Cards. In addition the Reader supports microSD™ and MMCmicro™ Memory USB 2.0 Compact Card Reader Placement Cards, when combined with their adapter. Features • Fully Compliant with the Hi-Speed USB 2.0 specification • Hi-Speed Data transfer rates of up to 480Mb/s • USB powered (no external power or battery needed) • Supports many different types of Memory Cards without the need for an adapter : O O O O O O O O Dimensions Side A B Millimeters 69.00 ± 1.00 35.00 ± 1.00 15.00 ± 1.00 Inches 2.72 ± 0.04 1.38 ± 0.04 0.59 ± 0.04 Secure Digital Card (SD™) Secure Digital High Capacity (SDHC ) miniSD ™ ™ C miniSDHC™ MultiMediaCard (MMC™) MMCplus™ RS-MMC MMCmobile microSD™ MMCmicro™ ™ O O O O O O System Requirements Desktop or notebook computer with a working USB port One of the following Operating Systems: Windows® 98/98SE Windows® 2000 Windows® Me Windows® XP Mac™ OS 9.x, or later Linux™ Kernel 2.4, or later • Supports additional Memory Cards with an adapter : O O • LED indicates power connection Transcend information Inc 1 TS-RDS1 Block Diagram USB Interface +5V ALCOR AU6333 Power +3.3V USB 2.0 Compact Card Reader Memory Card Pinouts Pin No. 01 02 03 04 Pin Identification Symbol USBUSB+ VSS VCC Function USB differential signal: The pairs are used to transmit Data/Address/Command Ground USB Power Input Pin Name VCC USBUSB+ VSS Transcend information Inc 2 TS-RDS1 Absolute Maximum Rating USB 2.0 Compact Card Reader Recommended Operating Conditions General DC Characteristics Transcend information Inc 3 TS-RDS1 DC Characteristics USB 2.0 Compact Card Reader USB Transceiver Electrical Characteristics Above technical information is based on industry standard data and tested to be reliable. However, Transcend makes no warranty, either expressed or implied, as to its accuracy and assumes no liability in connection with the use of this product. Transcend reserves the right to make changes in specifications at any time without prior notice. Transcend information Inc 4
