BTT6030-2EKA

P R O F ET ™ + 24 V B T T 60 3 0- 2 E K A Smart High-Side Power Switch Dual Channel, 32m D a ta S he e t PROFET™+ 24V Rev. 1.1, 2015-03-04 A u t o mo t i v e P ow e r BTT6030-2EKA Table of Contents Table of Contents 1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 3 3.1 3.2 3.3 Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pin Definitions and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Voltage and Current Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 4.1 4.2 4.3 4.3.1 4.3.2 General Product Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Functional Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Thermal Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 PCB set up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Thermal Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 5 5.1 5.2 5.3 5.3.1 5.3.2 5.4 5.5 Power Stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Output ON-state Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Turn ON/OFF Characteristics with Resistive Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Inductive Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Output Clamping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Maximum Load Inductance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Inverse Current Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Electrical Characteristics Power Stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 15 15 16 16 17 17 19 6 6.1 6.2 6.3 6.4 6.5 6.5.1 6.5.2 6.6 Protection Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Loss of Ground Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Undervoltage Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Overvoltage Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Reverse Polarity Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Overload Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Current Limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Temperature Limitation in the Power DMOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Electrical Characteristics for the Protection Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 21 21 22 23 23 23 24 26 7 7.1 7.2 7.3 7.3.1 7.3.2 7.3.3 7.3.3.1 7.3.3.2 7.3.3.3 7.3.4 7.3.5 7.3.6 7.4 Diagnostic Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IS Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SENSE Signal in Different Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SENSE Signal in the Nominal Current Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SENSE Signal Variation as a Function of Temperature and Load Current . . . . . . . . . . . . . . . . . . . SENSE Signal Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SENSE Signal in Open Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Open Load in ON Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Open Load in OFF Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Open Load Diagnostic Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SENSE Signal with OUT in Short Circuit to VS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SENSE Signal in Case of Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SENSE Signal in Case of Inverse Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Electrical Characteristics Diagnostic Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 27 28 29 29 30 31 31 31 32 33 33 33 34 8 8.1 8.2 Input Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Input Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 DEN / DSEL Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Data Sheet PROFET™+ 24V 2 7 7 7 8 Rev. 1.1, 2015-03-04 BTT6030-2EKA Table of Contents 8.3 8.4 Input Pin Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 9 9.1 9.1.1 9.1.2 9.1.3 9.1.4 9.1.5 9.2 9.2.1 9.2.2 9.2.3 9.2.4 9.2.5 9.2.6 9.2.7 9.2.8 9.2.9 9.3 9.3.1 9.3.2 9.4 9.4.1 9.4.2 9.4.3 9.4.4 9.5 9.5.1 9.5.2 9.5.3 9.5.4 Characterization Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . General Product Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Minimum Functional Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Undervoltage Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Current Consumption One Channel active . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Current Consumption Two Channels active . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Standby Current for Whole Device with Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power Stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Output Voltage Drop Limitation at Low Load Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Drain to Source Clamp Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Slew Rate at Turn ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Slew Rate at Turn OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Turn ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Turn OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Turn ON / OFF matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Switch ON Energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Switch OFF Energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Protection Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Overload Condition in the Low Voltage Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Overload Condition in the High Voltage Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Diagnostic Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Current Sense at no Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Open Load Detection Threshold in ON State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Sense Signal Maximum Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Sense Signal maximum Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Input Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Input Voltage Threshold ON to OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Input Voltage Threshold OFF to ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Input Voltage Hysteresis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Input Current High Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 10.1 Application Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Further Application Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 11 Package Outlines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 12 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Data Sheet PROFET™+ 24V 3 39 39 39 39 40 40 40 41 41 41 42 42 42 43 43 44 44 45 45 45 46 46 46 47 47 48 48 48 49 49 Rev. 1.1, 2015-03-04 Smart High-Side Power Switch 1 BTT6030-2EKA Overview Application • • • • Suitable for resistive, inductive and capacitive loads Replaces electromechanical relays, fuses and discrete circuits Most suitable for loads with high inrush current, such as lamps Suitable for 24V Trucks and Transportation System Basic Features • • • • • • • • • PG-DSO-14-40 EP Two channel device Very low stand-by current 3.3 V and 5 V compatible logic inputs Electrostatic discharge protection (ESD) Optimized electromagnetic compatibility Logic ground independent from load ground Very low power DMOS leakage current in OFF state Green product (RoHS compliant) AEC qualified Description The BTT6030-2EKA is a 32 m dual channel Smart High-Side Power Switch, embedded in a PG-DSO-14-40 EP, Exposed Pad package, providing protective functions and diagnosis. The power transistor is built by an N-channel vertical power MOSFET with charge pump. The device is integrated in Smart6 HV technology. It is specially designed to drive lamps up to 3 * P21W 24V or 1 * 70W 24V, as well as LEDs in the harsh automotive environment. Table 1 Product Summary Parameter Symbol Value Operating voltage range VS(OP) VS(LD) RDS(ON) IL(NOM)1 IL(NOM)2 kILIS IL5(SC) IS(OFF) 5 V ... 36 V Maximum supply voltage Maximum ON state resistance at TJ = 150 °C per channel Nominal load current (one channel active) Nominal load current (both channels active) Typical current sense ratio Minimum current limitation Maximum standby current with load at TJ = 25 °C 65 V 62 m 6A 4A 2240 56 A 500 nA Type Package Marking BTT6030-2EKA PG-DSO-14-40 EP BTT6030-2EKA Data Sheet PROFET™+ 24V 4 Rev. 1.1, 2015-03-04 BTT6030-2EKA Overview Diagnostic Functions • • • • • • Proportional load current sense for both channels multiplexed Open load in ON and OFF Short circuit to battery and ground Overtemperature Stable diagnostic signal during short circuit Enhanced kILIS dependency with temperature and load current Protection Functions • • • • • • • Stable behavior during undervoltage Reverse polarity protection with external components Secure load turn-off during logic ground disconnect with external components Overtemperature protection with latch Overvoltage protection with external components Voltage dependent current limitation Enhanced short circuit operation Data Sheet PROFET™+ 24V 5 Rev. 1.1, 2015-03-04 BTT6030-2EKA Block Diagram 2 Block Diagram Figure 1 Block Diagram for the BTT6030-2EKA Data Sheet PROFET™+ 24V 6 Rev. 1.1, 2015-03-04 BTT6030-2EKA Pin Configuration 3 Pin Configuration 3.1 Pin Assignment GND 1 14 OUT0 IN0 2 13 OUT0 DEN 3 12 OUT0 IS 4 11 NC DSEL 5 10 OUT1 IN1 6 9 OUT1 NC 7 8 OUT1 Pinout dual SO14 .vsd Figure 2 Pin Configuration 3.2 Pin Definitions and Functions Pin Symbol Function 1 GND GrouND; Ground connection 2 IN0 INput channel 0; Input signal for channel 0 activation 3 DEN Diagnostic ENable; Digital signal to enable/disable the diagnosis of the device 4 IS Sense; Sense current of the selected channel 5 DSEL Diagnostic SELection; Digital signal to select the channel to be diagnosed 6 IN1 INput channel 1; Input signal for channel 1 activation 7, 11 NC Not Connected; No internal connection to the chip 8, 9, 10 OUT1 OUTput 1; Protected high side power output channel 1 1) 12, 13, 14 OUT0 OUTput 0; Protected high side power output channel 0 1) Cooling Tab VS Voltage Supply; Battery voltage 1) All output pins of a given channel must be connected together on the PCB. All pins of an output are internally connected together. PCB traces have to be designed to withstand the maximum current which can flow. Data Sheet PROFET™+ 24V 7 Rev. 1.1, 2015-03-04 BTT6030-2EKA Pin Configuration 3.3 Voltage and Current Definition Figure 3 shows all terms used in this data sheet, with associated convention for positive values. Figure 3 Voltage and Current Definition Data Sheet PROFET™+ 24V 8 Rev. 1.1, 2015-03-04 BTT6030-2EKA General Product Characteristics 4 General Product Characteristics 4.1 Absolute Maximum Ratings Table 2 Absolute Maximum Ratings 1) TJ = -40 °C to +150 °C; (unless otherwise specified) Parameter Symbol Values Unit Note / Test Condition Number 48 V – P_4.1.1 – 28 V P_4.1.2 – 36 V t < 2 min TA = 25 °C RL 12 RGND = 150 RECU = 20 m RCable= 16 m /m LCable= 1 µH/m, l = 0 or 5 m Min. Typ. Max. VS -VS(REV) -0.3 – 0 VBAT(SC) 0 Supply Voltages Supply voltage Reverse polarity voltage Supply voltage for short circuit protection P_4.1.3 See Chapter 6 and Figure 53 – – 65 V 2) RI = 2 RL = 12 P_4.1.12 nRSC1 – – 100 k cycles 3) P_4.1.4 VIN -0.3 – – 6 7 V IIN VDEN -2 – 2 mA -0.3 – – 6 7 V IDEN VDSEL -2 – 2 mA – P_4.1.16 -0.3 – – 6 7 V – P_4.1.17 IDSEL -2 – 2 mA – P_4.1.18 VIS IIS -0.3 – VS V – P_4.1.19 -25 – 50 mA – P_4.1.20 Load current | IL | – – IL(LIM) A – P_4.1.21 Power dissipation (DC) PTOT – – 2.0 W TA = 85 °C TJ < 150 °C P_4.1.22 Supply voltage for Load dump VS(LD) protection Short Circuit Capability Permanent short circuit IN pin toggles VSupply= 28V Input Pins Voltage at INPUT pins Current through INPUT pins Voltage at DEN pin Current through DEN pin Voltage at DSEL pin Current through DSEL pin – P_4.1.13 t < 2 min – P_4.1.14 – P_4.1.15 t < 2 min t < 2 min Sense Pin Voltage at IS pin Current through IS pin Power Stage Data Sheet PROFET™+ 24V 9 Rev. 1.1, 2015-03-04 BTT6030-2EKA General Product Characteristics Table 2 Absolute Maximum Ratings (cont’d)1) TJ = -40 °C to +150 °C; (unless otherwise specified) Parameter Symbol Values Unit Note / Test Condition Number Min. Typ. Max. Maximum energy dissipation EAS Single pulse (one channel) – – 85 mJ IL(0) = 4 A TJ(0) = 150 °C VS = 28 V P_4.1.23 VDS – – 65 V – P_4.1.26 I GND -20 -200 – 20 20 mA – P_4.1.27 TJ TSTG -40 – 150 °C – P_4.1.28 -55 – 150 °C – P_4.1.30 VESD VESD -2 – 2 kV 4) HBM P_4.1.31 -4 – 4 kV 4) HBM P_4.1.32 VESD VESD -500 – 500 V 5) CDM P_4.1.33 V 5) CDM P_4.1.34 Voltage at power transistor Currents Current through ground pin t < 2 min Temperatures Junction temperature Storage temperature ESD Susceptibility ESD susceptibility (all pins) ESD susceptibility OUT Pin vs. GND and VS connected ESD susceptibility ESD susceptibility pin (corner pins) -750 – 750 1) Not subject to production test. Specified by design. 2) VS(LD) is setup without the DUT connected to the generator per ISO 7637-1. 3) Threshold limit for short circuit failures : 100ppm. Please refer to the legal disclaimer for short circuit capability at the end of this document. 4) ESD susceptibility HBM according to ANSI/ESDA/JEDEC JS-001-2010 5) “CDM” ESDA STM5.3.1 Notes 1. Stresses above the ones listed here may cause permanent damage to the device. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. 2. Integrated protection functions are designed to prevent IC destruction under fault conditions described in the data sheet. Fault conditions are considered as “outside” normal operating range. Protection functions are not designed for continuous repetitive operation. Data Sheet PROFET™+ 24V 10 Rev. 1.1, 2015-03-04 BTT6030-2EKA General Product Characteristics 4.2 Functional Range Table 3 Functional Range TJ = -40 °C to +150 °C; (unless otherwise specified) Parameter Symbol Nominal operating voltage VNOM VS(OP) Extended operating voltage Values Min. Typ. Max. 8 28 36 5 – 48 Unit Note / Test Condition Number V – P_4.2.1 V 2) P_4.2.2 VIN = 4.5 V RL = 12 VDS < 0.5 V See Figure 15 Minimum functional supply voltage VS(OP)_MIN 3.8 4.3 5 V 1) VIN = 4.5 V RL = 12 From IOUT = 0 A P_4.2.3 to VDS < 0.5 V; See Figure 15 See Figure 29 Undervoltage shutdown VS(UV) 3 3.5 4.1 V 1) VIN = 4.5 V VDEN = 0 V RL = 12 From VDS < 1 V; to IOUT = 0 A P_4.2.4 See Figure 15 See Figure 30 Undervoltage shutdown hysteresis VS(UV)_HYS – 850 – mV 2) Operating current One channel active IGND_1 – 5.5 9 mA P_4.2.5 VIN = 5.5 V VDEN = 5.5 V Device in RDS(ON) VS = 36 V Operating current All channels active IGND_2 – 9 12 mA P_4.2.6 VIN = 5.5 V VDEN = 5.5 V Device in RDS(ON) VS = 36 V Standby current for whole device with load (ambiente) IS(OFF) – 0.1 0.5 µA 1) – P_4.2.13 See Figure 31 See Figure 32 VS = 36 V VOUT = 0 V VIN floating VDEN floating TJ 85 °C P_4.2.7 See Figure 33 Data Sheet PROFET™+ 24V 11 Rev. 1.1, 2015-03-04 BTT6030-2EKA General Product Characteristics Table 3 Functional Range (cont’d)TJ = -40 °C to +150 °C; (unless otherwise specified) Parameter Symbol Maximum standby current for IS(OFF)_150 whole device with load Values Unit Note / Test Condition Number VS = 36 V VOUT = 0 V VIN floating VDEN floating TJ 150 °C P_4.2.10 Min. Typ. Max. – 6 15 µA – 0.6 – mA See Figure 33 Standby current for whole device with load, diagnostic active IS(OFF_DEN) 2) VS = 36 V VOUT = 0 V VIN floating VDEN = 5.5 V P_4.2.8 1) Test at TJ = -40°C only 2) Not subject to production test. Specified by design. Note: Within the functional range the IC operates as described in the circuit description. The electrical characteristics are specified within the conditions given in the related electrical characteristics table. 4.3 Thermal Resistance Table 4 Thermal Resistance Parameter Symbol Junction to soldering point Junction to ambient Both channels active RthJS RthJA Values Min. Typ. Max. – 5 – – 29 – Unit Note / Test Condition Number K/W 1) P_4.3.1 K/W 1) 2) P_4.3.2 1) Not subject to production test. Specified by design. 2) Specified Rthja value is according to JEDEC JESD51-2,-5,-7 at natural convection on FR4 2s2p board; The product (chip + package) was simulated on a 76.4 x 114.3 x 1.5 mm board with 2 inner copper layers (2 x 70µm Cu, 2 x 35 µm Cu). Where applicable, a thermal via array under the exposed pad contacts the first inner copper layer. Please refer to Figure 4. 4.3.1 PCB set up Figure 4 2s2p PCB Cross Section Data Sheet PROFET™+ 24V 12 Rev. 1.1, 2015-03-04 BTT6030-2EKA General Product Characteristics S thermique SO14.vsd Figure 5 PC Board Top and Bottom View for Thermal Simulation with 600 mm² Cooling Area 4.3.2 Thermal Impedance Figure 6 Typical Thermal Impedance. 2s2p set up according Figure 4 Data Sheet PROFET™+ 24V 13 Rev. 1.1, 2015-03-04 BTT6030-2EKA General Product Characteristics Figure 7 Typical Thermal Resistance. PCB set up 1s0p Data Sheet PROFET™+ 24V 14 Rev. 1.1, 2015-03-04 BTT6030-2EKA Power Stage 5 Power Stage The power stages are built using an N-channel vertical power MOSFET (DMOS) with charge pump. 5.1 Output ON-state Resistance The ON-state resistance RDS(ON) depends on the supply voltage as well as the junction temperature TJ. Figure 8 shows the dependencies in terms of temperature and supply voltage for the typical ON-state resistance. The behavior in reverse polarity is described in Chapter 6.4. Figure 8 Typical ON-state Resistance A high signal (see Chapter 8) at the input pin causes the power DMOS to switch ON with a dedicated slope, which is optimized in terms of EMC emission. 5.2 Turn ON/OFF Characteristics with Resistive Load Figure 9 shows the typical timing when switching a resistive load. IN _H IN _L OUT ON OFF ON S OFF_D ELAY S S ON _D EL AY OFF S Figure 9 Switching a Resistive Load Timing Data Sheet PROFET™+ 24V 15 Rev. 1.1, 2015-03-04 BTT6030-2EKA Power Stage 5.3 Inductive Load 5.3.1 Output Clamping When switching OFF inductive loads with high side switches, the voltage VOUT drops below ground potential, because the inductance intends to continue driving the current. To prevent the destruction of the device by avalanche due to high voltages, there is a voltage clamp mechanism ZDS(AZ) implemented that limits negative output voltage to a certain level (VS - VDS(AZ)). Please refer to Figure 10 and Figure 11 for details. Nevertheless, the maximum allowed load inductance is limited. Figure 10 Output Clamp (OUT0 and OUT1) Figure 11 Switching an Inductive Load Timing Data Sheet PROFET™+ 24V 16 Rev. 1.1, 2015-03-04 BTT6030-2EKA Power Stage 5.3.2 Maximum Load Inductance During demagnetization of inductive loads, energy has to be dissipated in the BTT6030-2EKA. This energy can be calculated with following equation: E = V DS L RL ------ AZ V S – V DS AZ -------------------------------RL R L IL ln 1 – -------------------------------- + I L VS – VDS AZ Following equation simplifies under the assumption of RL = 0 2 1 E = --- L I 2 (1) . VS 1 – -------------------------------VS – VDS AZ (2) The energy, which is converted into heat, is limited by the thermal design of the component. See Figure 12 for the maximum allowed energy dissipation as a function of the load current. Figure 12 Maximum Energy Dissipation Single Pulse, TJ(0) = 150 °C; VS = 28V 5.4 Inverse Current Capability In case of inverse current, meaning a voltage VINV at the OUTput higher than the supply voltage VS, a current IINV will flow from output to VS pin via the body diode of the power transistor (please refer to Figure 13). The output stage follows the state of the IN pin, except if the IN pin goes from OFF to ON during inverse. In that particular case, the output stage is kept OFF until the inverse current disappears. Nevertheless, the current IINV should not be higher than IL(INV). Otherwise, the second channel can be corrupted and erratic behavior can be observed. If the affected channel is OFF, the diagnostic will detect an open load at OFF. If the affected channel is ON, the diagnostic will detect open load at ON (the overtemperature signal is inhibited). At the appearance of VINV, a parasitic diagnostic can be observed at the unaffected channel. After, the diagnosis is valid and reflects the output state. At VINV vanishing, the diagnosis is valid and reflects the output state. During inverse current, no protection function are available. Data Sheet PROFET™+ 24V 17 Rev. 1.1, 2015-03-04 BTT6030-2EKA Power Stage &%8 -2: +2( Figure 13 Inverse Current Circuitry Data Sheet PROFET™+ 24V 18 Rev. 1.1, 2015-03-04 BTT6030-2EKA Power Stage 5.5 Electrical Characteristics Power Stage Table 5 Electrical Characteristics: Power Stage VS = 8 V to 36 V, TJ = -40 °C to +150 °C (unless otherwise specified). Typical values are given at VS = 28 V, TJ = 25 °C Parameter ON-state resistance per channel Symbol RDS(ON)_150 Values Min. Typ. Max. 40 55 62 Unit Note / Test Condition Number m IL = IL4 = 7 A VIN = 4.5 V TJ = 150 °C P_5.5.1 See Figure 8 ON-state resistance per channel RDS(ON)_25 – 32 – m 1) Nominal load current One channel active IL(NOM)1 – 6 – A 1) Nominal load current All channels active IL(NOM)2 – 4 – A Output voltage drop limitation VDS(NL) at small load currents – 10 22 mV TJ = 25 °C TA = 85 °C TJ < 150 °C P_5.5.21 P_5.5.2 P_5.5.3 IL = IL0 = 50 mA P_5.5.4 See Figure 34 Drain to source clamping voltage VDS(AZ) = [VS - VOUT] VDS(AZ) 66 70 75 V IDS = 20 mA See Figure 11 See Figure 35 P_5.5.5 Output leakage current per channel; TJ 85 °C IL(OFF) – 0.05 0.5 µA 2) P_5.5.6 Output leakage current per channel; TJ = 150 °C IL(OFF)_150 – 2 10 µA VIN floating VOUT = 0 V TJ 85°C VIN floating VOUT = 0 V TJ = 150 °C RL = 12 VS = 28 V P_5.5.8 Slew rate 30% to 70% VS V/dtON 0.3 0.8 1.4 V/µs Slew rate 70% to 30% VS - V/dtOFF 0.3 0.8 1.4 V/µs -0.15 0 0.15 V/µs Turn-ON time to VOUT = 90% tON 20 50 150 µs Turn-OFF time to VOUT = 10% tOFF 20 55 150 µs P_5.5.15 -50 0 50 µs P_5.5.16 Turn-ON time to VOUT = 10% tON_delay – 30 70 µs P_5.5.17 Turn-OFF time to VOUT = 90% tOFF_delay – 30 70 µs P_5.5.18 Slew rate matching dV/dtON - dV/dtOFF dV/dt VS P_5.5.11 See Figure 9 See Figure 36 See Figure 37 See Figure 38 See Figure 39 See Figure 40 P_5.5.12 P_5.5.13 P_5.5.14 VS Turn-ON / OFF matching tOFF - tON tSW VS VS Data Sheet PROFET™+ 24V 19 Rev. 1.1, 2015-03-04 BTT6030-2EKA Power Stage Table 5 Electrical Characteristics: Power Stage (cont’d) VS = 8 V to 36 V, TJ = -40 °C to +150 °C (unless otherwise specified). Typical values are given at VS = 28 V, TJ = 25 °C Parameter Symbol Switch ON energy EON Values Min. Typ. Max. – 0.6 – Unit Note / Test Condition Number mJ 1) P_5.5.19 mJ 1) RL = 12 VOUT = 90% VS VS = 36 V See Figure 41 Switch OFF energy EOFF – 0.8 – RL = 12 VOUT = 10% VS VS = 36 V P_5.5.20 See Figure 42 1) Not subject to production test, specified by design. 2) Test at TJ = -40°C only Data Sheet PROFET™+ 24V 20 Rev. 1.1, 2015-03-04 BTT6030-2EKA Protection Functions 6 Protection Functions The device provides integrated protection functions. These functions are designed to prevent the destruction of the IC from fault conditions described in the data sheet. Fault conditions are considered as “outside” normal operating range. Protection functions are designed for neither continuous nor repetitive operation. 6.1 Loss of Ground Protection In case of loss of the module ground and the load remains connected to ground, the device protects itself by automatically turning OFF (when it was previously ON) or remains OFF, regardless of the voltage applied on IN pins. In case of loss of device ground, it’s recommended to use input resistors between the microcontroller and the BTT6030-2EKA to ensure switching OFF of the channels. In case of loss of module or device ground, a current (IOUT(GND)) can flow out of the DMOS. Figure 14 sketches the situation. ZGND is recommended to be a resistor in serias to a diode. >-7%> :7 >(%> -7 67)27) :&%8 >(7%> (7)0 6(7)0 ()2 6()2 -2 6-2 -398+2( 03+-' -2 6-2 398 >()7( +2( 6-7 >+2( 0SWWSJKVSYRHTVSXIGXMSRWZK Figure 14 Loss of Ground Protection with External Components 6.2 Undervoltage Protection Between VS(UV) and VS(OP), the undervoltage mechanism is triggered. VS(OP) represents the minimum voltage where the switching ON and OFF can takes place. VS(UV) represents the minimum voltage the switch can hold ON. If the supply voltage is below the undervoltage mechanism VS(UV), the device is OFF (turns OFF). As soon as the supply voltage is above the undervoltage mechanism VS(OP), then the device can be switched ON. When the switch is ON, protection functions are operational. Nevertheless, the diagnosis is not guaranteed until VS is in the VNOM range. Figure 15 sketches the undervoltage mechanism. Data Sheet PROFET™+ 24V 21 Rev. 1.1, 2015-03-04 BTT6030-2EKA Protection Functions Figure 15 Undervoltage Behavior 6.3 Overvoltage Protection There is an integrated clamp mechanism for overvoltage protection (ZD(AZ)). To guarantee this mechanism operates properly in the application, the current in the Zener diode has to be limited by a ground resistor. Figure 16 shows a typical application to withstand overvoltage issues. In case of supply voltage higher than VS(AZ), the power transistor switches ON and the voltage across the logic section is clamped. As a result, the internal ground potential rises to VS - VS(AZ). Due to the ESD Zener diodes, the potential at pin IN and DEN rises almost to that potential, depending on the impedance of the connected circuitry. In the case the device was ON, prior to overvoltage, the BTT6030-2EKA remains ON. In the case the BTT6030-2EKA was OFF, prior to overvoltage, the power transistor can be activated. In the case the supply voltage is in above VBAT(SC) and below VDS(AZ), the output transistor is still operational and follows the input. If at least one channel is in the ON state, parameters are no longer guaranteed and lifetime is reduced compared to the nominal supply voltage range. This especially impacts the short circuit robustness, as well as the maximum energy EAS capability. 73: -7%> 7 (%> (7%> &%8 7)27) (7)0 ()2 -2 -2 )7( -7 +2( 3ZIVZSPXEKITVSXIGXMSRWZK Figure 16 Overvoltage Protection with External Components Data Sheet PROFET™+ 24V 22 Rev. 1.1, 2015-03-04 BTT6030-2EKA Protection Functions 6.4 Reverse Polarity Protection In case of reverse polarity, the intrinsic body diodes of the power DMOS causes power dissipation. The current in this intrinsic body diode is limited by the load itself. Additionally, the current into the ground path and the logic pins has to be limited to the maximum current described in Chapter 4.1 with an external resistor. Figure 17 shows a typical application. RGND resistor is used to limit the current in the Zener protection of the device. Resistors RDSEL, RDEN, and RIN are used to limit the current in the logic of the device and in the ESD protection stage. RSENSE is used to limit the current in the sense transistor which behaves as a diode. The recommended value for RDEN = RDSEL = RIN = RSENSE = 10 k . ZGND is recommended to be a resistor in series to a diode. During reverse polarity, no protection functions are available. Figure 17 Reverse Polarity Protection with External Components 6.5 Overload Protection In case of overload, such as high inrush of cold lamp filament, or short circuit to ground, the BTT6030-2EKA offers several protection mechanisms. 6.5.1 Current Limitation At first step, the instantaneous power in the switch is maintained at a safe value by limiting the current to the maximum current allowed in the switch IL(SC). During this time, the DMOS temperature is increasing, which affects the current flowing in the DMOS. The current limitation value is VDS dependent. Figure 18 shows the behavior of the current limitation as a function of the drain to source voltage. Data Sheet PROFET™+ 24V 23 Rev. 1.1, 2015-03-04 BTT6030-2EKA Protection Functions 80 70 60 50 40 30 20 10 0 3 8 13 18 23 28 33 38 43 48 Drain Source Voltage VDS (V) Figure 18 Current Limitation (typical behavior) 6.5.2 Temperature Limitation in the Power DMOS Each channel incorporates both an absolute ( TJ(SC)) and a dynamic (TJ(SW)) temperature sensor. Activation of either sensor will cause an overheated channel to switch OFF to prevent destruction. Any protective switch OFF latches the output until the temperature has reached an acceptable value. Figure 19 gives a sketch of the situation. No retry strategy is implemented such that when the DMOS temperature has cooled down enough, the switch is switched ON again. Only the IN pin signal toggling can re-activate the power strage. (latch behavior). Data Sheet PROFET™+ 24V 24 Rev. 1.1, 2015-03-04 BTT6030-2EKA Protection Functions Figure 19 Overload Protection Note: For better understanding, the time scale is not linear. The real timing of this drawing is application dependant and cannot be described. Data Sheet PROFET™+ 24V 25 Rev. 1.1, 2015-03-04 BTT6030-2EKA Protection Functions 6.6 Electrical Characteristics for the Protection Functions Table 6 Electrical Characteristics: Protection VS = 8 V to 36 V, TJ = -40 °C to +150 °C (unless otherwise specified). Typical values are given at VS = 28 V, TJ = 25 °C Parameter Symbol Values Unit Note / Test Condition Number – mA 1) 2) VS = 48 V See Figure 14 P_6.6.1 700 mV IL = - 4 A TJ = 150 °C P_6.6.2 Min. Typ. Max. – 0.1 200 610 Loss of Ground Output leakage current while IOUT(GND) GND disconnected Reverse Polarity Drain source diode voltage during reverse polarity VDS(REV) See Figure 17 Overvoltage Overvoltage protection VS(AZ) 65 70 75 V ISOV = 5 mA P_6.6.3 See Figure 16 Overload Condition Load current limitation IL5(SC) 56 70 84 A 3) VDS = 5 V See Figure 43 P_6.6.4 Load current limitation IL28(SC) – 35 – A 2) VDS = 42 V See Figure 43 P_6.6.7 TJ(SW) – 80 – K 4) See Figure 19 P_6.6.8 150 170 4) 200 4) °C 5) See Figure 19 P_6.6.10 – 30 – K 5) 4) Dynamic temperature increase while switching Thermal shutdown temperature Thermal shutdown hysteresis 1) 2) 3) 4) 5) TJ(SC) TJ(SC) See Figure 19 P_6.6.11 All pins are disconnected except VS and OUT. Not Subject to production test, specified by design Test at TJ = -40°C only Functional test only Test at TJ = +150°C only Data Sheet PROFET™+ 24V 26 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions 7 Diagnostic Functions For diagnosis purpose, the BTT6030-2EKA provides a combination of digital and analog signals at pin IS. These signals are called SENSE. In case the diagnostic is disabled via DEN, pin IS becomes high impedance. In case DEN is activated, the sense current of the channel X is enabled/disabled via associated pin DSEL. Table 7 gives the truth table. Table 7 Diagnostic Truth Table DEN DSEL 0 don’t care Z 1 0 Sense output 0 IIS(0) 1 1 Sense output 1 IIS(1) 7.1 IS IS Pin The BTT6030-2EKA provides a SENSE current written IIS at pin IS. As long as no “hard” failure mode occurs (short circuit to GND / current limitation / overtemperature / excessive dynamic temperature increase or open load at OFF) a proportional signal to the load current (ratio kILIS = IL / IIS) is provided. The complete IS pin and diagnostic mechanism is described on Figure 20. The accuracy of the SENSE depends on temperature and load current. The IS pin multiplexes the current IIS(0) and IIS(1), via the pin DSEL. Thanks to this multiplexing, the matching between kILISCHANNEL0 and kILISCHANNEL1 is optimized. Due to the ESD protection, in connection to VS, it is not recommended to share the IS pin with other devices if these devices are using another battery feed. The consequence is that the unsupplied device would be fed via the IS pin of the supplied device. Figure 20 Diagnostic Block Diagram Data Sheet PROFET™+ 24V 27 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions 7.2 SENSE Signal in Different Operating Modes Table 8 gives a quick reference for the state of the IS pin during device operation. Table 8 Sense Signal, Function of Operation Mode Operation Mode Input level Channel X DEN1) Normal operation OFF H Output Level Diagnostic Output Z Z Short circuit to GND ~ GND Z Overtemperature Z Z Short circuit to VS VS IIS(FAULT) Open Load < VOL(OFF) > VOL(OFF)2) Z Current limitation < VS Short circuit to GND ~ GND Overtemperature TJ(SW) event Z IIS(FAULT) IIS(FAULT) IIS = IL / kILIS IIS(FAULT) IIS(FAULT) IIS(FAULT) Short circuit to VS VS ~ VS3) ~ VINV ~ VS5) IIS < IL / kILIS IIS < IIS(OL) IIS < IIS(OL)4) IIS(OL) < IIS < IL / kILIS Don’t care Z ~ VINV Inverse current Normal operation ~ VS ON Open Load Inverse current Underload Don’t care 1) 2) 3) 4) 5) Don’t care L The table doesn’t indicate but it is assumed that the appropriate channel is selected via the DSEL pin. With additional pull-up resistor. The output current has to be smaller than IL(OL). After maximum tINV. The output current has to be higher than IL(OL). Data Sheet PROFET™+ 24V 28 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions 7.3 SENSE Signal in the Nominal Current Range Figure 21 show the current sense as a function of the load current in the power DMOS. Usually, a pull-down resistor RIS is connected to the IS pin. This resistor has to be higher than 560 to limit the power losses in the sense circuitry. A typical value is 1.2 k . The blue curve represents the ideal SENSE, assuming an ideal kILIS factor value. The red curves show the accuracy the device provides across full temperature range, at a defined current. 5 4.5 4 3.5 3 2.5 2 1.5 1 0.5 0 min/max Sense Current typical Sense Current 0 1 2 3 4 5 IL [A] 6 7 8 9 10 BTT6030-2EKA Figure 21 Current Sense for Nominal Load 7.3.1 SENSE Signal Variation as a Function of Temperature and Load Current In some applications a better accuracy is required around half the nominal current IL(NOM). To achieve this accuracy requirement, a calibration on the application is possible. To avoid multiple calibration points at different load and temperature conditions, the BTT6030-2EKA allows limited derating of the kILIS value, at nominal load current (IL3; TJ = +25 °C). This derating is described by the parameter kILIS. Figure 22 shows the behavior of the SENSE current, assuming one calibration point at nominal load at +25 °C. The blue line indicates the ideal kILIS ratio. The green lines indicate the derating on the parameter across temperature and voltage, assuming one calibration point at nominal temperature and nominal battery voltage. The red lines indicate the kILIS accuracy without calibration. Data Sheet PROFET™+ 24V 29 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions 4000 calibrated k ILIS min/max k ILIS typical k ILIS 3500 3000 2500 2000 1500 1000 0 1 2 3 4 5 IL [A] 6 Figure 22 Improved SENSE Accuracy with One Calibration Point 7.3.2 SENSE Signal Timing 7 8 9 10 BTT6030-2EKA Figure 23 shows the timing during settling and disabling of the SENSE. L IS Figure 23 SENSE Settling / Disabling Timing Data Sheet PROFET™+ 24V 30 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions 7.3.3 SENSE Signal in Open Load 7.3.3.1 Open Load in ON Diagnostic If the channel is ON, a leakage current can still flow through an open load, for example due to humidity. The parameter IL(OL) gives the threshold of recognition for this leakage current. If the current IL flowing out the power DMOS is below this value, the device recognizes a failure, if the DEN (and DSEL) is selected. In that case, the SENSE current is below IIS(OL). Otherwise, the minimum SENSE current is given above parameter IIS(OL). Figure 24 shows the SENSE current behavior in this area. The red curve shows a typical product curve. The blue curve shows the ideal kILIS ratio. Figure 24 Current Sense Ratio for Low Currents 7.3.3.2 Open Load in OFF Diagnostic For open load diagnosis in OFF-state, an external output pull-up resistor (ROL) is recommended. For the calculation of pull-up resistor value, the leakage currents and the open load threshold voltage VOL(OFF) have to be taken into account. Figure 25 gives a sketch of the situation. Ileakage defines the leakage current in the complete system, including IL(OFF) (see Chapter 5.5) and external leakages, e.g, due to humidity, corrosion, etc.... in the application. To reduce the stand-by current of the system, an open load resistor switch SOL is recommended. If the channel x is OFF, the output is no longer pulled down by the load and VOUT voltage rises to nearly VS. This is recognized by the device as an open load. The voltage threshold is given by VOL(OFF). In that case, the SENSE signal is switched to the IIS(FAULT). An additional RPD resistor can be used to pull VOUT to 0V. Otherwise, the OUT pin is floating. This resistor can be used as well for short circuit to battery detection, see Chapter 7.3.4. Data Sheet PROFET™+ 24V 31 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions FEX 30 30 -7 +2( 4( PIEOEKI Figure 25 Open Load Detection in OFF Electrical Equivalent Circuit 7.3.3.3 Open Load Diagnostic Timing Figure 26 shows the timing during either Open Load in ON or OFF condition when the DEN pin is HIGH. Please note that a delay tsIS(FAULT_OL_OFF) has to be respected after the falling edge of the input, when applying an open load in OFF diagnosis request, otherwise the diagnosis can be wrong. Figure 26 SENSE Signal in Open Load Timing Data Sheet PROFET™+ 24V 32 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions 7.3.4 SENSE Signal with OUT in Short Circuit to VS In case of a short circuit between the OUTput-pin and the VS pin, all or portion (depending on the short circuit impedance) of the load current will flow through the short circuit. As a result, a lower current compared to the normal operation will flow through the DMOS of the BTT6030-2EKA, which can be recognized at the SENSE signal. The open load at OFF detection circuitry can also be used to distinguish a short circuit to VS. In that case, an external resistor to ground RSC_VS is required. Figure 27 gives a sketch of the situation. :FEX :7 -7*%908 &%8 30 GSQT -7 398 303** +2( 6-7 >+2( 67'C:7 7LSVXGMVGYMXXS:WWZK Figure 27 Short Circuit to Battery Detection in OFF Electrical Equivalent Circuit 7.3.5 SENSE Signal in Case of Overload An overload condition is defined by a current flowing out of the DMOS reaching the current limitation and / or the absolute dynamic temperature swing TJ(SW) is reached, and / or the junction temperature reaches the thermal shutdown temperature TJ(SC). Please refer to Chapter 6.5 for details. In that case, the SENSE signal given is by IIS(FAULT) when the diagnostic is selected. The device has a thermal latch behavior, such that when the overtemperature or the exceed dynamic temperature condition has disappeared, the DMOS is reactivated only when the IN is toggled LOW to HIGH. If the DEN pin is activated, and DSEL pin is selected to the correct channel, the SENSE follows the output stage. If no reset of the latch occurs, the device remains in the latching phase and IIS(FAULT) at the IS pin, eventhough the DMOS is OFF. 7.3.6 SENSE Signal in Case of Inverse Current In the case of inverse current, the sense signal of the affected channel will indicate open load in OFF state during OFF state and indicate open load in ON during ON state. The unaffected channel indicates normal behavior as long as the IINV current is not exceeding the maximum value specified in Chapter 5.4. Data Sheet PROFET™+ 24V 33 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions 7.4 Electrical Characteristics Diagnostic Function Table 9 Electrical Characteristics: Diagnostics VS = 8 V to 36 V, TJ = -40 °C to +150 °C (unless otherwise specified). Typical values are given at VS = 28 V, TJ = 25 °C Parameter Symbol Values Min. Typ. Max. Unit Note / Test Condition – 6 V Number Load Condition Threshold for Diagnostic Open load detection threshold in OFF state VS - VOL(OFF) 4 1) VIN = 0 V VDEN = 4.5 V P_7.5.1 See Figure 26 Open load detection threshold in ON state IL(OL) 4 – 25 mA VIN = VDEN = 4.5 V IIS(OL) = 5 A P_7.5.2 See Figure 24 See Figure 46 Sense Pin IS pin leakage current when sense is disabled Sense signal saturation voltage IIS_(DIS) – 0.02 1 µA VS - VIS 1 – 3.5 V (RANGE) 1) VIN = 4.5 V VDEN = 0 V IL = IL4 = 7 A 2) VIN = 0 V VOUT = VS > 10 V VDEN = 4.5 V IIS = 6 mA P_7.5.4 P_7.5.6 See Figure 47 Sense signal maximum current in fault condition IIS(FAULT) 6 15 40 mA VIS = VIN = VDSEL = 0 V P_7.5.7 VOUT = VS > 10 V VDEN = 4.5 V See Figure 20 See Figure 48 Sense pin maximum voltage VIS(AZ) 65 70 75 V IIS = 5 mA P_7.5.3 See Figure 20 Current Sense Ratio Signal in the Nominal Area, Stable Load Current Condition kILIS0 -50% 2450 +50% VIN = 4.5 V VDEN = 4.5 V P_7.5.8 Current sense ratio IL1 = 0.5 A kILIS1 -25% 2360 +25% See Figure 21 TJ = -40 °C; 150 °C P_7.5.9 Current sense ratio IL2 = 2 A kILIS2 -12% 2240 +12% P_7.5.10 Current sense ratio IL3 = 4 A kILIS3 -9% 2240 +9% P_7.5.11 Current sense ratio IL4 = 7 A kILIS4 -8% 2240 +8% P_7.5.12 -5 0 +5 Current sense ratio IL0 = 50 mA kILIS derating with current and kILIS temperature % 2) kILIS3 versus kILIS2 See Figure 22 P_7.5.17 Diagnostic Timing in Normal Condition Data Sheet PROFET™+ 24V 34 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions Table 9 Electrical Characteristics: Diagnostics (cont’d) VS = 8 V to 36 V, TJ = -40 °C to +150 °C (unless otherwise specified). Typical values are given at VS = 28 V, TJ = 25 °C Parameter Symbol Current sense settling time to tsIS(ON) kILIS function stable after positive input slope on both INput and DEN Current sense settling time with load current stable and transition of the DEN tsIS(ON_DEN) Values Min. Typ. Max. Unit Note / Test Condition – – 150 µs 2) VDEN = VIN = 0 to 4.5 V VS = 28 V RIS = 1.2 k CSENSE < 100 pF IL = IL3 = 4 A See Figure 23 P_7.5.18 – – 10 µs 1) P_7.5.19 – – 20 µs 1) VIN = 4.5 V VDEN = 0 to 4.5 V RIS = 1.2 k CSENSE < 100 pF IL = IL3 = 4 A Number See Figure 23 Current sense settling time to tsIS(LC) IIS stable after positive input slope on current load VIN = 4.5 V P_7.5.20 VDEN = 4.5 V RIS = 1.2 k CSENSE < 100 pF IL = IL2 = 2 A to IL = IL3 =4A See Figure 23 Diagnostic Timing in Open Load Condition Current sense settling time to tsIS(FAULT_OL_ – IIS stable for open load OFF) detection in OFF state – 100 µs 1) VIN = 0V VDEN = 0 to 4.5 V RIS = 1.2 k CSENSE < 100 pF VOUT = VS = 28 V P_7.5.22 See Figure 26 Diagnostic Timing in Overload Condition Current sense settling time to tsIS(FAULT) IIS stable for overload detection Current sense over current blanking time tsIS(OC_blank) 2) – – 150 µs VIN = VDEN = 0 to 4.5 V RIS = 1.2 k CSENSE < 100 pF VDS = 24 V See Figure 19 P_7.5.24 – 350 – µs 2) P_7.5.32 VIN = VDEN = 4.5 V RIS = 1.2 k CSENSE < 100 pF VDS = 5 V to 0 V See Figure 19 Data Sheet PROFET™+ 24V 35 Rev. 1.1, 2015-03-04 BTT6030-2EKA Diagnostic Functions Table 9 Electrical Characteristics: Diagnostics (cont’d) VS = 8 V to 36 V, TJ = -40 °C to +150 °C (unless otherwise specified). Typical values are given at VS = 28 V, TJ = 25 °C Parameter Symbol Values Min. Typ. Max. Unit Note / Test Condition Diagnostic disable time DEN transition to IIS < 50% IL /kILIS tsIS(OFF) – – 20 µs 1) Current sense settling time from one channel to another tsIS(ChC) – – 20 µs VIN0 = VIN1 = 4.5 V VDEN = 4.5 V VDSEL = 0 to 4.5 V RIS = 1.2 k CSENSE < 100 pF IL(OUT0) = IL3 = 4 A IL(OUT1) = IL2 = 2 A VIN = 4.5 V VDEN = 4.5 V to 0 V RIS = 1.2 k CSENSE < 100 pF IL = IL3 = 4 A Number P_7.5.25 See Figure 23 P_7.5.26 See Figure 23 1) DSEL pin select channel 0 only. 2) Not subject to production test, specified by design Data Sheet PROFET™+ 24V 36 Rev. 1.1, 2015-03-04 BTT6030-2EKA Input Pins 8 Input Pins 8.1 Input Circuitry The input circuitry is compatible with 3.3 and 5 V microcontrollers. The concept of the input pin is to react to voltage thresholds. An implemented Schmitt trigger avoids any undefined state if the voltage on the input pin is slowly increasing or decreasing. The output is either OFF or ON but cannot be in a linear or undefined state. The input circuitry is compatible with PWM applications. Figure 28 shows the electrical equivalent input circuitry. In case the pin is not needed, it must be left opened, or must be connected to device ground (and not module ground) via a 4.7k input resistor. Figure 28 Input Pin Circuitry 8.2 DEN / DSEL Pin The DEN / DSEL pins enable and disable the diagnostic functionality of the device. The pins have the same structure to INput pins, please refer to Figure 28. 8.3 Input Pin Voltage The IN, DSEL and DEN use a comparator with hysteresis. The switching ON / OFF takes place in a defined region, set by the thresholds VIN(L) Max. and VIN(H) Min. The exact value where the ON and OFF take place are unknown and depends on the process, as well as the temperature. To avoid cross talk and parasitic turn ON and OFF, a hysteresis is implemented. This ensures a certain immunity to noise. Data Sheet PROFET™+ 24V 37 Rev. 1.1, 2015-03-04 BTT6030-2EKA Input Pins 8.4 Electrical Characteristics Table 10 Electrical Characteristics: Input Pins VS = 8 V to 36 V, TJ = -40 °C to +150 °C (unless otherwise specified). Typical values are given at VS = 28 V, TJ = 25 °C Parameter Symbol Values Min. Typ. Max. Unit Note / Test Condition Number INput Pins Characteristics Low level input voltage range VIN(L) -0.3 – 0.8 V See Figure 49 P_8.4.1 High level input voltage range VIN(H) 2 – 6 V See Figure 50 P_8.4.2 P_8.4.3 Input voltage hysteresis Low level input current High level input current VIN(HYS) IIN(L) IIN(H) – 250 – mV 1) 1 10 25 µA 2 10 25 µA VIN = 0.8 V VIN = 5.5 V See Figure 51 P_8.4.4 P_8.4.5 See Figure 52 DEN Pin Low level input voltage range VDEN(L) -0.3 – 0.8 V – P_8.4.6 High level input voltage range VDEN(H) 2 – 6 V – P_8.4.7 P_8.4.8 Input voltage hysteresis Low level input current High level input current VDEN(HYS) IDEN(L) IDEN(H) – 250 – mV 1) 1 10 25 µA 10 25 µA VDEN = 0.8 V VDEN = 5.5 V P_8.4.9 2 P_8.4.10 DSEL Pin Low level input voltage range VDSEL(L) -0.3 – 0.8 V – P_8.4.11 High level input voltage range VDSEL(H) 2 – 6 V – P_8.4.12 P_8.4.13 P_8.4.14 Input voltage hysteresis Low level input current High level input current VDSEL(HYS) IDSEL(L) IDSEL(H) – 250 – mV 1) 1 10 25 µA 2 10 25 µA VDSEL = 0.8 V VDSEL = 5.5 V P_8.4.15 1) Not subject to production test, specified by design Data Sheet PROFET™+ 24V 38 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9 Characterization Results The characterization have been performed on 3 lots, with 3 devices each. Characterization have been performed at 8 V, 28 V and 36 V, from -40°C to 160°C. When no dependency to voltage is seen, only one curve (28 V) is sketched. 9.1 General Product Characteristics 9.1.1 Minimum Functional Supply Voltage P_4.2.3 Figure 29 Minimum Functional Supply Voltage VS(OP)_MIN = f(TJ) 9.1.2 Undervoltage Shutdown P_4.2.4 Figure 30 Undervoltage Threshold VS(UV) = f(TJ) Data Sheet PROFET™+ 24V 39 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.1.3 Current Consumption One Channel active P_4.2.5 Figure 31 Current Consumption for Whole Device with Load. One Channel Active IGND_1 = f(TJ;VS) 9.1.4 Current Consumption Two Channels active P_4.2.6 Figure 32 Current Consumption for Whole Device with Load. Two Channels Active IGND_2 = f(TJ;VS) 9.1.5 Standby Current for Whole Device with Load P_4.2.7, P_4.2.10 Figure 33 Standby Current for Whole Device with Load. IS(OFF) = f(TJ;VS) Data Sheet PROFET™+ 24V 40 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.2 Power Stage 9.2.1 Output Voltage Drop Limitation at Low Load Current P_5.5.4 Figure 34 Output Voltage Drop Limitation at Low Load Current VDS(NL) = f(TJ;VS) ; IL = IL(0) = 50mA 9.2.2 Drain to Source Clamp Voltage P_5.5.5 Figure 35 Drain to Source Clamp Voltage VDS(AZ) = f(TJ) Data Sheet PROFET™+ 24V 41 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.2.3 Slew Rate at Turn ON P_5.5.11 Figure 36 Slew Rate at Turn ON d V/dtON = f(TJ;VS), RL = 12 9.2.4 Slew Rate at Turn OFF P_5.5.12 Figure 37 Slew Rate at Turn OFF - dV/dtOFF = f(TJ;VS), RL = 12 9.2.5 Turn ON P_5.5.14 Figure 38 Turn ON tON = f(TJ;VS), RL = 12 Data Sheet PROFET™+ 24V 42 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.2.6 Turn OFF P_5.5.15 Figure 39 Turn OFF tOFF = f(TJ;VS), RL = 12 9.2.7 Turn ON / OFF matching P_5.5.16 Figure 40 Turn ON / OFF matching tSW = f(TJ;VS), RL = 12 Data Sheet PROFET™+ 24V 43 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.2.8 Switch ON Energy P_5.5.19 Figure 41 Switch ON Energy EON = f(TJ;VS), RL = 12 9.2.9 Switch OFF Energy P_5.5.20 Figure 42 Switch OFF Energy EOFF = f(TJ;VS), RL = 12 Data Sheet PROFET™+ 24V 44 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.3 Protection Functions 9.3.1 Overload Condition in the Low Voltage Area P_6.6.4 .YRGXMSR8IQTIVEXYVI?”'A Figure 43 Overload Condition in the Low Voltage Area IL5(SC) = f(TJ;VS) 9.3.2 Overload Condition in the High Voltage Area P_6.6.7 Figure 44 Overload Condition in the High Voltage Area IL42(SC) = f(TJ;VS) Data Sheet PROFET™+ 24V 45 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.4 Diagnostic Mechanism 9.4.1 Current Sense at no Load Figure 45 Current Sense at no Load IL(OL) = f(TJ;VS), IL = 0 9.4.2 Open Load Detection Threshold in ON State P_7.5.2 Figure 46 Open Load Detection ON State Threshold IL(OL) = f(TJ;VS) Data Sheet PROFET™+ 24V 46 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.4.3 Sense Signal Maximum Voltage P_7.5.3 Figure 47 Sense Signal Maximum Voltage VS - VIS(RANGE) =f(TJ;VS) 9.4.4 Sense Signal maximum Current P_7.5.7 Figure 48 Sense Signal Maximum Current in Fault Condition IIS(FAULT) = f(TJ;VS) Data Sheet PROFET™+ 24V 47 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.5 Input Pins 9.5.1 Input Voltage Threshold ON to OFF P_8.4.1 Figure 49 Input Voltage Threshold VIN(L) = f(TJ;VS) 9.5.2 Input Voltage Threshold OFF to ON P_8.4.2 Figure 50 Input Voltage Threshold VIN(H) = f(TJ;VS) Data Sheet PROFET™+ 24V 48 Rev. 1.1, 2015-03-04 BTT6030-2EKA Characterization Results 9.5.3 Input Voltage Hysteresis P_8.4.3 Figure 51 Input Voltage Hysteresis VIN(HYS) = f(TJ;VS) 9.5.4 Input Current High Level P_8.4.5 Figure 52 Input Current High Level IIN(H) = f(TJ;VS) Data Sheet PROFET™+ 24V 49 Rev. 1.1, 2015-03-04 BTT6030-2EKA Application Information 10 Application Information Note: The following information is given as a hint for the implementation of the device only and shall not be regarded as a description or warranty of a certain functionality, condition or quality of the device. VBAT Voltage Regulator OUT T1 VS GND Z CVS VS VDD I/O DEN RDEN OUT0 OUT3 I/O I/O Micro controller I/O RDSEL COUT DSEL RIN IN0 RIN IN1 OUT4 Bulb OUT1 COUT A/D RSENSE IS Bulb GND GND CSENSE D Figure 53 Application Diagram with BTT6030-2EKA Note: This is a very simplified example of an application circuit. The function must be verified in the real application. Table 11 Bill of Material Reference Value Purpose RIN 10 k Protection of the microcontroller during overvoltage, reverse polarity Guarantee BTT6030-2EKA channels OFF during loss of ground RDEN RDSEL RPD 10 k Protection of the microcontroller during overvoltage, reverse polarity 10 k Protection of the microcontroller during overvoltage, reverse polarity 47 k Polarization of the output for short circuit to VS detection Improve BTT6030-2EKA immunity to electomagnetic noise ROL 1.5 k Ensures polarization of the BTT6030-2EKA output during open load in OFF diagnostic RIS 1.2 k Sense resistor Data Sheet PROFET™+ 24V 50 Rev. 1.1, 2015-03-04 BTT6030-2EKA Application Information Table 11 Bill of Material (cont’d) Reference Value Purpose RSENSE 4.7 k Overvoltage, reverse polarity, loss of ground. Value to be tuned with micro controller specification. CSENSE COUT 100 pF Sense signal filtering. 10nF Protection of the device during ESD and BCI T1 Dual NPN/PNP Switch the battery voltage for open load in OFF diagnostic RGND 27 Protection of the BTT6030-2EKA during overvoltage D BAS21 Protection of the BTT6030-2EKA during reverse polarity Z 58 V Zener diode Protection of the device during overvoltage CVS 100 nF Filtering of voltage spikes at the battery line 10.1 Further Application Information • • • Please contact us to get the pin FMEA Existing App. Notes For further information you may visit http://www.infineon.com/profet Data Sheet PROFET™+ 24V 51 Rev. 1.1, 2015-03-04 BTT6030-2EKA Package Outlines 11 Package Outlines Figure 54 PG-DSO-14-40 EP (Plastic Dual Small Outline Package) (RoHS-Compliant) Green Product (RoHS compliant) To meet the world-wide customer requirements for environmentally friendly products and to be compliant with government regulations the device is available as a green product. Green products are RoHS-Compliant (i.e Pb-free finish on leads and suitable for Pb-free soldering according to IPC/JEDEC J-STD-020). Data Sheet PROFET™+ 24V 52 Rev. 1.1, 2015-03-04 BTT6030-2EKA Revision History 12 Revision History Version Date Changes 1.1 2015-03-04 Chapter 4.1 - Changed test condition of P_4.1.4 and adapted footnote, erased footnote for P_4.1.3 Chapter 4.3 /Table 4 /Footnote 2 - corrected misleading wording in text, P_4.3.2 updated Rthja value Chapter 4.3.2 - changed wording in title of figure 6 Chapter 5.5. - typo in Parameter Name P_5.5.3 Chapter 6.1 - updated text Chapter 6.3 - updated text Chapter 6.4 - corrected typo, changed Rin recommendation to 10k Chapter 6.5.1 - updated figure "Current Limitation (typical behavior)" Chapter 6.5.2 - changed wording in text, updated figure "Overload Protection" Chapter 7 - corrected typo in text Chapter 7.3 - updated Figure "Current Sense for Nominal Load" Chapter 7.3.1 - updated Figure "Improved Current Sense Accuracy with one calibration point" Chapter 7.3.3.3 - corrected wording in text, updated figure "SENSE Signal in Open Load Timing" Chapter 7.3.5 - changed wording in text Chapter 7.4 - P_7.5.9, P_7.5.10, P_7.5.11, P_7.5.12, P_7.5.17 updated Chapter 7.4 - P_7.5.32 - changed Name and Symbol Chapter 8.1 - corrected typo in text Chapter 8.2 - corrected typos in text Chapter 10 - Updated Application Diagram and BOM table Chapter 11 - updated package drawing 1.0 2013-08-07 Creation of the document Data Sheet PROFET™+ 24V 53 Rev. 1.1, 2015-03-04 Edition 2015-03-04 Published by Infineon Technologies AG 81726 Munich, Germany © 2015 Infineon Technologies AG All Rights Reserved. Legal Disclaimer The information given in this document shall in no event be regarded as a guarantee of conditions or characteristics. With respect to any examples or hints given herein, any typical values stated herein and/or any information regarding the application of the device, Infineon Technologies hereby disclaims any and all warranties and liabilities of any kind, including without limitation, warranties of non-infringement of intellectual property rights of any third party. Legal Disclaimer for short-circuit capability Infineon disclaims any warranties and liabilities, whether expressed nor implied, for any short-circuit failures below the threshold limit. Information For further information on technology, delivery terms and conditions and prices, please contact the nearest Infineon Technologies Office (www.infineon.com). Warnings Due to technical requirements, components may contain dangerous substances. For information on the types in question, please contact the nearest Infineon Technologies Office.
