IKW40N65H5

IGBT Highspeed5IGBTinTRENCHSTOPTM5technologycopackedwithRAPID1 fastandsoftantiparalleldiode IKP40N65H5,IKW40N65H5 650VDuoPackIGBTanddiode Highspeedswitchingseriesfifthgeneration Datasheet IndustrialPowerControl IKP40N65H5,IKW40N65H5 Highspeedswitchingseriesfifthgeneration Highspeed5IGBTinTRENCHSTOPTM5technologycopackedwithRAPID1 fastandsoftantiparalleldiode  FeaturesandBenefits: C HighspeedH5technologyoffering •Best-in-Classefficiencyinhardswitchingandresonant topologies •PlugandplayreplacementofpreviousgenerationIGBTs •650Vbreakdownvoltage •LowgatechargeQG •IGBTcopackedwithRAPID1fastandsoftantiparalleldiode •Maximumjunctiontemperature175°C •QualifiedaccordingtoJEDECfortargetapplications •Pb-freeleadplating;RoHScompliant •CompleteproductspectrumandPSpiceModels: http://www.infineon.com/igbt/ G E 1 2 3 Applications: •Solarconverters •Uninterruptiblepowersupplies •Weldingconverters •Midtohighrangeswitchingfrequencyconverters Packagepindefinition: •Pin1-gate •Pin2&backside-collector •Pin3-emitter KeyPerformanceandPackageParameters Type VCE IC VCEsat,Tvj=25°C Tvjmax Marking Package IKP40N65H5 650V 40A 1.65V 175°C K40EH5 PG-TO220-3 IKW40N65H5 650V 40A 1.65V 175°C K40EH5 PG-TO247-3 2 Rev.2.1,2015-05-06 IKP40N65H5,IKW40N65H5 Highspeedswitchingseriesfifthgeneration TableofContents Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Thermal Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Electrical Characteristics Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Package Drawing PG-TO220-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Package Drawing PG-TO247-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Testing Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 3 Rev.2.1,2015-05-06 IKP40N65H5,IKW40N65H5 Highspeedswitchingseriesfifthgeneration MaximumRatings Foroptimumlifetimeandreliability,Infineonrecommendsoperatingconditionsthatdonotexceed80%ofthemaximumratingsstatedinthisdatasheet. Parameter Symbol Value Unit Collector-emittervoltage,Tvj≥25°C VCE 650 V DCcollectorcurrent,limitedbyTvjmax TC=25°C TC=100°C IC 74.0 46.0 A Pulsedcollectorcurrent,tplimitedbyTvjmax ICpuls 120.0 A Turn off safe operating area VCE≤650V,Tvj≤175°C,tp=1µs - 120.0 A Diodeforwardcurrent,limitedbyTvjmax TC=25°C TC=100°C IF 36.0 21.0 A Diodepulsedcurrent,tplimitedbyTvjmax IFpuls 120.0 A Gate-emitter voltage TransientGate-emittervoltage(tp≤10µs,D
