10-01-C84-YSC-AAS2T2DH-AM

EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Lead (Pb) Free Product- RoHS Compliant Feature ‧ ‧ ‧ ‧ ‧ ‧ Piranha package. Colorless clear resin. Low thermal resistance. Packaged in tubes for Automatic Insertion Equipment. Total Flux: 5650 to 11250 mlm at 70mA. Qualification according to AEC-Q101. Applications ‧ Automotive Lighting ‧ Electronic signs and signals ‧ General lighting application ‧ Device Selection Guide Chip Material AlGaInP Emitted Color Yellow Resin Color Water Clear Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 1 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Peak Forward Current (Duty 1/10 @1KHz) Power Dissipation Junction Temperature Operating Temperature Storage Temperature Thermal Resistance Symbol VR IF IFP Pd Tj Topr Tstg Rth J-A ESDHBM ESDMM Tsol Rating 5 70 100 200 115 -40 ~ +100 -40 ~ +100 165 2000 200 Unit V mA mA mW ℃ ℃ ℃ K/W V V ESD (Classification acc. AEC Q101) Soldering Temperature Wave Soldering : 260 ℃ for 5 sec. Hand Soldering : 350 ℃ for 3 sec. Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 2 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Electro-Optical Characteristics (Ta=25℃) Parameter Total Flux Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Reverse Current Symbol Φv 2θ1/2 λp λd ∆λ VF IR Min. 5650 ----589 --1.9 --Typ. --130 594 --15 ----Max. 11250 ----598 --2.9 10 Unit mlm deg nm nm nm V µA Condition IF =70mA IF =70mA IF =70mA IF =70mA IF =70mA IF =70mA VR =5V Note: 1. Tolerance of Total Flux: ±11% 2. Tolerance of Dominant Wavelength: ±1nm 3. Tolerance of Forward Voltage: ±0.1V Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 3 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Bin Range of Total Flux Bin Code S2 T1 T2 Note: Tolerance of Total Flux: ±11% Min. 5650 7150 9000 Max. 7150 9000 11250 mlm IF =70mA Unit Condition Bin Range of Dominant Wavelength Bin Code 2 3 4 Min. 589 592 595 Max. 592 595 598 nm IF =70mA Unit Condition Note: Tolerance of Dominant Wavelength: ±1nm Bin Range of Forward Voltage Bin Code 1 2 3 4 5 Min. 1.9 2.1 2.3 2.5 2.7 Max. 2.1 2.3 2.5 2.7 2.9 V IF =70mA Unit Condition Note: Tolerance of Forward Voltage: ±0.1V Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 4 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Typical Electro-Optical Characteristics Curves Typical Curve of Spectral Distribution 001 001 Relative Intensity(％) W(nm) Note: V(λ)=Standard eye response curve; IF =20mA Diagram Characteristics of Radiation 0 1.0 0 10 0 20 0 Relative Intensity (a.u.) 30 0.8 0.6 0 40 0 50 0 60 0.4 0.2 0 .0 0 -90 0 70 0 80 0 90 -30 -70 -50 -10 View ing angle (degree) 0 0 0 0 0 Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 5 of 12 DPE-0000161 Created by: 007 007 007 007 056 056 056 056 006 006 006 006 055 055 055 055 005 005 005 005 054 054 054 054 004 004 004 004 0 05 EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Forward Current vs. Forward Voltage (Ta=25℃) 100 90 80 70 60 50 40 30 20 10 0 1.7 1.9 2.1 2.3 2.5 2.7 Dominant Wavelength vs. Forward Current (Ta=25℃) 593 Dominant Wavelength (nm) 592 591 590 589 588 587 0 10 20 30 40 50 60 70 80 90 100 Forward Current (mA) Forward Voltage (V) Forward Current (mA) Relative Luminous Intensity vs. Forward Current (Ta=25℃) 1.0 Relative Luminous Intensity Relative Intensity Max. Permissible Forward Current vs. Ambient Temperature 100.0 90.0 80.0 70.0 60.0 50.0 40.0 30.0 20.0 10.0 0.0 0.6 0.4 0.2 0.0 0 10 20 30 40 50 60 70 Forward Current (mA) 0.8 0.0 20.0 40.0 60.0 80.0 100.0 Forward Current (mA) Ambient Temperature ( Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: DPE-0000161 Created by: ℃ ) 6 of 12 EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Package Dimension Note: 1.Tolerances unless mentioned ±0.25mm. Unit = mm 2.An epoxy meniscus may extend about 1.5mm(0.059") down the leads Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 7 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Antistic Packing Materials Tube PART NO: LOT NO: Label area CAT: QTY: Tube Label Explanation ‧ PART NO: Product Number ‧ QTY: Packing Quantity ‧ LOT No: Lot Number ‧ CAT: Rank of (VF)(Note*1)( Note*2) Note1: λd/CIE/Color temperature Note2: Luminous Intensity/ Total Flux Note: Tolerances unless mentioned ±2.0mm. Unit = mm Standard Box Tube Label Explanation ‧ CPN: Customer’s Product Number ‧ P/N: Product Number ‧ QTY: Packing Quantity ‧ CAT: Rank of (VF)(Note*1)( Note*2) Note1: λd/CIE/Color temperature Note2: Luminous Intensity/ Total Flux ‧ HUE/REF: Reference ‧ LOT No: Lot Number Note: Tolerances unless mentioned ±3.0mm. Unit = mm Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 8 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Packing Quantity Packing material Tube height Standard box Large box Length × Width × height (mm) 485 x 9.5 x12 510 x 100 x 45 510 x 150 x 90 Tube Quantity (Pcs) LED Quantity (Pcs) 1 30 105 60 1800 6300 Note: 1. Normal packing specification is use standard box, unless already defined initially. 2. Vacuum packing with anti-static bag after packing in standard box. 3. Specifications are subject to change without prior notice. Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 9 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Notes 1. Lead Forming During lead formation, the leads should be bent at a point at least 3mm from the base of the epoxy bulb. Lead forming should be done before soldering. Avoid stressing the LED package during leads forming. The stress to the base may damage the LED’s characteristics or it may break the LEDs. Cut the LED leadframes at room temperature. Cutting the leadframes at high temperatures may cause failure of the LEDs. When mounting the LEDs onto a PCB, the PCB holes must be aligned exactly with the lead position of the LED. If the LEDs are mounted with stress at the leads, it causes deterioration of the epoxy resin and this will degrade the LEDs. 2. Storage The LEDs should be stored at 30°C or less and 70%RH or less after being shipped from Everlight and the storage life limits are 3 months. If the LEDs are stored for 3 months or more, they can be stored for a year in a sealed container with a nitrogen atmosphere and moisture absorbent material. Please avoid rapid transitions in ambient temperature, especially, in high humidity environments where condensation can occur. 3. Soldering Careful attention should be paid during soldering. Solder the LED no lower than 1.6mm from the base of stopper is recommended. Avoiding applying any stress to the lead frame while the LEDs are at high temperature particularly when soldering. Recommended soldering conditions: Hand Soldering Temp. at tip of iron Soldering time Distance 300 3 sec Max. No lower than 1.6mm from the base of stopper Distance No lower than 1.6mm from the base of stopper DIP Soldering Preheat temp. Bath temp. Bath time. 100 260 Max. 5 sec Max. Max. (30W Max.) Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng DPE-0000161 Created by: ℃ ℃ Max. (60 sec Max.) Page: 10 of 12 EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM Dip and hand soldering should not be done more than one time. After soldering the LEDs, the epoxy bulb should be protected from mechanical shock or vibration until the LEDs return to room temperature. A rapid-rate process is not recommended for cooling the LEDs down from the peak temperature. Although the recommended soldering conditions are specified in the above table, dip or handsoldering at the lowest possible temperature is desirable for the LEDs. Wave soldering parameter must be set and maintain according to recommended temperature and dwell time in the solder wave. 4. Cleaning When necessary, cleaning should occur only with isopropyl alcohol at room temperature for a duration of no more than one minute. Dry at room temperature before use. Do not clean the LEDs by the ultrasonic. When it is absolutely necessary, the influence of ultrasonic cleaning on the LEDs depends on factors such as ultrasonic power and the assembled condition. Ultrasonic cleaning shall be pre-qualified to ensure this will not cause damage to the LED 5. Heat Management Heat management of LEDs must be taken into consideration during the design stage of LED application. The current should be de-rated appropriately by referring to the de-rating curve found in each product specification. The temperature surrounding the LED in the application should be controlled. Please refer to the data sheet de-rating curve. 6. ESD (Electrostatic Discharge) Electrostatic discharge (ESD) or surge current (EOS) can damage LEDs. An ESD wrist strap, ESD shoe strap or antistatic gloves must be worn whenever handling LEDs. All devices, equipment and machinery must be properly grounded. Use ion blower to neutralize the static charge which might have built up on surface of the LEDs plastic lens as a result of friction between LEDs during storage and handing. Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 11 of 12 DPE-0000161 Created by: EVERLIGHT ELECTRONICS CO., LTD. Technical Data Sheet Flat Power LED 10-01-C84-YSC-AAS2T2DH-AM 7. Other Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’s consent. Everlight Electronics Co., Ltd. Device No.: http://www.everlight.com Published date: 31-Aug-2009 Rev.: 1.0 Vicky Feng Page: 12 of 12 DPE-0000161 Created by:
