12-22-R6GHC-A30-2C

EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Right Angle Lens Chip LED with Bi-Color(Multi-Color) 12-22/R6GHC-A30/2C Features ․Package in 8mm tape on 7〞diameter reel. ․Compatible with automatic placement equipment. ․Compatible with infrared and vapor phase reflow solder process. ․Mulit-color type. ․Pb-free. ․The product itself will remain within RoHS compliant version. Descriptions ․ The 12-22 SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained. ․Besides, lightweight makes them ideal for miniature applications. etc. Applications ․Backlighting in dashboard and switch. ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD, switch and symbol. ․General use. Device Selection Guide Chip Type R6 GH Material AlGaInP InGaN Emitted Color Brilliant Red Brilliant Green Resin Color Water Clear Everlight Electronics Co., Ltd. Device No: SZDSE-122-A31 http://www.everlight.com Prepared date: 18-Feb-2008 Rev 1 Page: 1 of 12 Prepared by:Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:09.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Package Outline Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 2 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Peak Forward Current (Duty 1/10 @1KHz) Power Dissipation Electrostatic Discharge(HBM) Operating Temperature Storage Temperature Soldering Temperature Symbol VR IF IFP Pd ESD Topr Tstg Tsol Rating 5 R6:25 GH:25 R6:60 GH:100 R6:60 GH:95 R6:2000 GH:150 -40 ~ +85 -40~ +90 Unit V mA mA mW V ℃ ℃ Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 3 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Peak Wavelength Symbol Iv R6 GH Min. 72.0 112 --------------------- Typ. ------120 632 518 624 525 20 35 2.0 3.3 ----- Max. 180 285 --------------------2.4 3.7 10 50 Unit mcd deg nm Condition 2θ1/2 λp R6 GH Dominant Wavelength λd R6 GH nm IF=20mA Spectrum Radiation Bandwidth △λ R6 GH nm Forward Voltage VF R6 GH 1.7 2.7 ----- V Reverse Current IR R6 GH μA VR=5V Notes: 1.Tolerance of Luminous Intensity ±11% Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 4 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Bin Range Of Luminous Intensity R6 Bin Q R Min 72.0 112 Max 112 180 Unit mcd Condition IF=20mA GH Bin R S Min 112 180 Max 180 285 Unit mcd Condition IF=20mA Notes: 1.Tolerance of Luminous Intensity ±11% Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 5 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Typical Electro-Optical Characteristics Curves R6 Ta=25°C Relative luminous intensity ( % ) I (mA) Ta=25°C Wavelength λ(nm) Forward Current Forward Voltage VF (V) Ta=25°C Relative luminous intensity ( % ) Relative luminous intensity ( %) Ambient Temperature Ta(°C ) Forward Current I (mA) Ta=25°C 0° 10° 20° 30° Forward Current I (mA) 40° 1.0 0.9 0.8 0.7 50° 60° 70° 80° 90° 0.5 0.3 0.1 0.2 0.4 0.6 Ambient Temperature Ta (°C ) Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 6 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Typical Electro-Optical Characteristics Curves GH Ta=25°C Relative luminous intensity ( % ) I (mA) Ta=25°C Wavelength λ(nm) Forward Current Forward Voltage VF (V) Ta=25°C Relative luminous intensity ( % ) Relative luminous intensity ( %) Ambient Temperature Ta(°C ) Forward Current I (mA) Ta=25°C 0° 10° 20° 30° I (mA) Forward Current 40° 1.0 0.9 0.8 0.7 0.5 0.3 0.1 0.2 0.4 0.6 50° 60° 70° 80° 90° Ambient Temperature Ta (°C ) Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 7 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Label explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 8 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Carrier Tape Dimensions: Loaded quantity 2000 PCS per reel Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 9 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 2 Items Reflow Soldering Temperature Cycle Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH Test Sample Hours/Cycles Size 6 Min. 300 Cycles 22 PCS. 22 PCS. Ac/Re 0/1 0/1 3 4 5 6 7 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 0/1 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 10 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C Precautions For Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 11 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 12-22/R6GHC-A30/2C 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. http://www.everlight.com Rev 1 Page: 12 of 12 Revision :1 Device No: SZDSE-122-A31 Release Date:2008-09-20 00:16:09.0 Prepared date: 18-Feb-2008 Prepared by:Yuan Shaoxiang Expired Period: Forever LifecyclePhase:
