Technical Data Sheet 1206 Package Chip LED (0.5mm Height)
15-215/R6C-AM2P1VY/2T
Features
․Package in 8mm tape on 7〞diameter reel. ․Compatible with automatic placement equipment. ․Compatible with infrared and vapor phase reflow solder process. ․Mono-color type. ․Pb-free. ․The product itself will remain within RoHS compliant version.
Descriptions
․The 15-215 SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained. ․Besides, lightweight makes them ideal for miniature applications. etc.
Applications
․Backlighting in dashboard and switch. ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD, switch and symbol. ․General use.
Device Selection Guide
Chip Material 15-215/R6C-AM2P1VY/2T AlGaInP Emitted Color Briliant Red Water Clear
Part No.
Resin Color
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 1 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Package Outline Dimensions
Note: The tolerances unless mentioned is ±0.1mm,Unit = mm
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 2 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Absolute Maximum Ratings (Ta=25℃)
Parameter Reverse Voltage Forward Current Peak Forward Current (Duty 1/10 @1KHz) Power Dissipation Electrostatic Discharge(HBM) Operating Temperature Storage Temperature Soldering Temperature Symbol VR IF IFP Pd ESD Topr Tstg Tsol Rating 5 25 60 60 2000 -40 ~ +85 -40 ~ +90 Unit V Ma mA mW V ℃ ℃
Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec.
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 3 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Electro-Optical Characteristics (Ta=25℃)
Parameter
Luminous Intensity Viewing Angle Peak Wavelength
Dominant Wavelength
Symbol Iv 2θ1/2 λp λd △λ VF IR
Min. 22.5 --------617.5 ----1.7 -----
Typ. ----140 632 ----20 ---------
Max. 57.0 --------633.5 ----2.2 10
Unit mcd deg nm
Condition
IF=5mA nm nm V μA VR=5V
Spectrum Radiation Bandwidth Forward Voltage
Reverse Current
Notes:
1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.05V
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 4 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Bin Range Of Luminous Intensity
Bin M2 N1 N2 P1 Min 22.5 28.5 36.0 45.0 Max 28.5 36.0 45.0 57.0 mcd IF=5mA Unit Condition
Bin Range Of Dom. Wavelength
Group Bin E4 A E5 E6 E7 Min 617.5 621.5 625.5 629.5 Max 621.5 625.5 629.5 633.5 nm IF=5mA Unit Condition
Bin Range Of Forward Voltage
Group Bin 19 20 V 21 22 23 Min 1.7 1.8 1.9 2.0 2.1 Max 1.8 1.9 2.0 2.1 2.2 V IF=5mA Unit Condition
Notes:
1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.05V
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 5 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Typical Electro-Optical Characteristics Curves
Spectrum Distribution Forward Current IF (mA) 100 75 Ta=25°C 50 40 30 25 20 10 0 1.2
Forward Current vs. Forward Voltage
Ta=25°C
Relative luminous intensity (%)
50 25
0 500
550 600 650 Wavelength λ (nm)
700
1.6 2.0 2.4 2.8 3.0 Forward Voltage VF (V) Luminous Intensity vs. Forward Current Ta=25°C
Luminous Intensity vs. Relative luminous intensity (%) 1000 Ambient Temperature Relative luminous intensity (%) 1000
100
100
10
10
1 -60 -40 -20
0
20 40 60 80 100
10 10
10
1
10
2
Ambient Temperature Ta (°C) Forward Current Derating Curve Forward Current IF (mA) 50 40 30 25 20 10 0 0 20 1.0 0.9 0.8 0.7 40 60 85 100
Forward Current IF (mA) Radiation Diagram 0° 10° Ta=25°C 20° 30°
40° 50° 60° 70° 80° 90° 0.5 0.3 0.1 0.2 0.4 0.6
Ambient Temperature Ta (°C)
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 6 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Label Explanation
CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank
XXXXXXXXXXXXX QTY : XXX CAT : XXX HUE : XXX REF : XXX
Pb
EVERLIGHT
RoHS
CPN : P N : XXXXXXXXXXXXX
LOT NO : XXXXXXXXXX
Reference : XXXXXXXX
MADE IN TAIWAN
Reel Dimensions
Note: The tolerances unless mentioned is ±0.1mm , Unit = mm
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 7 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Carrier Tape Dimensions: Loaded quantity 2000 PCS per reel
Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm
Moisture Resistant Packaging
Label
Aluminum moisture-proof bag
Desiccant
Label
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 8 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Reliability Test Items And Conditions
The reliability of products shall be satisfied with items listed below. Confidence level:90% LTPD:10%
No. 1
Items Reflow Soldering
Test Condition Temp. : 260℃±5℃ Max. 10sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH
Test Sample Hours/Cycles Size 6 Min. 300 Cycles 22 PCS.
Ac/Re 0/1
2
Temperature Cycle
22 PCS.
0/1
3
Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity
300 Cycles
22 PCS.
0/1
4 5 6 7
1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs.
22 PCS. 22 PCS. 22 PCS. 22 PCS.
0/1 0/1 0/1 0/1
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 9 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
Precautions For Use
1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile
3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board.
Everlight Electronics Co., Ltd. Device No:DSE-0001299
http://www.everlight.com Prepared date: 24-Jun-2009
Rev 2
Page: 10 of 11
Prepared by: Ashley Kuo
Revision
:2
Release Date:2009-06-26 19:32:49.0 Expired Period: Forever
LifecyclePhase:
15-215/R6C-AM2P1VY/2T
4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing.
EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C
Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com
