EVERLIGHT ELECTRONICS CO., LTD.
Technical Data Sheet 0805 Package Chip LED (1.1mm Height)
17-21/R6C-AP1Q2L/3T
Features
․Package in 8mm tape on 7〞diameter reel. ․Compatible with automatic placement equipment. ․Compatible with infrared and vapor phase reflow solder process. ․Mono-color type. ․Pb-free ․Rohs refer to SMD B Type SGS report
Descriptions
․The 17-21 SMD Taping is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained. ․Besides, lightweight makes them ideal for miniature applications, etc.
Applications
․Automotive: backlighting in dashboard and switch. ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD, switch and symbol. ․General use.
Device Selection Guide
Chip Material AlGaInP Emitted Color Brilliant Red
PART No. 17-21/R6C-AP1Q2L/3T
Lens Color Water Clear
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 1 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Package Outline Dimensions
-
+
Note: The tolerances unless mentioned are ±0.1, unit = mm.
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 2 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Absolute Maximum Ratings (Ta=25℃)
Parameter Reverse Voltage Forward Current Operating Temperature Storage Temperature Electrostatic Discharge Power Dissipation Peak Forward Current (Duty 1/10 @1KHz) Soldering Temperature Symbol VR IF Topr Tstg ESD Pd IFP Rating 5 25 -40 ~ +85 -40 ~ +90 2000 60 60 Unit V mA ℃ ℃ V mW mA
Reflow Soldering : 260 ℃ for 10 sec. Tsol Hand Soldering : 350 ℃ for 3 sec.
Electro-Optical Characteristics (Ta=25℃) Parameter
Luminous Intensity Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Viewing Angle Forward Voltage Reverse Current
Symbol
IV λp λd △λ 2θ1/2 VF IR
Min.
45.0 ---617.5 ------1.70 ----
Typ.
----632 ----20 120 -------
Max.
112.0 ---633.5 ------2.30 10
Unit
mcd nm nm
Condition
IF=20mA nm deg V μA VR=5V
Notes:
1.Tolerance of Luminous Intensity ±10% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.05V
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06 http://www.everlight.com Prepared date: 23-May-2005 Rev.: 1 Page: 3 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Bin Range Of Dom. Wavelength
Group Bin E4 A E5 E6 E7 Min 617.5 621.5 625.5 629.5 Max 621.5 625.5 629.5 633.5 nm IF=20mA Unit Condition
Bin Range Of Luminous Intensity
Bin P1 P2 Q1 Q2 Min 45.0 57.0 72.0 90.0 Max 57.0 72.0 90.0 112 mcd IF=20mA Unit Condition
Bin Range Of Forward Voltage
Groups Bin 19 20 L 21 22 23 24 Min 1.70 1.80 1.90 2.00 2.10 2.20 Max 1.80 1.90 2.00 2.10 2.20 2.30 V IF=20mA Unit Condition
Notes:
1.Tolerance of Luminous Intensity ±10% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.05V
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 4 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Typical Electro-Optical Characteristics Curves
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 5 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Label explanation
CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank
Reel Dimensions
Note: The tolerances unless mentioned are ±0.1, unit = mm.
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 6 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Carrier Tape Dimensions: Loaded quantity 3000 PCS per reel
Note: The tolerances unless mentioned are ±0.1, unit = mm.
Moisture Resistant Packaging
Label
Aluminum moisture-proof bag
Desiccant
Label
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 7 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Reliability Test Items And Conditions
The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10%
No. 1
Items Reflow Soldering
Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH
Test Sample Hours/Cycles Size 6 Min. 300 Cycles 22 PCS.
Ac/Re 0/1
2
Temperature Cycle
22 PCS.
0/1
3
Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity
300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs.
22 PCS.
0/1
4 5 6 7
22 PCS. 22 PCS. 22 PCS. 22 PCS.
0/1 0/1 0/1 0/1
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 8 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
Precautions For Use 1. Over-current-proof Customer must apply resistors for protection , otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package, the LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 The LEDs should be used within a year. 2.4 After opening the package, the LEDs should be kept at 30℃ or less and 70%RH or less. 2.5 The LEDs should be used within 168 hours (7 days) after opening the package. 2.6 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile
3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board.
Everlight Electronics Co., Ltd. Device No: SZDSE-171-R06
http://www.everlight.com Prepared date: 23-May-2005
Rev.: 1
Page: 9 of 10
Prepared by: Hao Liu
EVERLIGHT ELECTRONICS CO., LTD.
17-21/R6C-AP1Q2L/3T
4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing.
EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C
Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com
