EVERLIGHT ELECTRONICS CO.,LTD. DATA SHEET PART NO. DATE ： ： A804B/4G 2005/8/26 CHR&D1 DEPARTMENT ： . REVISION ： 2 RECEIVED ■ MASS PRODUCTION □ PRELIMINARY □ CUSTOMER DESIGN DEVICE NUMBER : PAGE : 6 CUSTOMER DESIGNER CDAE-080-005 CHECKER APPROVER REV. DESCRIPTION RELEASE DATE OFFICE: 7C BUILDING, LIAN HUA PORT INDUSTRIAL DISTRICT, LIAN HUA SHAN BONDED PRICESSING ZONE PAN YU, GUANG ZHU, CHINA TEL. : (020)84860913,84860914 FAX : (020)84860600 http : //www.everlight.com EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet 3.0mm Round Type LED Lamps A804B/4G █ Features : ● ● ● Low power consumption High efficiency and low cost Good control and free combinations on the colors of LED lamps 10 6.3 ● ● ● ● ● ● ● Good lock and easy to assembly Stackable and easy to assembly Stackable vertically and easy to assembly Versatile mounting on P.C board or panel Stackable horizontally and easy to assembly Pb free The product itself will remain within RoHS compliant version. █ Descriptions : ● ● ARRAY=Plastic Holder+Combinations of Lamps The array will easily mount the applicable lamps on any panel up to █ Applications : ● 1.Used as indicators of indicating the Degree, Functions, Positions etc, in electronic instruments. PART NO. 204-10GD Chip Material GaP Emitted Color Green Lens Color Green Diffused EVERLIGHT ELECTRONICS CO.,LTD. Device Number : CDAE-080-005 http : //www.everlight.com Prepared da 2005/8/26 REV.: 2 Page: 1 of 6 Prepared by: Lian Xiang You EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet 3.0mm Round Type LED Lamps A804B/4G Package Dimensions 10 6.3 Notes: 1.All dimensions are in millimeters, tolerance is 0.25mm except being specified 2.Lead spacing is measured where the lead emerge from the package █ Absolute Maximum Ratings at Ta = 25℃ Parameter Forward Current Operating Temperature Storage Temperature Soldering Temperature Power Dissipation Peak Forward Current Reverse Voltage Symbol IF Topr Tstg Tsol Pd IF(Peak) VR Rating 30 -40 to +85 -40 to +100 260 ± 5 100 160 5 Unit mA ℃ ℃ ℃ mW mA V Note: *1:I FP Conditions --Pulse Width ≦ 1msec and Duty ≦ 1/10. *2:Soldering time ≦ 5 seconds. EVERLIGHT ELECTRONICS CO.,LTD. Device Number : CDAE-080-005 http : //www.everlight.com Prepared date: 2005/8/26 REV.: 2 Page: 2 0f 6 Prepared by: Lian Xiang You EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet 3.0mm Round Type LED Lamps A804B/4G Electro-Optical Characteristics (Ta=25 ℃) Parameter Forward Voltage Reverse Current Luminous Intensity Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Symbol VF IR Iv 2θ1/2 λp λd △λ Condition IF= VR= IF= IF= IF= IF= IF= 20 5 10 20 20 20 20 mA V mA mA mA mA mA Min. 1.7 ／ 4.0 ／ ／ ／ ／ Typ. 2.1 ／ 6 60 565 570 30 Max. 2.4 10 ／ ／ ／ ／ ／ Unit V μA mcd deg nm nm nm EVERLIGHT ELECTRONICS CO.,LTD. Device Number : CDAE-080-005 http : //www.everlight.com Prepared date: 2005/8/26 REV.: Prepared by: 2 Page: 3 of 6 Lian Xiang You EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet 3.0mm Round Type LED Lamps A804B/4G Typical Electro-Optical Characteristic Curves: █ 10 6.3 EVERLIGHT ELECTRONICS CO.,LTD. Device Number : CDAE-080-005 http : //www.everlight.com Prepared date: 2005/8/26 REV.: 2 Page: 4 of 6 Prepared by: Lian Xiang You EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet 3.0mm Round Type LED Lamps A804B/4G █ Reliability test items and conditions: Test Sample Ac/Re Hours/Cycle Size SEC 76 PCS 0/1 NO 1 Item Solder Heat Test Conditions TEMP : 260℃ ± 5 ℃ H : +100℃ 15min 10 L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min TEMP : 100℃ 2 Temperature Cycle 300 CYCLES 76 PCS 0/1 3 Thermal Shock 300 CYCLES 76 PCS 0/1 4 High Temperature Storage 1000 HRS 76 PCS 0/1 5 Low Temperature Storage TEMP : -40℃ TEMP : 25℃ IF = 20mA 85℃ / 85% RH 1000 HRS 76 PCS 0/1 6 7 DC Operating Life High Temperature / High Humidity 1000 HRS 1000 HRS 76 PCS 76 PCS 0/1 0/1 EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com Prepared date: 2005/8/26 REV.: 2 Prepared by: Page: 5 of 6 Lian Xiang You Device Number : CDAE-080-005 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet 3.0mm Round Type LED Lamps A804B/4G Packing Quantity Specification 1.30PCS/1Plate，4Plates/1Box 2. 10Boxes/1Carton Label Form Specification CPN: Customer＇s Production Number 10 RoHS P/N : Production Num QTY: Packing Quantity CAT: Ranks HUE: Peak Wavelength REF: Reference LOT No: Lot Number 6.3 A804B/4G MADE IN TAIWAN: Production Place Notes 1. Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. 2. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. 3. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don＇t reproduce or cause anyone to reproduce them without EVERLIGHT ＇sconsent. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: (886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http:\\www.everlight.com EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com Prepared date: 2005/8/26 REV.: Prepared by: 2 Page: 6 0f 6 Lian Xiang You Device Number : CDAE-080-005
