22-23C-R6GHBHW-C01-2C

Technical Data Sheet Full Color Chip LED (Chip LED with Right Angle Lens) 22-23C/R6GHBHW-C01/2C Features ․Package in 8mm tape on 7〞diameter reel. ․Compatible with automatic placement equipment. ․Compatible with infrared and vapor phase reflow solder process. ․Full-color type. ․Pb-free. ․Halogen-free. ․Component surface is Tin plating. ․The product itself will remain within RoHS compliant version. Descriptions ․The 22-23C SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained. ․Besides, lightweight makes them ideal for miniature applications. etc. Applications ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD, switch and symbol. ․General use. Device Selection Guide Chip Type R6 GH BH Material AlGaInP InGaN InGaN Emitted Color Brilliant Red Brilliant Green Blue White Diffused Resin Color Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 1 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Package Outline Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 2 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Symbol VR IF Rating 5 R6:25 GH:30 BH:30 Peak Forward Current (Duty 1/20 @Pulse 1ms) R6:60 IFP GH:100 BH:100 R6:60 Power Dissipation Pd GH:95 BH:95 R6:2000 Electrostatic Discharge Operating Temperature Storage Temperature Soldering Temperature ESD Topr Tstg Tsol GH:150 BH:150 -40 ~ +85 -40 ~ +100 ℃ ℃ V mW mA mA Unit V Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering(30W) : 350 ℃ for 5 sec. Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 3 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Electro-Optical Characteristics (Ta=25℃) Parameter Symbol R6 GH BH 2θ1/2 R6 GH BH R6 GH BH R6 GH BH R6 GH BH R6 GH BH Notes: 1.Tolerance of Luminous Intensity ±11% 2. Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.1V Min. 14.5 35.0 10.0 ----130 626 ----613.0 523.0 466.5 518 468 619.0 531.5 472.5 20 35 25 1.85 2.90 2.90 ----625.0 540.0 478.5 nm IF=5mA nm IF=5mA ----nm IF=5mA ----Typ. Max. 36.0 110 24.5 ----deg IF=5mA mcd IF=5mA Unit Condition Luminous Intensity Iv Viewing Angle Peak Wavelength λp Dominant Wavelength λd Spectrum Radiation Bandwidth △λ ----1.70 2.70 2.70 ----- ----2.00 3.20 3.10 10 50 50 Forward Voltage VF V IF=5mA Reverse Current IR μA VR=5V Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 4 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C R6 Bin Range Of Luminous Intensity Bin 1 2 Min 14.5 22.5 Max 22.5 36.0 Unit mcd Condition IF=5mA GH Bin Range Of Luminous Intensity Bin A B C Min 35.0 55.0 80.0 Max 55.0 80.0 110 mcd IF=5mA Unit Condition Bin Range Of Dom. Wavelength Bin 1 2 Min 523.0 531.5 Max 531.5 540.0 Unit nm Condition IF=5mA BH Bin Range Of Luminous Intensity Bin 1 2 Min 10.0 17.5 Max 17.5 24.5 Unit mcd Condition IF=5mA Note: Tolerance of Luminous Intensity ±11% Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 5 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Typical Electro-Optical Characteristics Curves R6 Spectrum Distribution Relative luminous intensity (%) Forward Current IF (mA) 100 75 Ta=25°C 50 40 30 25 20 10 0 1.2 1.6 2.0 2.4 2.8 3.0 Forward Voltage VF (V) Luminous Intensity vs. Forward Current Relative luminous intensity (%) 1000 Ta=25°C Forward Current vs. Forward Voltage Ta=25°C 50 25 0 500 550 600 650 Wavelength λ (nm) 700 Luminous Intensity vs. Relative luminous intensity (%) 1000 Ambient Temperature 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 10 10 10 1 10 2 Ambient Temperature Ta (°C) Forward Current Derating Curve Forward Current IF (mA) Forward Current IF (mA) Radiation Diagram 0° 10° Ta=25°C 20° 30° 50 40 30 25 20 10 0 0 20 40 60 85 100 1.0 0.9 0.8 0.7 0.5 0.3 0.1 0.2 40° 50° 60° 70° 80° 90° 0.4 0.6 Ambient Temperature Ta (°C) Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 6 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Typical Electro-Optical Characteristics Curves GH Spectrum Distribution Ta=25°C Relative luminous intensity (%) 100 I (mA) 75 50 25 50 40 30 25 20 10 0 2.6 3.0 3.4 3.8 4.2 4.5 Forward Current vs. Forward Voltage Ta=25°C 0 400 450 500 550 600 Forward Current F Wavelength λ (nm) Luminous Intensity vs. Relative luminous intensity (%) Relative luminous intensity (%) 1000 Ambient Temperature 1000 Forward Voltage VF (V) Luminous Intensity vs Forward Current Ta=25°C f=1KHz Duty=1/10 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 1 10 10 10 Ambient Temperature Ta (°C) Forward Current Derating Curve 50 IF(mA) 40 30 25 20 10 0.7 0 0 20 40 60 85 100 0.5 1.0 0.9 0.8 Forward Current IF(mA) Radiation Diagram 0° Ta=25°C 20° 30° 10° Forward Current 40° 50° 60° 70° 80° 90° 0.3 0.1 0.2 0.4 0.6 Ambient Temperature Ta (°C) Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 7 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Typical Electro-Optical Characteristics Curves BH Spectrum Distribution Forward Current IF (mA) 100 75 Ta=25°C Forward Current vs. Forward Voltage Relative luminous intensity (%) 50 40 30 25 20 10 0 2.6 3.0 3.4 3.8 Ta=25°C 50 25 0 400 450 500 550 600 4.2 4.5 Wavelength λ (nm) Luminous Intensity vs. Relative luminous intensity (%) 1000 Ambient Temperature Relative luminous intensity (%) 1000 Forward Voltage VF (V) Luminous Intensity vs. Forward Current f=1KHz Duty=1/10 Ta=25°C 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 1 10 10 1 10 2 Ambient Temperature Ta (°C) Forward Current Derating Curve Forward Current IF (mA) Forward Current IF (mA) Radiation Diagram 0° 10° Ta=25°C 20° 30° 50 40 30 25 20 10 0 0 20 40 60 85 100 1.0 0.9 0.8 0.7 40° 50° 60° 70° 80° 90° 0.5 0.3 0.1 0.2 0.4 0.6 Ambient Temperature Ta (°C) Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 8 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Label Explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Pb EVERLIGHT RoHS CAT : XXX HUE : XXX REF : XXX CPN : P N : XXXXXXXXXXXXX XXXXXXXXXXXXX QTY : XXX LOT NO : XXXXXXXXXX Reference : XXXXXXXX MADE IN TAIWAN Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm , Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 9 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Carrier Tape Dimensions: Loaded quantity 3000 PCS per reel Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 10 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 2 Items Reflow Soldering Temperature Cycle Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH Test Sample Hours/Cycles Size 6 Min. 300 Cycles 22 PCS. 22 PCS. Ac/Re 0/1 0/1 3 4 5 6 7 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 0/1 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 11 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C Precautions For Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 12 of 13 Prepared by: Esther Yan 22-23C/R6GHBHW-C01/2C 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-0001583 http://www.everlight.com Prepared date: 20-May-2009 Rev. 1 Page: 13 of 13 Prepared by: Esther Yan
