23-21B-T1D-CP2Q2TY-2A

EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Reverse Package Chip LED 23-21B/T1D-CP2Q2TY/2A Features ․Package in 8mm tape on 7〞diameter reel. ․Compatible with automatic placement equipment. ․Compatible with infrared and vapor phase reflow solder process. ․Mono-color type. ․Pb-free. ․The product itself will remain within RoHS compliant version. Descriptions ․The 23-21B SMD LED is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained. ․Besides, lightweight makes them ideal for miniature applications. etc. Applications ․Backlighting in dashboard and switch. ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD, switch and symbol. ․General use. Device Selection Guide Part No. 23-21B/T1D-CP2Q2TY/2A Chip Material InGaN Emitted Color Pure White Resin Color Yellow Diffused Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 1 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Package Outline Dimensions Note: The tolerances unless mentioned is ±0.1mm,Unit = mm Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 2 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Peak Forward Current (Duty 1/10 @1KHz) Power Dissipation Electrostatic Discharge(HBM) Operating Temperature Storage Temperature Soldering Temperature Symbol VR IF IFP Pd ESD Topr Tstg Tsol Rating 5 25 100 110 150 -40 ~ +85 -40 ~ +90 Unit V mA mA mW V ℃ ℃ Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Forward Voltage Symbol Iv 2θ1/2 VF IR Min. 57.0 ----2.60 ----- Typ. ----140 --------- Max. 112 ----3.00 50 Unit mcd deg V μA Condition IF=5mA Reverse Current VR=5V Notes: 1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Forward Voltage ±0.05V Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 3 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Bin Range Of Luminous Intensity Bin P2 Q1 Q2 Min. 57.0 72.0 90.0 Max. 72.0 90.0 112 mcd IF=5mA Unit Condition Bin Range Of Forward Voltage Symbol Bin 28 T 29 30 31 Min. 2.60 2.70 2.80 2.90 Max. 2.70 2.80 2.90 3.00 V IF=5mA Unit Condition Notes: 1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Forward Voltage ±0.05V Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 4 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Chromaticity Coordinates Specifications for Bin Grading Groups Bin Code CIE_x 0.274 0.274 0.294 0.294 0.274 0.274 0.294 0.294 0.294 0.294 0.314 0.314 0.294 0.294 0.314 0.314 CIE_y 0.226 0.258 0.286 0.254 0.258 0.291 0.319 0.286 0.254 0.286 0.315 0.282 0.286 0.319 0.347 0.315 Condition 1 2 C IF=5mA 3 4 Notes: 1.The C.I.E. 1931 chromaticity diagram ( Tolerance ±0.01). 2.The products are sensitive to static electricity and care must be fully taken when handling products. Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 5 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A CIE Chromaticity Diagram Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 6 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Typical Electro-Optical Characteristics Curves Spectrum Distribution Ta=25°C Relative luminous intensity (%) 100 IF (mA) 75 50 25 50 40 30 25 20 10 0 2.6 2.8 3.4 3.8 4.2 4.5 Forward Current vs. Forward Voltage Ta=25°C 0 400 500 600 700 800 Wavelength λ (nm) Forward Current Forward Voltage (VF )-volts Luminous Intensity vs Forward Current Relative luminous intensity (%) 1000 Ta=25°C Luminous Intensity vs. Relative luminous intensity (%) 1000 Ambient Temperature f=1KHz Duty=1/10 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 10 10 10 1 10 2 Ambient Temperature Ta (°C) Forward Current I F(mA) Radiation Diagram 0° Ta=25°C 10° 20° 30° Forward Current Derating Curve 50 Forward Current I (mA) F 40 30 25 20 10 0 0 20 1.0 0.9 0.8 0.7 40 60 85 100 40° 50° 60° 70° 80° 90° 0.5 0.3 0.1 0.2 0.4 0.6 Ambient Temperature Ta (°C) Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 7 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Label explanation CAT: Luminous Intensity Rank HUE: Chromaticity Coordinates REF: Forward Voltage Rank RoHS Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 8 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Carrier Tape Dimensions : Loaded quantity 2000 pcs per reel Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 9 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 Items Reflow Soldering Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH Test Sample Hours/Cycles Size 6 Min. 300 Cycles 22 PCS. Ac/Re 0/1 2 Temperature Cycle 22 PCS. 0/1 3 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 22 PCS. 0/1 4 5 6 7 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 10 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A Precautions For Use 1. Over-current-proof Customer must apply resistors for protection , otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package, the LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 11 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 23-21B/T1D-CP2Q2TY/2A 4. Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No.:SZDSE-23B-T07 http://www.everlight.com Prepared date:16 -Sep-2007 Rev. 1 Page: 12 of 12 Prepared by: Yuan Shaoxiang Revision :1 Release Date:2008-09-20 00:16:11.0 Expired Period: Forever LifecyclePhase:
