32-01-Y5C-AQSC-AM

Technical Data Sheet Flat POWER LED 32-01/Y5C-AQSC/AM Features . High Flux Output. . Designed for High Current Operation. . Low Thermal Resistance. . Low Profile. . Packaged in Tubes for Use with Automatic . Insertion Equipment. . The product itself will remain within RoHS compliant version. Descriptions This revolutionary package design allows the light designer to reduce the number of LEDs required and provide a more uniform and unique illuminated appearance than with other LED solutions. This is possible through the efficient optical package design and high-current capabilities. The low profile package can be easily coupled with reflectors or lenses to efficiently distribute light and provide the desired light appearance. Applications . Automotive Lighting . Electronic Signs and Signals . Channel Letter . Special Lighting application Device Selection Guide Chip Emitted Color Yellow Lens Color Water Clear PART NO. 32-01/Y5C-AQSC/AM Material AlGaInP Everlight Electronics Co., Ltd. Device number: DLE-302-030 http:\\www.everlight.com Established date: 04-30-2007 Rev. 1 Page: 1 of 6 Established by: Jim Lin Technical Data Sheet Flat POWER LED 32-01/Y5C-AQSC/AM Package Dimensions Notes: 1.All dimensions are in millimeters 2.An epoxy meniscus may extend about 1.5mm(0.059") down the leads 3.Tolerances unless dimensions ±0.25mm Absolute Maximum Ratings (Ta=25℃) Parameter Continuous Forward Current Peak Forward Current(Duty 1/10 @ 1KHZ) Operating Temperature Storage Temperature Soldering Temperature(T=5 sec) LED Junction Temperature Power Dissipation Electrostatic Discharge Reverse Voltage Symbol IF IFP Topr Tstg Tsol Tj Pd ESD VR Rating 70 160 -40 ~ +100 -40 ~ +100 260 ± 5 125 220 2000 5 Units mA mA ℃ ℃ ℃ ℃ mW V V Everlight Electronics Co., Ltd. Device number: DLE-302-030 http:\\www.everlight.com Established date: 04-30-2007 Rev. 1 Page: 2 of 6 Established by: Jim Lin Technical Data Sheet Flat POWER LED 32-01/Y5C-AQSC/AM Electro-Optical Characteristics (Ta=25℃) Parameter Total Flux Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Reverse Current Symbol Φv 2θ1/2 λp λd △λ VF IR Min. 4500 ------586 ---2.1 ---Typ. 5400 135 594 592 15 2.6 ---Max. 7150 ------598 ---3.1 10 Condition IF=70mA IF=70mA IF=70mA IF=70mA IF=70mA IF=70mA VR=5V Unit mlm deg nm nm nm V µA Rank 32-01/Y5C-AQSC/AM (1) VF(V) Bin 3 4 5 6 7 Min 2.10 2.30 2.50 2.70 2.90 Max 2.30 2.50 2.70 2.90 3.10 (1) (2) (2) λd(nm) (3) (3)Φv(mlm) Max 590 594 598 Bin Q R S Min 3600 4500 5650 Max 4500 5650 7150 Bin 1 2 3 Min 586 590 594 *Measurement Uncertainty of Forward Voltage：±0.1V *Measurement Uncertainty of Luminous Intensity: ±15% *Measurement Uncertainty of Dominant Wavelength ±1.0nm Everlight Electronics Co., Ltd. Device number: DLE-302-030 http:\\www.everlight.com Established date: 04-30-2007 Rev. 1 Page: 3 of 6 Established by: Jim Lin Technical Data Sheet Flat POWER LED 32-01/Y5C-AQSC/AM Typical Electro-Optical Characteristics Curves Relative Intensity vs. Wavelength 1.00 80 Forward Current vs. Forward Voltage RELATIVE INTENSITY FORWARD CURRENT (mA) 60 0.50 40 20 0.00 540 560 580 600 620 WAVELENGTH (nm) 640 0 1.40 1.60 1.80 2.00 2.20 2.40 2.60 2.80 3.00 3.20 FORWARD VOLTAGE (V) Relative Intensity vs. Forward Current 1.00 Forward Current vs. Ambient Temp. 80 70 MAXMUM DC CURRENT(mA) 0.80 RELATIVE INTENSITY 60 50 40 30 20 10 0 0 20 40 60 80 100 120 140 AMBIENT TEMPERATURE (C) 0.60 0.40 0.20 0.00 0 10 20 30 40 50 60 FORWARD CURRENT (mA) 70 Relative Intensity vs. Angle Displacement 0 1.0 0 10 0 20 0 Relative Intensity (a.u.) 30 0.8 0.6 0 40 0 50 0 60 0.4 0.2 0.0 0 0 0 0 -90 -70 -30 -100 -50 Viewing angle (degree) 0 70 0 80 0 90 0 Everlight Electronics Co., Ltd. Device number: DLE-302-030 http:\\www.everlight.com Established date: 04-30-2007 Rev. 1 Page: 4 of 6 Established by: Jim Lin Technical Data Sheet Flat POWER LED 32-01/Y5C-AQSC/AM Packing Quantity Specification (1) 60 pcs/1 tube, 30 tubes/1 small inside box, 12 small inside boxes/1 outside box (2) 60 pcs/1 tube, 105 tubes/1 big inside box, 4 big inside boxes/1 outside box Label Form Specification (1)Tube Label Form PART NO: 32-01/Y5C-AQSC/AM LOT NO: QTY: 60 CAT: (2)Box Label Form EVERLIGHT CPN: P/N: RoHS 32-01/Y5C-AQSC/AM QTY： LOT NO： MADE IN TAIWAN CAT: HUE: REF: PART NO: Everlgiht’s Production Number QTY: Packing Quantity LOT NO: Lot Number CAT: Ranks of Forward Voltage, Dominant Wavelength and Total Flux CPN: Customer’s Production Number P/N : Production Number HUE: Reference REF: Reference MADE IN TAIWAN: Production Place Everlight Electronics Co., Ltd. Device number: DLE-302-030 http:\\www.everlight.com Established date: 04-30-2007 Rev. 1 Page: 5 of 6 Established by: Jim Lin Technical Data Sheet Flat POWER LED 32-01/Y5C-AQSC/AM Notes 1. Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. 2. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. 3. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’s consent. 4. Soldering Condition Careful attention should be paid during soldering. When soldering, leave more then 3mm from solder joint to case, and soldering beyond the base of the tie bar is recommended. Avoiding applying any stress to the lead frame while the LEDs are at high temperature particularly when soldering. Recommended soldering conditions: Hand Soldering 400℃ Max. Temp. at tip of iron (30W Max.) Soldering time 3 sec Max. 3mm Min. Distance (From solder joint to case) DIP Soldering 100℃ Max. Preheat temp. (60 sec Max.) Bath temp. 265 Max. Bath time. Distance 5 sec Max. 3mm Min. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C. Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http:\\www.everlight.com Everlight Electronics Co., Ltd. Device number: DLE-302-030 http:\\www.everlight.com Established date: 04-30-2007 Rev. 1 Page: 6 of 6 Established by: Jim Lin
