33-01-T4C-4PRB

Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB Features . High Flux Output. . Low Profile. . Low Thermal Resistance. . Low Power Consumption . The phosphor filled in the reflector converts the blue emission of GaN chip to ideal white. .Typical chromaticity coordinates x=0.30, y=0.29 according to CIE1931 .The product itself will remain within RoHS compliant version. . ESD-withstand voltage: up to 4KV Descriptions This revolutionary package design allows the light designer to reduce the number of LEDs required and provide a more uniform and unique illuminated appearance than with other LED solutions. This is possible through the efficient optical package design and high-current capabilities. The low profile package can be easily coupled with reflectors or lenses to efficiently distribute light and provide the desired light appearance. Applications . Automotive Lighting . Electronic Signs and Signals . Special Lighting application Device Selection Guide PART NO. 33-01/T4C-4PRB Chip Material InGaN Emitted Color White Lens Color Water Clear Everlight Electronics Co., Ltd. Device Number :DLE-303-015 http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 1 of 8 Establish by: Jim Lin Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB Package Dimensions Notes: 1.All dimensions are in millimeters 2.An epoxy meniscus may extend about 1.5mm(0.059") down the leads 3.Tolerances unless dimensions ±0.25mm Absolute Maximum Ratings (Ta=25℃) Parameter Continuous Forward Current Peak Forward Current(Duty 1/10 @ 1KHZ) Reverse Voltage Operating Temperature Storage Temperature Soldering Temperature(Time=5 sec) Power Dissipation Electrostatic Discharge Symbol IF IFP VR Topr Tstg Tsol Pd ESD Rating 30 100 5 -40 ~ +85 -40 ~ +100 260 ± 5 100 4000 Units mA mA V ℃ ℃ ℃ mW V Everlight Electronics Co., Ltd. Device Number :DLE-303-015 http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 2 of 8 Establish by: Jim Lin Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB Electro-Optical Characteristics (Ta=25℃) Parameter Forward Voltage Reverse Current Total Flux Viewing Angle Chromaticity Coordinates Zener Reverse Voltage Symbol VF IR Φv 2θ1/2 x y Vz Min. 3.0 ---2850 ---------5.2 Typ. 3.6 ---3800 75 0.30 0.29 ---Max. 4.0 10 5650 ------IF=30mA ------Iz=5mA ---V Condition IF=30mA VR=5V IF=30mA IF=30mA Unit V mA mlm deg ---- Rank 33-01/T4C-4PRB (1) VF(V) Bin. 1 2 3 4 5 Min. 3.00 3.20 3.40 3.60 3.80 Max. 3.20 3.40 3.60 3.80 4.00 (1) (2) (2) Color (3) (3)Φv(mlm) Max. ---------Bin. P Q R Min. 2850 3600 4500 Max. 3600 4500 5650 Bin. A0 B5 B6 Min. ---------- *Measurement Uncertainty of Forward Voltage：±0.1V *Measurement Uncertainty of Luminous Intensity: ±15% Everlight Electronics Co., Ltd. Device Number :DLE-303-015 http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 3 of 8 Establish by: Jim Lin Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB CIE Chromaticity Diagram Color Ranks (IF=30mA，Ta=25℃) Color Ranks A0 B5 B6 X Y X Y X 0.280 0.248 0.296 0.276 0.311 0.264 0.267 0.287 0.295 0.307 CIE Rank 0.283 0.305 0.307 0.315 0.330 0.339 0.296 0.276 0.311 0.294 0.330 0.318 Y 0.294 0.315 *Measurement uncertainty of the color coordinates：±0.01 Everlight Electronics Co., Ltd. Device Number :DLE-303-015 http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 4 of 8 Establish by: Jim Lin Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB Typical Electro-Optical Characteristics Curves Relative Intensity vs. Wavelength 1.2 Forward Current vs. Forward Voltage 30 1.0 FORWARD CURRENT (mA) RELATIVE INTENSITY 0.8 20 0.6 0.4 10 0.2 0.0 350 400 450 500 550 600 650 700 750 0 2.80 WAVELENGTH (nm) 3.00 3.20 3.40 3.60 3.80 FORWARD VOLTAGE (V) 4.00 Relative Intensity vs. Forward Current 1.00 Forward Current vs. Ambient Temp. 40 35 FORWARD CURRENT (mA) RELATIVE INTENSITY 0.80 30 25 20 15 10 5 0.60 0.40 0.20 0.00 0 5 10 15 20 25 30 0 0 20 40 60 80 AMBIENT TEMPERATURE (C) 100 FORWARD CURRENT (mA) Chromaticity Coordinate vs. Forward Current 0.34 Radiation Characteristics 0 Relative Intensity(a.u.) 1.0 0.8 0.6 0.4 0.2 0.0 -80 -60 -40 -20 0 Relative Intensity (a.u.) 30 0.32 x 0.30 y 60 0.28 0.26 0.24 90 10 20 30 40 50 Forward Current (mA) Viewing Angle(degree) http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 5 of 8 Everlight Electronics Co., Ltd. Device Number :DLE-303-015 Establish by: Jim Lin Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB Packing Quantity Specification (1) 60 pcs/1 tube, 30 tubes/1 small inside box, 12 small inside boxes/1 outside box (2) 60 pcs/1 tube, 105 tubes/1 big inside box, 4 big inside boxes/1 outside box Label Form Specification (1)Tube Label Form PART NO: 33-01/T4C-4PRB LOT NO: QTY: 60 CAT: (2)Box Label Form EVERLIGHT CPN: P/N: RoHS 33-01/T4C-4PRB QTY： LOT NO： MADE IN TAIWAN CAT: HUE: REF: PART NO: Everlgiht’s Production Number QTY: Packing Quantity LOT NO: Lot Number CAT: Ranks of Forward Voltage, Color Bin Grade and Total Flux CPN: Customer’s Production Number P/N : Production Number HUE: Reference REF: Reference MADE IN TAIWAN: Production Place Everlight Electronics Co., Ltd. Device Number :DLE-303-015 http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 6 of 8 Establish by: Jim Lin Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB Notes 1. 2. Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’s consent. Below the zener reference voltage Vz, all the current flows through LED and as the voltage rises to Vz, the zener diode “breakdown." If the voltage tries to rise above Vz current flows through the zener branch to keep the voltage at exactly Vz. When the LED is connected using serial circuit, if either piece of LED is no light up but current can’t flow through causing others to light down. In new design, the LED is parallel with zener diode. if either piece of LED is no light up but current can flow through causing others to light. 3. 4. 5. Everlight Electronics Co., Ltd. Device Number :DLE-303-015 http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 7 of 8 Establish by: Jim Lin Technical Data Sheet 3mm POWER LED 33-01/T4C-4PRB 6. Soldering Condition Careful attention should be paid during soldering. When soldering, leave more then 3mm from solder joint to case, and soldering beyond the base of the tie bar is recommended. Avoiding applying any stress to the lead frame while the LEDs are at high temperature particularly when soldering. Recommended soldering conditions: Hand Soldering Temp. at tip of iron Soldering time Distance 400℃ Max. (30W Max.) 3 sec Max. 3mm Min.(From solder joint to case) Distance 3mm Min. Preheat temp. Bath temp. Bath time. DIP Soldering 100℃ Max. (60 sec Max.) 265 Max. 5 sec Max. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http:\\www.everlight.com Everlight Electronics Co., Ltd. Device Number :DLE-303-015 http:\\www.everlight.com Establish date: 03-27-2007 Rev. 1 Page: 8 of 8 Establish by: Jim Lin
