333-2UBC-C430

Technical Data Sheet 5.0mm Round Type LED Lamps 333-2UBC/C430 █ Features : ● ● ● Choice of various viewing angles Available on tape and reel. Reliable and robust ● Pb free █ Descriptions : ● The series is specially designed for applications requiring higher brightness ● The led lamps are available with different colors, intensities, █ Applications : ● ● ● ● TV set Monitor Telephone Computer PART NO. 333-2UBC/C430 Material GaN/SiC Emitted Color Blue Lens Color Water Clear EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com Prepared date: 2004/6/25 Rev.: 3 Page: 1 of 6 Guangxiu Yuan Device Number : CDLE-033-525 Prepared by: A0005054,X0005026 Technical Data Sheet 5.0mm Round Type LED Lamps 333-2UBC/C430 Package Dimensions Notes: 1.All dimensions are in millimetres 2. An epoxy meniscus may extend about 1.5mm(0.059'') down to the lead. 3. Tolerances unless Dimension ±0.25mm. █ Absolute Maximum Ratings at Ta = 25℃ Parameter Forward Current Operating Temperature Storage Temperature Electrostatic Discharge Soldering Temperature Power Dissipation Peak Forward Current Reverse Voltage Symbol IF Topr Tstg ESD Tsol Pd IF(Peak) VR Rating 30 -40 to +85 -40 to +100 1000 260 ± 5 140 70 5 Unit mA ℃ ℃ V ℃ mW mA V Note: *1:I FP Conditions --Pulse Width ≦ 1msec and Duty ≦ 1/10. *2:Soldering time ≦ 5 seconds. EVERLIGHT ELECTRONICS CO.,LTD http : //w //www.everlight.com : Prepared date: 2004/6/25 Rev.: 3 Page: 2 of 6 Guangxiu Yuan Device Number : CDLE-033-525 Prepared by: Technical Data Sheet 5.0mm Round Type LED Lamps 333-2UBC/C430 Electro-Optical Characteristics (Ta=25℃) Parameter Forward Voltage Reverse Current Luminous Intensity Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Symbol VF IR Iv 2θ1/2 λp λd △λ Condition IF= VR= IF= IF= IF= IF= IF= 20 5 20 20 20 20 20 mA V mA mA mA mA mA Min. ／ ／ 160 ／ ／ ／ ／ Typ. 3.8 ／ 320 10 428 466 65 Max. 4.5 50 ／ ／ ／ ／ ／ Unit V μA mcd deg nm nm nm EVERLIGHT ELECTRONICS CO.,LTD. Device Number : CDLE-033-525 http : //www.everlight.com Prepared date: 2004/6/25 Rev.: 3 Page: 3 of 6 Prepared by: Guangxiu Yuan . Technical Data Sheet 5.0mm Round Type LED Lamps 333-2UBC/C430 █ Typical Electro-Optical Characteristic Curves: EVERLIGHT ELECTRONICS CO.,LTD http : //www.everlight.com Device Number : CDLE-033-525 Prepared date: 2004/6/25 Rev.: 3 Prepared by: Page: 4 of 6 Guangxiu Yuan Technical Data Sheet 5.0mm Round Type LED Lamps 333-2UBC/C430 █ Reliability test items and conditions: Test Sample Ac/Re Hours/Cycle size SEC 76 PCS 0/1 NO 1 Item Solder Heat Test Conditions TEMP : 260℃ ± 5 ℃ H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min TEMP : 100℃ 2 Temperature Cycle 300 CYCLES 76 PCS 0/1 3 Thermal Shock 300 CYCLES 76 PCS 0/1 4 High Temperature Storage 1000 HRS 76 PCS 0/1 5 Low Temperature Storage TEMP : -40℃ TEMP : 25℃ IF = 20mA 85℃ / 85% RH 1000 HRS 76 PCS 0/1 6 DC Operating Life High Temperature / High Humidity 1000 HRS 1000 HRS 76 PCS 0/1 0/1 7 76 PCS EVERLIGHT ELECTRONICS CO.,LTD. http : //www.everlight.com Prepared date: 2004/6/25 Rev.: 3 Page: 5 of 6 Device Number : CDLE-033-525 Prepared by: Guangxiu Yuan Technical Data Sheet 5.0mm Round Type LED Lamps 333-2UBC/C430 Packing Quantity Specification 1.500PCS/1Bag，5Bags/1Box 2.10Boxes/1Carton Label Form Specification CPN: Customer's Production Number P/N : Production Number QTY: Packing Quantity CAT: Ranks 333-2UBC/C430 HUE: Peak Wavelength REF: Reference LOT No: Lot Number MADE IN TAIWAN: Production Place Notes 1. Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. 2. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. 3. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT ’sconsent. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http:\\www.everlight.com EVERLIGHT ELECTRONICS CO.,LTD. Device Number : CDLE-033-525 http : //www.everlight.com Prepared date: 2004/6/25 Rev.: 3 Page: 6 of 6 Prepared by: Guangxiu Yuan
