38-01-G4C-ARTB

38-01-G4C-ARTB

  • 厂商:

    EVERLIGHT(台湾亿光)

  • 封装:

  • 描述:

    38-01-G4C-ARTB - 3mm POWER LED - Everlight Electronics Co., Ltd

  • 数据手册
  • 价格&库存
38-01-G4C-ARTB 数据手册
Technical Data Sheet 3mm POWER LED 38-01/G4C-ARTB Benefits . High Flux Output. . Low Profile. . Low Thermal Resistance. . Low Power Consumption. .The product itself will remain within RoHS compliant version. . ESD-withstand voltage: up to 4KV. Descriptions This revolutionary package design allows the light designer to reduce the number of LEDs required and provide a more uniform and unique illuminated appearance than with other LED solutions. This is possible through the efficient optical package design and high-current capabilities. The low profile package can be easily coupled with reflectors or lenses to efficiently distribute light and provide the desired light appearance. Applications . Automotive Exterior Lighting . Electronic Signs and Signals . Channel Letter . Special Lighting application Device Selection Guide Chip Material InGaN Emitted Color Brilliant Green PART NO. 38-01/G4C-ARTB Lens Color Water Clear Everlight Electronics Co., Ltd. Device number: DLE-308-019 http:\\www.everlight.com Established date: 04-30-2007 Rev.1 Page: 1 of 7 Established by: Jim Lin Technical Data Sheet 3mm POWER LED 38-01/G4C-ARTB Package Dimensions C1.2 C CATHODE C 7.62±0.5 A 5.0 TYP 2.5±0.5 R 0.7±0.2 3.0±0.2 A ANODE 7.62±0.5 4.4±0.2 5.08±0.2 1.55 TYP 5.08±0.3 0.75 TYP Notes: 1.All dimensions are in millimeters 2.An epoxy meniscus may extend about 1.5mm(0.059") down the leads 3.Tolerances unless dimensions ±0.25mm Absolute Maximum Ratings (Ta=25℃) Parameter Continuous Forward Current Peak Forward Current(Duty 1/10 @ 1KHZ) Operating Temperature Storage Temperature Soldering Temperature(T=5 sec) Power Dissipation Zener Reverse Current Electrostatic Discharge LED Junction Temperature Symbol IF IFP Topr Tstg Tsol Pd Iz ESD Tj Rating 30 100 -40 ~ +85 -40 ~ +100 260 ± 5 120 100 4K 110 Units mA mA ℃ ℃ ℃ mW mA V ℃ Everlight Electronics Co., Ltd. Device number: DLE-308-019 http:\\www.everlight.com Established date: 04-30-2007 Rev.1 0.5 Established by: Jim Lin 7.5±0.5 Page: 2 of 7 Technical Data Sheet 3mm POWER LED 38-01/G4C-ARTB Electro-Optical Characteristics (Ta=25℃) Parameter Total Flux Viewing Angle Peak Wavelength Dominant Wavelength Forward Voltage Reverse Current Zener Reverse Voltage Symbol Φv 2θ1/2 λp λd VF IR Vz Min. 4500 ------520 3.0 ---5.2 Typ. 6000 25 518 525 3.5 ------Max. 9000 ------532 4.0 10 ---Condition IF=30mA IF=30mA IF=30mA IF=30mA IF=30mA VR=5V Iz=5mA Unit mlm deg nm nm V uA V Rank 38-01/G4C-ARTB (1) VF(V) Bin. 1 2 3 4 5 Min. 3.00 3.20 3.40 3.60 3.80 Max. 3.20 3.40 3.60 3.80 4.00 (1) (2) (2) λd (3) (3)Φv(mlm) Max. 524 528 532 Bin. R S T Min. 4500 5650 7150 Max. 5650 7150 9000 Bin. 3 4 5 Min. 520 524 528 *Measurement Uncertainty of Forward Voltage:±0.1V *Measurement Uncertainty of Luminous Intensity: ±15% *Measurement Uncertainty of Dominant Wavelength ±1.0nm Everlight Electronics Co., Ltd. Device number: DLE-308-019 http:\\www.everlight.com Established date: 04-30-2007 Rev.1 Page: 3 of 7 Established by: Jim Lin Technical Data Sheet 3mm POWER LED 38-01/G4C-ARTB Typical Electro-Optical Characteristics Curves Relative Intensity vs. Wavelength 1.00 Forward Current vs. Forward Voltage 30 FORWARD CURRENT (mA) RELATIVE INTENSITY 20 0.50 10 0.00 450 475 500 525 550 575 600 625 650 WAVELENGTH (nm) 0 2.80 3.00 3.20 3.40 3.60 3.80 FORWARD VOLTAGE (V) 4.00 Relative Intensity vs. Forward Current 1.00 Forward Current vs. Ambient Temp. 40 35 RELATIVE INTENSITY 0.80 FORWARD CURRENT (mA) 0 5 10 15 20 25 30 30 25 20 15 10 5 0.60 0.40 0.20 0.00 0 0 20 40 60 80 AMBIENT TEMPERATURE (C) 100 FORWARD CURRENT (mA) Relative Intensity vs. Displacement Angle 0 1.0 0.9 0.8 0.7 0.6 0.5 0.4 0.3 0.2 0.1 0.0 30 Relative Intensity (a.u.) 60 -80 -60 -40 -20 0 Viewing angle (degree) 90 Everlight Electronics Co., Ltd. Device number: DLE-308-019 http:\\www.everlight.com Established date: 04-30-2007 Rev.1 Page: 4 of 7 Established by: Jim Lin Technical Data Sheet 3mm POWER LED 38-01/G4C-ARTB Packing Quantity Specification (1) 60 pcs/1 tube, 30 tubes/1 small inside box, 12 small inside boxes/1 outside box (2) 60 pcs/1 tube, 105 tubes/1 big inside box, 4 big inside boxes/1 outside box Label Form Specification (1)Tube Label Form PART NO: 38-01/G4C-ARTB LOT NO: QTY: 60 CAT: (2)Box Label Form EVERLIGHT CPN: P/N: RoHS 38-01/G4C-ARTB QTY: LOT NO: MADE IN TAIWAN CAT: HUE: REF: PART NO: Everlgiht’s Production Number QTY: Packing Quantity LOT NO: Lot Number CAT: Ranks of Forward Voltage, Dominant Wavelength and Total Flux CPN: Customer’s Production Number P/N : Production Number HUE: Reference REF: Reference MADE IN TAIWAN: Production Place Everlight Electronics Co., Ltd. Device number: DLE-308-019 http:\\www.everlight.com Established date: 04-30-2007 Rev.1 Page: 5 of 7 Established by: Jim Lin Technical Data Sheet 3mm POWER LED 38-01/G4C-ARTB Notes 1. Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. 2. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. 3. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’s consent. 4. Below the zener reference voltage Vz, all the current flows through LED and as the voltage rises to Vz, the zener diode “breakdown." If the voltage tries to rise above Vz current flows through the zener branch to keep the voltage at exactly Vz. 5. When the LED is connected using serial circuit, if either piece of LED is no light up but current can’t flow through causing others to light down. In new design, the LED is parallel with zener diode. if either piece of LED is no light up but current can flow through causing others to light. 6. Soldering Condition Everlight Electronics Co., Ltd. Device number: DLE-308-019 http:\\www.everlight.com Established date: 04-30-2007 Rev.1 Page: 6 of 7 Established by: Jim Lin Technical Data Sheet 3mm POWER LED 38-01/G4C-ARTB Careful attention should be paid during soldering. When soldering, leave more then 3mm from solder joint to case, and soldering beyond the base of the tie bar is recommended. Avoiding applying any stress to the lead frame while the LEDs are at high temperature particularly when soldering. Recommended soldering conditions: Hand Soldering Temp. at tip of iron Soldering time Distance 400℃ Max. (30W Max.) 3 sec Max. 3mm Min.(From solder joint to case) Distance 3mm Min. Preheat temp. Bath temp. Bath time. DIP Soldering 100℃ Max. (60 sec Max.) 265 Max. 5 sec Max. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http:\\www.everlight.com Everlight Electronics Co., Ltd. Device number: DLE-308-019 http:\\www.everlight.com Established date: 04-30-2007 Rev.1 Page: 7 of 7 Established by: Jim Lin
38-01-G4C-ARTB 价格&库存

很抱歉,暂时无法提供与“38-01-G4C-ARTB”相匹配的价格&库存,您可以联系我们找货
