57-21-R6C-AP1Q2B-BF

57-21-R6C-AP1Q2B-BF

  • 厂商:

    EVERLIGHT(台湾亿光)

  • 封装:

  • 描述:

    57-21-R6C-AP1Q2B-BF - Side View Red SMD LEDs - Everlight Electronics Co., Ltd

  • 数据手册
  • 价格&库存
57-21-R6C-AP1Q2B-BF 数据手册
EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Features ˙Fluorescence Type ․High Luminous Intensity ․High Efficiency ․Pb-free. ․The product itself will remain with RoHS compliant version Descriptions The 57-21series is available in soft orange, green,blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium. Applications ․OA Equipment ․Backlighting of Full Color LCD ․Replacement of Conventional Light Bulbs and Fluorescent Lamps Device Selection Guide Chip Lens Color Material AlGaInP Emitted Color Brilliant Red Water Clear Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:1 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Package Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:2 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Peak Forward Current (Duty 1/10 @1KHz) Power Dissipation Electrostatic Discharge(HBM) Operating Temperature Storage Temperature Soldering Temperature Symbol VR IF IFP Pd ESD Topr Tstg Tsol Rating 5 25 60 60 2000 -40 ~ +85 -40 ~+100 Unit V mA mA mW V ℃ ℃ Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Reverse Current Symbol Iv 2θ1/2 λp λd △λ VF IR Min. 45 --------617.5 ----1.75 ----- Typ. ----120 632 ----20 --------- Max. 112 --------633.5 ----2.35 10 Unit mcd deg nm nm nm V μA Condition IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA VR=5V Notes: 1.Tolerance of Luminous Intensity ±10% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.1V Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:3 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Bin Range of Dominant Wavelength Group Bin Code E4 A E5 E6 E7 Min. 617.5 621.5 625.5 629.5 Max. 621.5 625.5 629.5 633.5 nm IF=20mA Unit Condition Bin Range of Luminous Intensity Bin P1 P2 Q1 Q2 Min 45 57 72 90 Max 57 72 90 112 mcd IF=20mA Unit Condition Bin Range of Forward Voltage Group Bin 0 B 1 2 Min 1.75 1.95 2.15 Max 1.95 2.15 2.35 V IF=20mA Unit Condition Notes: 1. Tolerance of Dominant Wavelength ±1nm 2. Tolerance of Luminous Intensity ±10% 3.Tolerance of Forward Voltage ±0.1V Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:4 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Typical Electro-Optical Characteristics Curves Spectrum Distribution Relative luminous intensity (%) 100 75 Ta=25°C Forward Current I F (mA) ` 50 40 30 20 10 Forward Current vs. Forward Voltage Ta=25°C 50 25 0 550 600 650 700 Wavelength λ (nm) 750 0 1.2 1.6 2.0 2.4 2.8 3.0 Forward Voltage VF (V) Relative Luminous Intensity vs. Forward Current Ta=25°C Relative luminous intensity (%) 1000 f=1KHz Duty=1/10 Relative Luminous Intensity vs. Ambient Temperature Relative luminous intensity (%) 1000 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 10 10 Ambient Temperature T a (°C) Forward Current Derating Curve 40 Forward Current IF (mA) 30 1.0 20 10 0.7 0 0 20 40 60 80 100 0.9 0.8 10 10 Forward Current I F (mA) Radiation Diagram 0° 10° 1 2 10 3 Ta=25°C 20° 30° 40° 50° 60° 70° 80° 90° 0.5 0.3 0.1 0.2 0.4 0.6 Ambient Temperature T a (°C) Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:5 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Label Explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Pb EVERLIGHT RoHS CAT : XXX HUE : XXX REF : XXX CPN : P N : XXXXXXXXXXXXX XXXXXXXXXXXXX QTY : XXX LOT NO : XXXXXXXXXX Reference : XXXXXXXX MADE IN TAIWAN Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:6 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Carrier Tape Dimensions: Loaded Quantity 500 pcs Per Reel. Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:7 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Reliability Test Items and Conditions The reliability of products shall be satisfied with items listed below. Confidence level:90% LTPD:10% No. Items Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Test Sample Ac/Re Hours/Cycles Size 6 min 22 PCS. 0/1 1 Reflow Soldering 2 Temperature Cycle 300 Cycles 22 PCS. 0/1 3 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 22 PCS. 0/1 4 1000 Hrs. 22 PCS. 0/1 5 Temp. : -40℃ 1000 Hrs. 22 PCS. 0/1 6 IF = 20 mA 1000 Hrs. 22 PCS. 0/1 7 85℃/ 85%RH 1000 Hrs. 22 PCS. 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:8 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF Precautions For Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 48 hours under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 1~5 °C / Sec. 260°C. Max. 10 Sec. Max. 1~5 °C / Sec. Pre-heating 180~200°C 60 Sec. Max. Above 220°C 120 Sec. Max. 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:9 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Side View Red SMD LEDs 57-21/R6C-AP1Q2B/BF 4. Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5. Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-0000692 http://www.everlight.com Prepared date:05-Jan-2009 Rev. 1 Page:10 of 10 Prepared by: Ryan Chen Revision :1 Release Date:2009-05-11 22:09:23.0 Expired Period: Forever LifecyclePhase:
57-21-R6C-AP1Q2B-BF 价格&库存

很抱歉,暂时无法提供与“57-21-R6C-AP1Q2B-BF”相匹配的价格&库存,您可以联系我们找货
