EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Mini TOP Views LEDs 65-11UTC/S933/TR8 Features ․White SMT package. ․Optical indicator. ․Wide viewing angle. ․Soldering methods: IR reflow soldering. ․Available on tape and reel. ․Pb-free ․The product itself will remain within RoHS compliant version. Descriptions ․The 65-11 series is available in soft orange, green, blue, and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes the LED ideal for light pipe application. Applications ․Optical indicators. ․Coupling into light guides. ․Backlighting (LCD, cellular phones, switches, keys, displays, illuminated advertising, general lighting). ․Coupling into light guides. Device Selection Guide Chip Emitted Color Material InGaN Pure White Water Clear Resin Color Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 1 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Package Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 2 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Absolute Maximum Ratings (Ta=25℃) Parameter Symbol Rating Unit Reverse Voltage VR 5 V Forward Current Peak Forward Current IF 30 mA IFP (Duty 1/10 @1KHz) Power Dissipation Pd 100 mA 110 mW Electrostatic Discharge(HBM) ESD 2000 V Operating Temperature Topr -40 ~ +85 ℃ Storage Temperature Tstg -40 ~ +90 ℃ Reflow Soldering : 260 ℃ for 10 sec. Soldering Temperature Tsol Hand Soldering : 350 ℃ for 3 sec. Max. 1800 -3.50 Units mcd deg V Condition IF=20mA IF=20mA IF=20mA Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Forward Voltage Symbol IV 2θ1/2 VF Min. 1000 -2.70 Typ. -----120 ----- Notes: 1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Forward Voltage ±0.05V Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 3 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Bin Range Of Luminous Intensity Bin Code V2-1 W1 W2 Min. 1000 1120 1420 Max. 1120 1420 1800 mcd IF=20mA Unit Condition Bin Range Of Forward Voltage Group Bin Code 34 35 36 B14 37 38 39 40 41 Notes: 1.Tolerance of Luminous Intensity ±11% 2.Tolerance of Forward Voltage ±0.05V Min. 2.70 2.80 2.90 3.00 3.10 3.20 3.30 3.40 Max. 2.80 2.90 3.00 3.10 3.20 3.30 3.40 3.50 Unit Condition V IF=20mA Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 4 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Chromaticity Coordinates Specifications for Bin Grading IF=20mA Bin Code CIE_x 0.330 0.330 CC0-1 0.335 0.338 0.33 0.33 CC0-3 0.338 0.340 0.345 0.329 CIE_y 0.339 0.360 0.360 0.345 0.318 0.339 CC0-4 0.345 0.350 0.350 0.340 CC0-2 0.340 0.345 0.340 0.338 0.360 0.350 0.329 0.345 Bin Code CIE_x 0.338 0.335 CIE_y 0.345 0.360 *The C.I.E. 1931 chromaticity diagram ( Tolerance ±0.01). 0.36 CC0-2 CC0-1 0.35 0.34 y CC0-3 0.33 CC0-4 0.32 0.330 0.335 0.340 x 0.345 0.350 Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 5 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Typical Electro-Optical Characteristics Curves Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 6 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Label explanation CAT: Luminous Intensity Rank HUE: Chromaticity Coordinates REF: Forward Voltage Rank Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 7 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Carrier Tape Dimensions: Loaded quantity 2000 PCS per reel. + Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 8 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 Items Reflow Soldering Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA / 25℃ 85℃/ 85%RH Test Sample Ac/Re Hours/Cycles Size 6 min 22 PCS. 0/1 2 Temperature Cycle 300 Cycles 22 PCS. 0/1 3 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 22 PCS. 0/1 4 5 6 7 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 9 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 Precautions For Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 1~5 °C / Sec. 260°C. Max. 10 Sec. Max. 1~5 °C / Sec. Pre-heating 180~200°C 60 Sec. Max. Above 220°C 120 Sec. Max. 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 10 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. 65-11UTC/S933/TR8 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. :DSE-651-236 http://www.everlight.com Date:22-Sep.-2006 Rev. 1 Page: 11 of 11 Prepared by:Teresa Lee Revision :1 Release Date:2008-09-20 00:15:56.0 Expired Period: Forever LifecyclePhase:
