67-21-GHC-BV1-2T

Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Features ․P-LCC-2 package. ․White package. ․Optical indicator. ․Colorless clear window. ․Wide viewing angle. ․Suitable for vapor-phase reflow, Infrared reflow and wave solder processes. ․Computable with automatic placement equipment. ․Available on tape and reel (8mm Tape). ․Pb-free Descriptions ․The 67-21 series is available in soft orange, green, blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes it ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium. Applications ․Automotive: backlighting in dashboard and switch. ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD, switch and symbol. ․Light pipe application. ․General use. Device Selection Guide Chip Emitted Color Material InGaN Brilliant Green Water Clear Resin Color Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 1 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Package Dimensions Note: Tolerance unless mentioned is ±0.1mm; Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 2 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Peak Forward Current(Duty 1/10 @1KHZ) Power Dissipation Electrostatic Discharge Operating Temperature Storage Temperature Soldering Temperature Symbol VR IF IFP Pd ESD Topr Tstg Tsol Rating 5 25 100 110 150 -40 ~ +85 -40~ +100 Unit V mA mA mW V ℃ ℃ Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Reverse Current Symbol IV 2θ1/2 λp λd Δλ VF IR Min. 715 --------523.5 ----2.7 ----Typ. ----120 518 ----35 --------Max. 900 --------533.5 ----4.3 50 Unit Condition mcd deg nm nm nm V μA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA VR=5V Notes: 1.Tolerance of Luminous Intensity: ±11% 2.Tolerance of Dominant Wavelength: ±1nm 3.Tolerance of Forward Voltage: ±0.1V Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 3 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Bin Rang of Luminous Intensity Bin V1 Min 715 Max 900 Unit mcd Condition IF=20mA Bin Range of Dominant Wavelength Group Bin Code B13 B14 B B15 B16 B17 Min. 523.5 525.5 527.5 529.5 531.5 Max. 525.5 527.5 529.5 531.5 533.5 nm IF=20mA Unit Condition Notes: 1.Tolerance of Luminous Intensity: ±11% 2.Tolerance of Dominant Wavelength: ±1nm Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 4 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Typical Electro-Optical Characteristics Curves Spectrum Distribution Relative luminous intensity (%) IF(mA) 100 75 50 25 0 400 Ta=25° 50 40 30 25 20 10 0 2.6 3.0 3.4 3.8 4.2 4.5 Forward Current vs. Forward Voltage Ta=25° 450 500 550 Wavelength λp(nm) 600 Forward Current Forward Voltage(VF )-volts Luminous Intensity vs Forward Current Ta=25° Relative luminous intensity (%) 1000 Relative luminous intensity (%) 1000 L uminous Intensity vs. Ambient Temperature 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 10 10 10 1 10 2 Ambient Temperature Ta(°C) Forward Current IF(mA) Radiation Diagram 0° IF(mA) 50 40 30 20 10 0 0 20 40 60 85 100 10° 20° Ta=25° 30° Forward Current 1.0 0.9 0.8 0.7 0.5 0.3 0.1 0.2 0.4 0.6 40° 50° 60° 70° 80° 90° Ambient Temperature Ta(°C) Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 5 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Label Explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Pb EVERLIGHT RoHS CPN : P N : XXXXXXXXXXXXX XXXXXXXXXXXXX QTY : XXX CAT : XXX HUE : XXX REF : XXX LOT NO : XXXXXXXXXX Reference : XXXXXXXX MADE IN TAIWAN Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm; Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 6 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Carrier Tape Dimensions: Loaded Quantity 2000 pcs Per Reel. Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 7 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Reliability Test Items and Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 2 3 4 5 6 7 Items Reflow Soldering Temperature Cycle Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH Test Hours/Cycles 6 Min. 300 Cycles 300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. Sample Size 22 PCS. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 22 PCS. 22 PCS. Ac/Re 0/1 0/1 0/1 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 8 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T Precautions for Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life are 168 hours under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 1~5 °C / Sec. 260°C. Max. 10 Sec. Max. 1~5 °C / Sec. Pre-heating 180~200°C 60 Sec. Max. Above 220°C 120 Sec. Max. 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 9 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase: Technical Data Sheet TOP View LEDs 67-21/GHC-BV1/2T 4. Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-0000392 http://www.everlight.com Prepared date: Nov-14-2008 Rev. 1 Page: 10 of 10 Prepared by: Tracy Revision :1 Release Date:2009-04-01 21:34:23.0 Expired Period: Forever LifecyclePhase:
