67-21-R6C-FN2Q1BZ-2T_07

EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-FN2Q1BZ/2T Features ․P-LCC-2 package. ․White package. ․Optical indicator. ․Colorless clear window. ․Wide viewing angle. ․Suitable for vapor-phase reflow, Infrared reflow and wave solder processes. ․Computable with automatic placement equipment. ․Available on tape and reel (8mm Tape). ․Pb-free. ․The product itself will remain within RoHS compliant version Descriptions ․The 67-21 series is available in soft orange, green, blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium. Applications ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD, switch and symbol. ․Light pipe application. ․General use. Device Selection Guide Chip Emitted Color Material AlGaInP Brilliant Red Water Clear Resin Color Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 1 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Package Dimensions Note: The tolerances unless mentioned is ±0.1mm ; Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 2 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Peak Forward Current (Duty 1/10 @1KHz) Power Dissipation Electrostatic Discharge(HBM) Operating Temperature Storage Temperature Soldering Temperature Symbol VR IF IFP Pd ESD Topr Tstg Tsol Rating 5 25 60 60 2000 -40 ~ +85 -40 ~+90 Unit V mA mA mW V ℃ ℃ Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Typ. ----120 632 ----20 --------Max. 90 --------631 ----2.35 10 Unit mcd deg nm nm nm V μA Condition IF=10mA IF=10mA IF=10mA IF=10mA IF=10mA IF=10mA VR=5V Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Reverse Current Symbol Iv 2θ1/2 λp λd △λ VF IR Min. 36 --------621 ----1.75 ----- Notes: 1. Tolerance of Luminous Intensity: ±11% 2. Tolerance of Dominant Wavelength: ±1nm 3. Tolerance of Forward Voltage: ±0.1V Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 3 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Bin Rang of Luminous Intensity Group F Bin Code FF1 FF2 Min. 36 45 57 72 Bin 0 B 1 2 Min. 621 626 Max. 45 57 72 90 Min. 1.75 1.95 2.15 Max. 1.95 2.15 2.35 V IF=10mA Unit Condition nm IF=10mA Max. 626 631 Unit Unit nm Condition IF=10mA Bin Range of Dominant Wavelength Bin Code N2 P1 P2 Q1 Group Condition Bin Rang of Forward Voltage Notes: 1. Tolerance of Luminous Intensity: ±11% 2. Tolerance of Dominant Wavelength: ±1nm 3. Tolerance of Forward Voltage: ±0.1V Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 4 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Typical Electro-Optical Characteristics Curves Spectrum Distribution Relative luminous intensity (%) Forward Current IF (mA) 100 75 Ta=25°C 50 40 30 20 10 0 Forward Current vs. Forward Voltage Ta=25°C 50 25 0 550 600 650 700 Wavelength λ (nm) 750 1.4 1.6 1.8 2.0 2.2 2.4 Forward Voltage VF (V) Relative Luminous Intensity vs. Forward Current Relative luminous intensity (%) 1000 f=1KHz Duty=1/10 Relative Luminous Intensity vs. 1000 Ambient Temperature Ta=25°C Relative luminous intensity (%) 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 10 10 10 1 10 2 Ambient Temperature Ta (°C) Forward Current Derating Curve Forward Current IF (mA) 40 30 20 10 1.0 0.9 0.8 0.7 0 20 40 60 85 100 Forward Current IF (mA) Radiation Diagram 0° 10° Ta=25°C 20° 30° 40° 50° 60° 70° 80° 90° 0.5 0.3 0.1 0.2 0.4 0.6 Ambient Temperature Ta (°C) Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 5 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Label Explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 6 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Carrier Tape Dimensions: Loaded Quantity 2000 pcs Per Reel. Note: The tolerances unless mentioned is ±0.1mm Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 7 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. Items Test Condition Test Hours/Cycles Sample Size Ac/Re 1 Reflow Soldering Temp. : 260℃±5℃ Min. 5 sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ 6 Min. 22 PCS 0/1 2 Temperature Cycle 300 Cycles 22 PCS. 0/1 3 Thermal Shock 300 Cycles 22 PCS. 0/1 4 High Temperature Storage 1000 Hrs. 22 PCS. 0/1 5 Low Temperature Storage Temp. : -40℃ 1000 Hrs. 22 PCS. 0/1 6 DC Operating Life IF = 20 mA / 25℃ 1000 Hrs. 22 PCS. 0/1 7 High Temperature / High Humidity 85℃/85%RH 1000 Hrs. 22 PCS. 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 8 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T Precautions For Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 1~5 °C / Sec. 260°C. Max. 10 Sec. Max. 1~5 °C / Sec. Pre-heating 180~200°C 60 Sec. Max. Above 220°C 120 Sec. Max. . 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 9 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase: EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Top View LEDs 67-21/R6C-AP2R1B/2T 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-671-286 http://www.everlight.com Prepared date:6-Nov-2007 Rev. 1 Page: 10 of 10 Prepared by: Ray Yuan Revision :1 Release Date:2008-09-20 00:15:57.0 Expired Period: Forever LifecyclePhase:
