EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Features ․Pb-free. ․Inner reflector. ․White package. ․Optical indicator. ․P-LCC-2 package. ․Wide viewing angle. ․Colorless clear resin. ․Precondition：Base on JEDEC Level-2. ․ESD：Up to 2KV. (Base JESD22-A114-B) ․The product itself will remain within RoHS compliant version. ․Suitable for vapor-phase reflow, infrared reflow and wave solder processes. Descriptions ․The 67-21 series is available for orange, green, blue and yellow or other color due to the different raw material. ․Base on the package design, the device result in wide view angle. Applications ․Automotive backlighting or indicator：Dashboard, switch, audio and video equipments…etc. ․Backlight：LCD, switches, symbol, mobile phone and illuminated advertising. ․Display for indoor and outdoor application：Traffic…etc. ․Ideal for coupling into light guides. ․Substitution of traditional light ․Optical indicator ․General applications. Device Selection Guide Chip Material Emitted Color AlGaInP Brilliant Yellow Resin Color Water Clear Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 1 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Package Dimensions Note：Tolerances unless dimension ±0.1mm. Unit = mm Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 2 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Absolute Maximum Ratings (Ta=25℃) Parameter Symbol Rating Unit Reverse Voltage VR 12 V Forward Current IF 30 mA Peak Forward Current (Duty 1/10 @1KHz) IFP 100 mA Power Dissipation Pd 80 mW Junction Temperature Tj 115 ℃ Operating Temperature Topr -40 ~ +100 ℃ Storage Temperature Tstg -40 ~ +110 ℃ Soldering Temperature Tsol Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Electro-Optical Characteristics (Ta=25℃) Parameter Symbol Min. Typ. Max. Unit Condition Luminous Intensity Iv 71 ----- 180 mcd IF=20mA Viewing Angle 2θ1/2 ----- 120 ----- deg IF=20mA Peak Wavelength λp ----- 591 ----- nm IF=20mA Dominant Wavelength λd 583 ----- 592 nm IF=20mA Spectrum Radiation Bandwidth Δλ ----- 15 ----- nm IF=20mA Forward Voltage VF 1.70 2.10 2.40 V IF=20mA Reverse Current IR ----- ----- 10 μA VR=12V Notes： 1. Tolerance of Luminous Intensity：±11% 2. Tolerance of Dominant Wavelength：±1nm Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 3 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Bin Range of Dominant Wavelength Bin Code Min. Max. 3 583 586 4 586 589 5 589 592 Bin Range of Luminous Intensity Bin Min Max Q1 71 90 Q2 90 112 R1 112 140 R2 140 180 Unit Condition nm IF=20mA Unit Condition mcd IF=20mA Notes： 1. Tolerance of Luminous Intensity：±11% 2. Tolerance of Dominant Wavelength：±1nm Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 4 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Typical Electro-Optical Characteristics Curves ․Typical curve of spectral distribution： 100 Relative Intensity (%) V(λ) UY 50 0 400 450 500 550 600 650 700 Wp (nm) Note：V(λ)=Standard eye response curve Diagram characteristics of radiation 20 30 View Angle 50 60 70 80 90 10 o 0 o 1.0 o o 0.8 o 0.6 o 0.4 o 0.2 o o 0 1.0 0.8 0.6 0.4 0.2 0 Relative Intensity 20 o o 60 40 View Angle Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen o 80 o Page: 5 of 10 Relative Intensity 40 o EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Forward Current vs. Forward Voltage (Ta=25℃) Forward Current I F (mA) 100 10 1 0.1 1.5 1.6 1.7 1.8 1.9 2 2.1 2.2 2.3 For war d Voltage V F ( V) IF(mA) Forward current vs. Ambient Temp. 40 35 30 25 20 15 10 5 0 0 20 40 60 80 100 T (degree C) Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 6 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Label explanation ․CPN：Customer’s Production Number ․P/N：Production Number ․QTY：Packing Quantity ․CAT：Luminous Intensity Rank ․HUE：Dom. Wavelength Rank ․REF：Forward Voltage Rank ․LOT No：Lot Number RoHS Reel Dimensions 2.2 0.5 178.0 1.0 60.0 1.0 9.0 1.0 12.0 1.0 13.0 0.5 Note：Tolerances unless dimension ±0.1mm. Unit = mm Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 7 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Carrier Tape Dimensions: Loaded quantity 2000 PCS per reel Progressive direction 1.5+0.1 Polarity 0.23 1.75 3.5±0.05 4.0 8.0±0.3 4.0±0.1 1.75 2.0±0.05 3.23 2.24 Note：Tolerances unless dimension ±0.1mm. Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Label Page: 8 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM Precautions for Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LED should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED floor life is 1 year under 30℃ or less and 60% RH or less. If unused LED remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LED have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 (A) Pb-free solder temperature profile 1~5 °C / Sec. 260°C. Max. 10 Sec. Max. 1~5 °C / Sec. Pre-heating 180~200°C 60 Sec. Max. Above 220°C 120 Sec. Max. (B) Recommend soldering pad Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 9 of 10 EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet –Top View LED 67-21UYC/S602/TR8/AM 3.3 When soldering, do not put stress on the LED during heating. 3.4 After soldering, do not warp the circuit board. 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 1 Device No. : DSE-671-461 prepared date: 26-Dec-2006 Prepared by: Rita Shen Page: 10 of 10
