EVERLIGHT ELECTRONICS CO.,LTD.
Technical Data Sheet Bi-Color (Multi-color) Top Views LEDs
67-22/R6BHC-B07/2T
Features
․P-LCC-4 package. ․White package. ․Optical indicator. ․Colorless clear window. ․Ideal for backlight and light pipe application. ․Inter reflector. ․Wide viewing angle. ․Suitable for vapor-phase reflow, Infrared reflow and wave solder processes. ․Computable with automatic placement equipment. ․Available on tape and reel (8mm Tape). ․Pb-free. ․The product itself will remain within RoHS compliant version
Descriptions
․The 67-22 series is available in soft orange, green,blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium.
Applications
․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD’s, switches and symbols. ․Light pipe application. ․General use.
Device Selection Guide Chip Type Material Emitted Color AlGaInP Brilliant Red R6 InGaN Blue BH
Lens Color Water Clear
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 1 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Package Dimensions
C L
0.7±0.1 2.2±0.1
4
3.2±0.2 3.5±0.2 2.4±0.1
1
2.8±0.2
3
C L
2
3 4
2 1
Blue Red
0.5±0.1
2.8±0.2
0.15±0.05
0.8±0.1 1.9±0.2
2.7±0.2
For reflow soldering(propose)
0.8±0.1 1.8 1.6 1.8
Note: The tolerances unless mentioned is ±0.1mm;Unit = mm
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
0.7
Rev. 1 Prepared by: Venis Wu
Page: 2 of 11
2.2
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Absolute Maximum Ratings (Ta=25℃)
Parameter Reverse Voltage Forward Current Operating Temperature Storage Temperature Electrostatic Discharge(HBM) Power Dissipation Peak Forward Current(Duty 1/10 @ 1KHz) Soldering Temperature ESD IF Topr Tstg R6 BH Pd R6 BH R6 BH Tsol Symbol VR R6 BH Rating 5 50 25 -40 ~ +85 -40~ +100 2000 150 120 110 100 100 mA Unit V mA ℃ ℃ V V mW
IFP
Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Min. 90 90 ------------621 466.5 --------1.75 2.9 Typ. --------120 632 468 --------20 35 --------Max. 225 225 ------------631 471.5 --------2.35 3.7 10 μA VR=5V V nm deg nm nm IF=20mA Unit mcd Condition
Electro-Optical Characteristics (Ta=25℃)
Parameter Luminous Intensity Viewing Angle Peak Wavelength Symbol
IV
R6 BH
2θ1/2 λp λd △λ R6 BH R6 BH R6 BH VF R6 BH
Dominant Wavelength
Spectrum Radiation Bandwidth Forward Voltage
Reverse Current IR --------Notes: 1.Tolerance of Luminous Intensity ±10% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.1V
Everlight Electronics Co., Ltd. Device No. :DSE-672-085 http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 3 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Bin Range Of Luminous Intensity Chip Bin Code Q2 R6 R1 R2 S1 Q2 BH R1 R2 Min. 90.0 112 140 180 90.0 112 140 Max. 112 140 180 225 112 140 180 225 mcd
IF =20mA
Unit
Condition
S1 180 Bin Range Of Dominant Wavelength Chip R6 Bin Code Min.
Max. 626 631
Unit nm
Condition
IF =20mA
FF1 621 FF2 626 Bin Range Of Forward Voltage Chip R6 Bin Code 0 1 2 11 12 13 14 Min. 1.75 1.95 2.15 2.90 3.10 3.30 3.50
Max. 1.95 2.15 2.35 3.10 3.30 3.50 3.70
Unit
Condition
V
IF =20mA
BH Notes:
1.Tolerance of Luminous Intensity ±10% 2.Tolerance of Dominant Wavelength ±1nm 3.Tolerance of Forward Voltage ±0.1V
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 4 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Typical Electro-Optical Characteristics Curves(R6)
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 5 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Typical Electro-Optical Characteristics Curves(BH)
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 6 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Label explanation
CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank
Reel Dimensions
Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 7 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Carrier Tape Dimensions: Loaded quantity 2000 PCS per reel.
NOTE :TOLERANCES UNLESS DIMENSION ±0.1 mm UNIT: mm
Moisture Resistant Packaging
Label
Aluminum moisture-proof bag
Desiccant
Label
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 8 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Reliability Test Items And Conditions
The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10%
No. 1
Items Reflow Soldering
Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA/ 25℃ 85℃/ 85%RH
Test Sample Hours/Cycles Size 6 min 22 PCS.
Ac/Re 0/1
2
Temperature Cycle
300 Cycles
22 PCS.
0/1
3
Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity
300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs.
22 PCS.
0/1
4 5 6 7
22 PCS. 22 PCS. 22 PCS. 22 PCS.
0/1 0/1 0/1 0/1
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 9 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
Precautions For Use
1. Over-current-proof Customer must apply resistors for protection , otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package, the LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 The LEDs should be used within a year. 2.4 After opening the package, the LEDs should be kept at 30℃ or less and 70%RH or less. 2.5 The LEDs should be used within 168 hours (7 days) after opening the package. 2.6 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile
1~5 °C / Sec. 260°C . M ax. 10 Sec. M ax. 1~5 °C / Sec. Pre-heating 180~200°C
60 Sec. M ax. A bove 220°C
1 20 Sec. M ax.
3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder.
Everlight Electronics Co., Ltd. Device No. :DSE-672-085
http://www.everlight.com Prepared date: 27.Jan.2006
Rev. 1 Prepared by: Venis Wu
Page: 10 of 11
EVERLIGHT ELECTRONICS CO.,LTD.
67-22/R6BHC-B07/2T
5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing.
