67-22-R6G6C-B09-2T

Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Features ․P-LCC-4 package. ․White package. ․Optical indicator. ․Colorless clear window. ․Ideal for backlight and light pipe application. ․Inter reflector. ․Wide viewing angle. ․Suitable for vapor-phase reflow. ․Computable with automatic placement equipment. ․Available on tape and reel (8mm Tape). ․Pb-free. ․The product itself will remain within RoHS compliant version Descriptions ․The 67-22 series is available in soft orange, green,blue and yellow. Due to the package design, the LED has wide viewing angle and optimized light coupling by inter reflector. This feature makes ideal for light pipe application. The low current requirement makes this device ideal for portable equipment or any other application where power is at a premium. Applications ․Telecommunication: indicator and backlighting in telephone and fax. ․Flat backlight for LCD’s, switches and symbols. ․Light pipe application. ․General use. Device Selection Guide Chip Type R6 G6 Material AlGaInP AlGaInP Emitted Color Brilliant-Red Water Clear Brilliant Yellow Green Resin Color Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 1 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Package Dimensions Red Green Note: The tolerances unless mentioned is ±0.1mm; Unit = mm Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 2 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current IF G6 R6 Power Dissipation Peak Forward Current (Duty 1/10 @1KHz) Pd G6 R6 IFP G6 R6 Electrostatic Discharge(HBM) ESD G6 Operating Temperature Storage Temperature Soldering Temperature Topr Tstg Tsol 2000 -40 ~ +85 -40~ +90 ℃ ℃ 60 2000 V 60 60 mA 25 60 mW Symbol VR R6 Rating 5 25 mA Unit V Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 3 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Electro-Optical Characteristics (Ta=25℃) Parameter Luminous Intensity Viewing Angle Peak Wavelength Symbol R6 IV G6 2θ1/2 λp R6 G6 Min. 57 36 ------------621 570 --------1.75 1.75 ----- Typ. --------130 632 575 --------20 20 ------------- Max. 140 90 --------- Unit mcd Condition IF=20mA mcd deg nm IF=20mA IF=20mA ----627 nm IF=20mA 574 ----nm IF=20mA ----2.35 V IF=20mA VR=5V 2.35 10 μA Dominant Wavelength λd R6 G6 Spectrum Radiation Bandwidth △λ R6 G6 R6 Forward Voltage VF G6 IR Reverse Current Notes: 1. Tolerance of Luminous Intensity: ±11% 2. Tolerance of Dominant Wavelength: ±1nm 3. Tolerance of Forward Voltage: ±0.1V Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 4 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Bin Range of Luminous Intensity Chip Bin Code P2 Q1 R6 Q2 R1 N2 P1 G6 P2 Q1 57 72 72 90 90 112 36 45 112 140 mcd 45 57 IF=20mA Min. 57 72 Max. 72 90 Unit Condition Bin Range of Dominant Wavelength Chip Bin Code 0 R6 1 2 0 G6 1 2 Notes: 1. Tolerance of Luminous Intensity: ±11% 2. Tolerance of Forward Voltage: ±0.1V Min. 1.75 1.95 2.15 1.75 1.95 2.15 Max. 1.95 2.15 2.35 V 1.95 2.15 2.35 IF=20mA Unit Condition Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 5 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Typical Electro-Optical Characteristics Curves(R6) Spectrum Distribution Relative luminous intensity (%) Forward Current IF (mA) 100 75 Ta=25°C 50 40 30 20 10 0 Forward Current vs. Forward Voltage Ta=25°C 50 25 0 550 600 650 700 Wavelength λ (nm) 750 1.4 1.6 1.8 2.0 2.2 2.4 Forward Voltage VF (V) Relative Luminous Intensity vs. Forward Current Relative luminous intensity (%) 1000 f=1KHz Duty=1/10 Relative Luminous Intensity vs. 1000 Ambient Temperature Ta=25°C Relative luminous intensity (%) 100 100 10 10 1 -60 -40 -20 0 20 40 60 80 100 10 10 10 1 10 2 Ambient Temperature Ta (°C) Forward Current Derating Curve Forward Current IF (mA) 40 30 20 10 1.0 0.9 0.8 0.7 0 20 40 60 85 100 Forward Current IF (mA) Radiation Diagram 0° 10° Ta=25°C 20° 30° 40° 50° 60° 70° 80° 90° 0.5 0.3 0.1 0.2 0.4 0.6 Ambient Temperature Ta (°C) Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 6 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Typical Electro-Optical Characteristics Curves(G6) Spectrum Distribution Relative Luminous Intensity (%) 100 75 Ta=25°C Forward Current I (mA) F Forward Current vs. Forward Voltage Ta=25°C 50 40 30 20 10 0 1.6 1.8 2.0 2.2 50 25 0 500 550 600 650 Wavelength λ (nm) 700 2.4 2.6 Forward Voltage V (V) F Relative Luminous Intensity vs. Forward Current Ta=25°C Relative Luminous Intensity (%) 1000 f=1KHz Duty=1/10 Relative Luminous Intensity vs. Ambient Temperature Relative Luminous Intensity (%) 1000 100 100 10 10 1 -60 -40 -20 1 0 20 40 60 80 100 0 10 Ambient Temperature Ta (°C) Forward Current Derating Curve 40 Forward Current I F (mA) 30 1.0 20 10 0 0.9 0.8 0.7 20 40 60 80 100 2 1 10 10 Forward Current I F (mA) Radiation Diagram 0° 10° 3 10 Ta=25°C 20° 30° 40° 50° 60° 70° 80° 90° 0 0.5 0.3 0.1 0.2 0.4 0.6 Ambient Temperature Ta (°C) Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 7 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Label Explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Pb EVERLIGHT RoHS CAT : XXX HUE : XXX REF : XXX CPN : P N : XXXXXXXXXXXXX XXXXXXXXXXXXX QTY : XXX LOT NO : XXXXXXXXXX Reference : XXXXXXXX MADE IN TAIWAN Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 8 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Carrier Tape Dimensions: Loaded Quantity 2000 PCS per reel 3 4 + 2 Note: The tolerances unless mentioned is ±0.1mm; Unit = mm Moisture Resistant Packaging Everlight Electronics Co., Ltd. Device No.DSE-0000926 + 1 Label Aluminum moisture-proof bag Desiccant Label http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 9 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Reliability Test Items and Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. Items Test Condition Temp. : 260℃±5℃ Max. 10 sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Test Sample Size Ac/Re Hours/Cycles 6 Min. 22 PCS. 0/1 1 Reflow Soldering 2 Temperature Cycle 300 Cycles 22 PCS. 0/1 3 Thermal Shock 300 Cycles 22 PCS. 0/1 4 High Temperature Storage 1000 Hrs. 22 PCS. 0/1 5 Low Temperature Storage Temp. : -40℃ 1000 Hrs. 22 PCS. 0/1 6 DC Operating Life High Temperature / High Humidity IF = 20 mA/ 25℃ 1000 Hrs. 22 PCS. 0/1 7 85℃/ 85%RH 1000 Hrs. 22 PCS. 0/1 Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 10 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T Precautions for Use 1. Over-current-proof Customer must apply resistors for protection , otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package, the LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life are 168 hours under 30℃ or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 260°C Max. 10sec. Max. 6°C/sec.Max. Above255°C 30sec.Max. 3°C/sec.Max. Above 217°C 60~150sec. Pre-heating 150~200°C 60~120sec. 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 11 of 12 Prepared by: Rita Shen Technical Data Sheet Top Views LEDs 67-22/R6G6C-B09/2T 4. Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. 5. Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No.DSE-0000926 http://www.everlight.com Prepared date:18-Mar.-2011 Rev. 3 Page: 12 of 12 Prepared by: Rita Shen
