93-21SYGC

EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet High Performance SMD LED with Reflector 93-21SYGC/S530-XX/TR8 Features ․Compatible with automatic placement equipment. ․Compatible with infrared and vapor phase reflow solder process. ․EIA std. package. ․IC compatible. ․Pb- free. ․The product itself will remain within RoHS compliant version. Applications ․Telecommunication: indicator and backlighting in telephone and fax. ․Indicator and backlight for audio and video equipment ․Indicator and backlight for battery driven equipment. ․Flat backlight for LCD, switch and symbol. ․Light pipe application. ․General use. Device Selection Guide Chip Lens Color Material Emitted Color Brilliant Yellow Green Water Clear AlGaInP Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 1 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530-XX/TR8 Package Dimensions 0.4± 0.07 0.5± 0.07 2.2± 0.1 Anode mark 3.0± 0.1 4.6± 0.2 2.7± 0.1 1.0± 0.1 1.5± 0.1 1.7± 0.1 0.62 +0.13 -0 + Polarity 0.15± 0.05 0.26± 0.1 For reflow soldering (propose) 4.34± 0.1 0.4± 0.1 0.5± 0.1 0.74± 0.1 0.74± 0.1 Notes: All dimensions are in millimeters. Tolerances unspecified are±0.1mm Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 2 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530-XX/TR8 Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Operating Temperature Storage Temperature Electrostatic Discharge(HBM) Power Dissipation Peak Forward Current (Duty 1/10 @1KHz) Soldering Temperature Symbol VR IF Topr Tstg ESD Pd IFP Tsol Rating 5 25 -40 ~ +85 -40 ~ +100 2000 60 60 Unit V mA ℃ ℃ V mW mA Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Electro-Optical Characteristics (Ta=25℃) Parameter Symbol *Chip Rank E1 Luminous intensity Min. 10 16 25 38 Typ. 16 26 37 53 130 575 573 20 2.0 Max. Unit Condition IF=20mA --------------------------------2.4 10 deg nm nm nm V μA mcd Iv E2 E3 E4 IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA VR=5V Viewing Angle Peak Wavelength Dominant Wavelength 2θ1/2 λp λd △λ VF IR ------------------------- ------------------------- Spectrum Radiation Bandwidth Forward Voltage Reverse Current ----- *93-21SYGC/S530-XX/TR8 Chip Rank Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 3 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530- XX/TR8 Typical Electro-Optical Characteristics Curves Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 4 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530- XX/TR8 Label explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Reel Dimensions Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 5 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530-XX/TR8 Carrier Tape Dimensions: Loaded quantity 1000 PCS per reel. Note: The tolerances unless mentioned is ±0.1mm Unit = mm Moisture Resistant Packaging Label Aluminum moisture-proof bag Desiccant Label Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 6 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530-XX/TR8 Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 Items Solder Heat Test Condition Temp. : 260℃±5℃ Min. 5sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/ 85%RH Test Sample Ac/Re Hours/Cycles Size 6 Min. 22 PCS. 0/1 2 Temperature Cycle 300 Cycles 22 PCS. 0/1 3 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 22 PCS. 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 0/1 4 5 6 7 22 PCS. 22 PCS. 22PCS. 22 PCS. 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 7 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530-XX/TR8 Precautions For Use 1. Over-current-proof Customer must apply resistors for protection , otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package, the LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30 deg C or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3. Soldering Condition 3.1 Pb-free solder temperature profile 3.2 Reflow soldering should not be done more than two times. 3.3 When soldering, do not put stress on the LEDs during heating. 3.4 After soldering, do not warp the circuit board. 4.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 8 of 9 Prepared by:Rita Shen EVERLIGHT ELECTRONICS CO.,LTD. 93-21SYGC/S530-XX/TR8 5.Repairing Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether the characteristics of the LEDs will or will not be damaged by repairing. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-931-087 http://www.everlight.com Date:30-Nov-2005 Rev. 2 Page: 9 of 9 Prepared by:Rita Shen
