94-22SYGC

EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet High performance SMD LED with Reflector 94-22SYGC/S530-XX/S2 Features White package. Dual-chip, wide-angle, low-profile LEDs . Excellent chip to chip consistency Super Intensity High performance Pb-free. The product itself will remain within RoHS compliant version. Applications Automotive: backlighting in dashboard and switch. Telecommunication: indicator and backlighting in telephone and fax. Indicator and backlight for audio and video equipment. Indicator and backlight for battery driven equipment. Display Screen Illumination on Portable Handheld Devices Indicator and backlight in office equipment. General use. Device Selection Guide Chip Material AlGaInP Emitted Color Brilliant Yellow Green Lens Color Water Clear Everlight Electronics Co., Ltd. Device No. : DSE-942-077 http://www.everlight.com prepared date: 22-Aug-2005 Rev. 2 Page: 1 of 7 Prepared by: Venis Wu EVERLIGHT ELECTRONICS CO.,LTD. 94-22SYGC/S530-XX/S2 Package Dimensions Note: The tolerances unless mentioned is ±0.1mm ;Unit = mm Everlight Electronics Co., Ltd. Device No. : DSE-942-077 http://www.everlight.com prepared date: 22-Aug-2005 Rev. 2 Page: 2 of 7 Prepared by: Venis Wu EVERLIGHT ELECTRONICS CO.,LTD. 94-22SYGC/S530-XX/S2 Absolute Maximum Ratings @Ta=25℃ Parameter Reverse Voltage Forward Current Operating Temperature Storage Temperature Electrostatic Discharge(HBM) Power Dissipation Peak Forward Current(Duty 1/10 @ 1KHZ) Soldering Temperature Symbol VR IF Topr Tstg ESD Pd IFP Rating 5 25 -40 ~ +85 -40~ +100 2000 60 60 Unit V mA ℃ ℃ V mW mA Reflow Soldering : 260 ℃ for 10 sec. Tsol Hand Soldering : 350 ℃ for 3 sec. Everlight Electronics Co., Ltd. Device No. : DSE-942-077 http://www.everlight.com prepared date: 22-Aug-2005 Rev. 2 Page: 3 of 7 Prepared by: Venis Wu EVERLIGHT ELECTRONICS CO.,LTD. 94-22SYGC/S530-XX/S2 Electro-Optical Characteristics @ Ta=25℃ *Chip Rank E2 Luminous Intensity Parameter Symbol Min. 47 71 94 117 ------------------------- Typ. 61 100 132 152 575 573 20 2.0 130 ----- Max. ----------------------------2.4 ----10 Unit Condition IF=20mA IV E3 E4 E5 mcd IF=20mA IF=20mA IF=20mA Peak Wavelength λp λd △λ VF 2θ1/2 IR ------------------------- nm nm nm V deg uA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA VR=5V Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Viewing Angle Reverse Current *94-22SYGC/S530-XX/S2 Chip Rank Everlight Electronics Co., Ltd. Device No. : DSE-942-077 http://www.everlight.com prepared date: 22-Aug-2005 Rev. 2 Page: 4 of 7 Prepared by: Venis Wu EVERLIGHT ELECTRONICS CO.,LTD. 94-22SYGC/S530-XX/S2 Typical Electro-Optical Characteristics Curves Everlight Electronics Co., Ltd. Device No. : DSE-942-077 http://www.everlight.com prepared date: 22-Aug-2005 Rev. 2 Page: 5 of 7 Prepared by: Venis Wu EVERLIGHT ELECTRONICS CO.,LTD. 94-22SYGC/S530-XX/S2 Label explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% No. 1 Items Soldering Heat Test Condition Temp. : 260℃±5℃ Min. 5 sec. H : +100℃ 15min ∫ 5 min L : -40℃ 15min H : +100℃ 5min ∫ 10 sec L : -10℃ 5min Temp. : 100℃ Temp. : -40℃ IF = 20 mA / 25℃ 85℃/85%RH Test Sample Ac/Re Hours/Cycles Size 6 Min. 22 PCS. 0/1 2 Temperature Cycle 300 Cycles 22 PCS. 0/1 3 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 22 PCS. 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 0/1 4 5 6 7 22 PCS. 22 PCS. 22 PCS. 22 PCS. 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-942-077 http://www.everlight.com prepared date: 22-Aug-2005 Rev. 2 Page: 6 of 7 Prepared by: Venis Wu EVERLIGHT ELECTRONICS CO.,LTD. 94-22SYGC/S530-XX/S2 Precautions For Use 1. Over-current-proof Customer must apply resistors for protection, otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package: The LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30 deg C or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-942-077 http://www.everlight.com prepared date: 22-Aug-2005 Rev. 2 Page: 7 of 7 Prepared by: Venis Wu
