94-22UBC

EVERLIGHT ELECTRONICS CO., LTD Technical Data Sheet High Performance with Reflector LEDs 94-22UBC/C430 Features： White package. Dual-chip, wide-angle, low-profile LEDs . Excellent chip to chip consistency Super Intensity High performance Pb-free The product itself will remain within RoHS compliant version. Applications： Automotive: backlighting in dashboard and switch. Telecommunication: indicator and backlighting in telephone and fax. Indicator and backlight for audio and video equipment. Indicator and backlight for battery driven equipment. Display Screen Illumination on Portable Handheld Devices Indicator and backlight in office equipment. General use. Device Selection Guide Chip Lens Color Material GaN/SiC Emitted Color Blue Water Clear Everlight Electronics Co., Ltd. Device No. : DSE-942-017 http://www.everlight.com Prepared date: 22-Sep-2005 Rev. 2 Page: 1 of 6 Prepared by: Ray Yuan EVERLIGHT ELECTRONICS CO., LTD 94-22UBC/C430 Package Dimensions Notes: All dimensions are in millimeters. Tolerances unspecified are±0.1mm. Everlight Electronics Co., Ltd. Device No. : DSE-942-017 http://www.everlight.com Prepared date: 22-Sep-2005 Rev. 2 Page: 2 of 6 Prepared by: Ray Yuan EVERLIGHT ELECTRONICS CO., LTD 94-22UBC/C430 Absolute Maximum Ratings (Ta=25℃) Parameter Reverse Voltage Forward Current Operating Temperature Storage Temperature Electrostatic Discharge(HBM) Power Dissipation Peak Forward Current(Duty 1/10 @ 1KHZ) Soldering Temperature Symbol VR IF Topr Tstg ESD Pd IFP Tsol Rating 5 30 -40 ~ +85 -40~ +100 1000 130 70 Unit V mA ℃ ℃ V mW mA Reflow Soldering : 260 ℃ for 10 sec. Hand Soldering : 350 ℃ for 3 sec. Electro-Optical Characteristics (Ta=25℃) Parameter Luminous intensity Viewing Angle Peak Wavelength Symbol Iv 2θ1/2 λp λd △λ VF IR Min. 35 ------------------------- Typ. 45 130 428 466 65 7.6 ----- Max. --------------------9.0 10 Unit mcd deg nm nm nm V uA Condition IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA VR=5V Dominant Wavelength Spectrum Radiation Bandwidth Forward Voltage Reverse Current Everlight Electronics Co., Ltd. Device No. : DSE-942-017 http://www.everlight.com Prepared date: 22-Sep-2005 Rev. 2 Page: 3 of 6 Prepared by: Ray Yuan EVERLIGHT ELECTRONICS CO., LTD 94-22UBC/C430 Typical Electro-Optical Characteristics Curves Everlight Electronics Co., Ltd. Device No. : DSE-942-017 http://www.everlight.com Prepared date: 22-Sep-2005 Rev. 2 Page: 4 of 6 Prepared by: Ray Yuan EVERLIGHT ELECTRONICS CO., LTD 94-22UBC/C430 Label explanation CAT: Luminous Intensity Rank HUE: Dom. Wavelength Rank REF: Forward Voltage Rank Reliability Test Items And Conditions The reliability of products shall be satisfied with items listed below. Confidence level : 90 % LTPD : 10 % Test Sample No. Items Test Condition Hours/Cycles Size Temp. : 260℃±5℃ 1 Soldering Heat 22 Pcs. 10 sec. 2 Temperature Cycle H : +100℃ 15min. ∫ 5 min. L : -405℃ 15min. H : +100℃ 5min. ∫ 10 sec. L : -10℃ 5min. Temp. : 100℃ Temp. : -40℃ IF = 20 mA 85℃/R.H85% 300 Cycles 22 Pcs. Ac/Re 0/1 0/1 3 Thermal Shock High Temperature Storage Low Temperature Storage DC Operating Life High Temperature / High Humidity 300 Cycles 1000 Hrs. 1000 Hrs. 1000 Hrs. 1000 Hrs. 22 Pcs. 0/1 4 5 6 7 22 Pcs. 22 Pcs. 22 Pcs. 22 Pcs. 0/1 0/1 0/1 0/1 Everlight Electronics Co., Ltd. Device No. : DSE-942-017 http://www.everlight.com Prepared date: 22-Sep-2005 Rev. 2 Page: 5 of 6 Prepared by: Ray Yuan EVERLIGHT ELECTRONICS CO., LTD 94-22UBC/C430 Precautions For Use 1. Over-current-proof Customer must apply resistors for protection , otherwise slight voltage shift will cause big current change ( Burn out will happen ). 2. Storage 2.1 Do not open moisture proof bag before the products are ready to use. 2.2 Before opening the package, the LEDs should be kept at 30℃ or less and 90%RH or less. 2.3 After opening the package: The LED's floor life is 1 year under 30 deg C or less and 60% RH or less. If unused LEDs remain, it should be stored in moisture proof packages. 2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the storage time, baking treatment should be performed using the following conditions. Baking treatment : 60±5℃ for 24 hours. 3.Soldering Iron Each terminal is to go to the tip of soldering iron temperature less than 350℃ for 3 seconds within once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do soldering of each terminal. Be careful because the damage of the product is often started at the time of the hand solder. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http://www.everlight.com Everlight Electronics Co., Ltd. Device No. : DSE-942-017 http://www.everlight.com Prepared date: 22-Sep-2005 Rev. 2 Page: 6 of 6 Prepared by: Ray Yuan
