DATASHEET
3.0mm Infrared LED
IR264C
Technical Data Sheet
3mm Infrared LED , T-1
IR264C
Features
․High reliability
․High radiant intensity
․Peak wavelength λp=940nm
․2.54mm Lead spacing
․Low forward voltage
․Pb.Free
․This product itself will remain within RoHS compliant version.
․Compliance with EU REACH
․Compliance Halogen Free(Br < 900ppm, Cl < 900ppm, Br+Cl < 1500ppm)
Descriptions
․EVERLIGHT’s Infrared Emitting Diode (IR264C) is a
high intensity diode , molded in a water clear plastic package.
․The device is spectrally matched with phototransistor , photodiode
and infrared receiver module.
1
Copyright © 2010, Everlight All Rights Reserved. Release Date : Dec.12.2016 Issue No: DIR-0000248 . Rev3
www.everlight.com
DATASHEET
3.0mm Infrared LED
IR264C
Applications
․Free air transmission system
․Infrared remote control units with high power requirement
․Smoke detector
․Infrared applied system
Device Selection Guide
LED Part No.
Chip
Material
Lens Color
IR264C
GaAlAs
Water Clear
Package Dimensions
Notes: 1.All dimensions are in millimeters
2.Tolerances unless dimensions ±0.25mm
2
Copyright © 2010, Everlight All Rights Reserved. Release Date : Dec.12.2016 Issue No: DIR-0000248 . Rev3
www.everlight.com
DATASHEET
3.0mm Infrared LED
IR264C
Absolute Maximum Ratings (Ta=25℃)
Parameter
Symbol
Rating
Continuous Forward Current
IF
100
Units
mA
Peak Forward Current
IFP
1.0
A
Reverse Voltage
VR
5
V
Operating Temperature
Topr
-40 ~ +85
℃
Storage Temperature
Tstg
-40 ~ +100
℃
Soldering Temperature
Tsol
260
℃
Power Dissipation at(or below)
25℃Free Air Temperature
Pd
150
mW
Notes: *1:IFP Conditions--Pulse Width≦100μs and Duty≦1%.
*2:Soldering time≦5 seconds.
Electro-Optical Characteristics (Ta=25℃)
Parameter
Radiant Intensity
Symbol
Ee
Condition
IF=20mA
IF=100mA
Min.
Typ.
Max.
4.0
5.6
--
--
30
--
Pulse Width≦100μs ,Duty≦1%.
--
300
--
Pulse Width≦100μs ,Duty≦1%
IF=1A
mW/sr
Peak Wavelength
λp
IF=20mA
--
940
--
nm
Spectral
Bandwidth
Δλ
IF=20mA
--
45
--
nm
IF=20mA
IF=100mA
--
1.2
1.5
--
1.4
1.8
--
2.6
4.0
--
--
--
40
10
--
Forward Voltage
VF
Pulse Width≦100μs ,Duty≦1%
IF=1A
Pulse Width≦100μs ,Duty≦1%.
Reverse Current
IR
2θ1/2
VR=5V
IF=20mA
View Angle
Note:
*Measurement Uncertainty of Forward Voltage: ±0.1V
*Measurement Uncertainty of Luminous Intensity: ±10%
*Measurement Uncertainty of Dominant Wavelength ±1.0nm
3
Units
Copyright © 2010, Everlight All Rights Reserved. Release Date : Dec.12.2016 Issue No: DIR-0000248 . Rev3
V
μA
deg
www.everlight.com
DATASHEET
3.0mm Infrared LED
IR264C
Typical Electro-Optical Characteristics Curves
Fig.1
Forward Current vs.
Ambient Temperature
140
Fig.2
Spectral Distribution
100
120
IF=20mA
Ta=25°C
80
100
80
60
60
40
40
20
20
0
-40 -20 0
Fig.3
20
40
60
80
100
Peak Emission Wavelength vs.
0
Fig.4 Forward Current
Ambient Temperature
980
vs.
Forward Voltage
10
960
10
4
3
940
10
920
900
-25
4
0
25
50
75
100
2
1
10
0
1
Copyright © 2010, Everlight All Rights Reserved. Release Date : Dec.12.2016 Issue No: DIR-0000248 . Rev3
2
3
4
www.everlight.com
DATASHEET
3.0mm Infrared LED
IR264C
Typical Electro-Optical Characteristics Curves
Fig.5
Radiant Intensity vs.
Forward Current
Fig.6
Relative Radiant Intensity vs.
Angular Displacement
-20
Ie-Radiant Intensity(mW/sr)
1000
-10
0
10
20
30
100
10
1
10
0
10
1
2
10
10
3
10 4
1.0
40
0.9
50
0.8
0.7
60
70
80
0.6 0.4 0.2
0
0.2 0.4 0.6
IF-Forward Current (mA)
Fig.7
Radiant Intensity vs.
Ambient Temperature
Ie-Radiant Intensity (mW/sr)
Relative Forward Voltage vs.
Ambient Temperature
1.3
15
IF=20mA
10
1.2
5
1.1
0
1
25
5
Fig.8
50
75
100
120
IF=20mA
25
50
75
Copyright © 2010, Everlight All Rights Reserved. Release Date : Dec.12.2016 Issue No: DIR-0000248 . Rev3
100
120
www.everlight.com
DATASHEET
3.0mm Infrared LED
IR264C
Packing Quantity Specification
1. 200~1000PCS/1Bag,5Bag/1Box
2. 10Boxes/1Carton
Label Form Specification
CPN: Customer’s Production Number
P/N : Production Number
QTY: Packing Quantity
CAT: Ranks
HUE: Peak Wavelength
REF: Reference
LOT No: Lot Number
DISCLAIMER
1.
EVERLIGHT reserves the right(s) on the adjustment of product material mix for the specification.
2.
The product meets EVERLIGHT published specification for a period of twelve (12) months from date of
shipment.
3.
The graphs shown in this datasheet are representing typical data only and do not show guaranteed values.
4.
When using this product, please observe the absolute maximum ratings and the instructions for using outlined
in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from the use of
the product which does not comply with the absolute maximum ratings and the instructions included in these
specification sheets.
5.
These specification sheets include materials protected under copyright of EVERLIGHT. Reproduction in any
form is prohibited without obtaining EVERLIGHT’s prior consent.
6.
This product is not intended to be used for military, aircraft, automotive, medical, life sustaining or life saving
applications or any other application which can result in human injury or death. Please contact authorized
Everlight sales agent for special application request.
6
Copyright © 2010, Everlight All Rights Reserved. Release Date : Dec.12.2016 Issue No: DIR-0000248 . Rev3
www.everlight.com
