IR333-H0

Technical Data Sheet 5mm Infrared LED, T-1 3/4 IR333/H0 Features ․High reliability ․2.54mm lead spacing ․Low forward voltage ․Good spectral matching to Si photodetector ․High radiant intensity ․Pb free ․The product itself will remain within RoHS compliant version. Descriptions EVERLIGHT’s infrared emitting diode (IR333/H0) is a high intensity diode, molded in a blue transparent plastic package. The device is spectrally matched with phototransistor, photodiode and infrared receive module. Applications ․Free air transmission system ․Optoelectronic switch ․Floppy disk drive ․Infrared applied system ․Smoke detector Device Selection Guide LED Part No. IR Chip Material GaAlAs Lens Color Water clear Everlight Electronics Co., Ltd. Device No：DIR-033-005 http:\\www.everlight.com Prepared date：07-20-2005 Rev 3 Page: 1 of 7 Prepared by：David Huang IR333/H0 Package Dimensions Notes: 1.All dimensions are in millimeters 2.Tolerances unless dimensions ±0.25mm Absolute Maximum Ratings (Ta=25℃) Parameter Continuous Forward Current Peak Forward Current Reverse Voltage Operating Temperature Storage Temperature Soldering Temperature *2 Power Dissipation at(or below) 25℃Free Air Temperature *1 Symbol IF IFP VR Topr Tstg Tsol Pd Rating 100 1.0 5 -40 ~ +85 -40 ~ +85 260 150 Units mA A V ℃ ℃ ℃ mW Notes: *1:IFP Conditions--Pulse Width≦100μs and Duty≦1%. *2:Soldering time≦5 seconds. Everlight Electronics Co., Ltd. Device No：DIR-033-005 http:\\www.everlight.com Prepared date：07-20-2005 Rev 3 Page: 2 of 7 Prepared by：David Huang IR333/H0 Electro-Optical Characteristics (Ta=25℃) Parameter Symbol Condition IF=20mA IF=100mA Radiant Intensity Ee Pulse Width≦100μs and Duty≦1% Min. 5.6 ---------- Typ. Max. 7.8 35 350 940 45 1.2 1.4 2.6 -40 -----1.5 1.8 4.0 10 -- Units mW/sr IF=1A Pulse Width≦100μs and Duty≦1% Peak Wavelength Spectral Bandwidth λp Δλ IF=20mA IF=20mA IF=20mA IF=100mA nm nm Forward Voltage VF Pulse Width≦100μs and Duty≦1% V IF=1A Pulse Width≦100μs and Duty≦1% Reverse Current View Angle IR 2θ1/2 VR=5V IF=20mA μA deg Rank Condition：IF=20mA Unit：mW/sr Bin Number Min Max L 5.60 8.90 M 7.80 12.50 N 11.00 17.60 Everlight Electronics Co., Ltd. Device No：DIR-033-005 http:\\www.everlight.com Prepared date：07-20-2005 Rev 3 Page: 3 of 7 Prepared by：David Huang IR333/H0 Typical Electro-Optical Characteristics Curves Fig.1 Forward Current vs. Ambient Temperature 140 120 Fig.2 Spectral Distribution 100 80 IF=20mA Ta=25° C 100 80 60 40 20 0 60 40 20 0 -40 -20 0 20 40 60 80 100 Fig.3 Peak Emission Wavelength Ambient Temperature 980 Fig.4 Forward Current vs. Forward Voltage 4 10 960 3 10 940 2 10 920 900 -25 1 10 0 25 50 75 100 0 1 2 3 4 Everlight Electronics Co., Ltd. Device No：DIR-033-005 http:\\www.everlight.com Prepared date：07-20-2005 Rev 3 Page: 4 of 7 Prepared by：David Huang IR333/H0 Typical Electro-Optical Characteristics Curves Fig.5 Relative Intensity vs. Forward Current Fig.6 Relative Radiant Intensity vs. Angular Displacement 1000 Ie-Radiant Intensity(mW/sr) -20 -10 0 10 20 30 100 1.0 10 40 50 60 70 80 0.6 0.4 0.2 0 0.2 0.4 0.6 0.9 0.8 0.7 1 10 0 10 1 10 2 10 3 10 4 IF-Forward Current (mA) Fig.7 Relative Intensity vs. Ambient Temperature(°C) Fig.8 Forward Voltage vs. Ambient Temperature(°C) 15 IF=20mA 1.3 10 1.2 IF=20mA 5 1.1 0 25 50 75 100 120 1 25 50 75 100 120 Everlight Electronics Co., Ltd. Device No：DIR-033-005 http:\\www.everlight.com Prepared date：07-20-2005 Rev 3 Page: 5 of 7 Prepared by：David Huang IR333/H0 Reliability Test Item And Condition The reliability of products shall be satisfied with items listed below. Confidence level：90% LTPD：10% NO. Item Test Conditions Test Hours/ Cycles 10secs Sample Sizes 22pcs 22pcs IR≧U×2 Ee≦L×0.8 VF≧U×1.2 U：Upper 22pcs 22pcs 22pcs 22pcs Specification Limit L：Lower Specification Limit 0/1 0/1 0/1 0/1 Failure Judgement Criteria Ac/R e 0/1 0/1 1 Solder Heat TEMP.：260℃±5℃ 2 Temperature Cycle H : +100℃ L : -40℃ 3 Thermal Shock H :+100℃ L :-10℃ 4 High Temperature Storage 5 Low Temperature Storage 15mins 300Cycles 5mins 15mins 5mins 300Cycles 10secs 5mins 1000hrs 1000hrs 1000hrs 1000hrs 22pcs 0/1 TEMP.：+100℃ TEMP.：-40℃ 6 DC Operating Life IF=20mA 7 High Temperature/ 85℃ / 85% R.H High Humidity Everlight Electronics Co., Ltd. Device No：DIR-033-005 http:\\www.everlight.com Prepared date：07-20-2005 Rev 3 Page: 6 of 7 Prepared by：David Huang IR333/H0 Packing Quantity Specification 1.500PCS/1Bag，5Bags/1Box 2.10Boxes/1Carton Label Form Specification CPN: Customer’s Production Number P/N : Production Number QTY: Packing Quantity AT: Ranks HUE: Peak Wavelength REF: Reference LOT No: Lot Number MADE IN TAIWAN: Production Place RoHS IR333/H0 Notes 1. Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. 2. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. 3. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’s consent. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http:\\www.everlight.com Everlight Electronics Co., Ltd. Device No：DIR-033-005 http:\\www.everlight.com Prepared date：07-20-2005 Rev 3 Page: 7 of 7 Prepared by：David Huang
