EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Light Emitting Diode (5 mm Round LED,T-1 3/4) 7343-2UYC/H2/S400-AX Features ․Popular T-1 3/4 diameter package. ․Choice of various viewing angles. ․Reliable and robust. ․Pb free ․The product itself will remain within RoHS compliant version. Descriptions ․The series is specially designed for applications requiring higher brightness. ․The LED lamps are available with different colors,intensities,epoxy colors, etc. Applications ․TV set. ․Monitor. ․Telephone. ․Computer. Device Selection Guide Chip Material AlGaInP Emitted Color Super Yellow Water Clear Lens Color Everlight Electronics Co., Ltd. Device Number : DLE-734-089 http\\:www.everlight.com Prepared date: 09-02-2005 Rev :2 Page: 1 of 5 Prepared by: Grace Shen EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Light Emitting Diode (5 mm Round LED,T-1 3/4) 7343-2UYC/H2/S400-AX Package Dimensions Notes: ․All dimensions are in millimeters, tolerance is 0.25mm except being specified. ․Lead spacing is measured where the lead emerges from the package. ․Protruded resin under flange is 1.5mm Max LED. Absolute Maximum Ratings (Ta=25℃) Parameter Forward Current Pulse Forward Current*1 Operating Temperature Storage Temperature Electrostatic Discharge *2 Symbol IF IFP Topr Tstg ESD Tsol Pd VR Rating 50 200 -40 ~ +85 -40 ~ +100 2000 260 ±5 120 5 Units mA mA ℃ ℃ V ℃ mW V Soldering Temperature Power Dissipation Reverse Voltage Notes: *1:IFP Conditions--Pulse Width≦10msec and Duty≦1/10. *2:Soldering time≦5 seconds. Everlight Electronics Co., Ltd. Device Number : DLE-734-089 http\\:www.everlight.com Prepared date: 09-02-2005 Rev :2 Page: 2 of 5 Prepared by: Grace Shen EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Light Emitting Diode (5 mm Round LED,T-1 3/4) 7343-2UYC/H2/S400-AX Electro-Optical Characteristics (Ta=25℃) Parameter Forward Voltage Reverse Current Symbol Condition Chip Rank VF IR IF=20mA VR=5V --A6 A7 Luminous Intensity IV IF=20mA A8 A9 Viewing Angle Peak Wavelength Dominant Wavelength Spectrum Radiation Bandwidth 2θ1/2 λp λd Δλ IF=20mA IF=20mA IF=20mA IF=20mA ----1250 1600 ----2000 2500 30 591 589 15 ------deg nm nm nm Min. --800 1000 Typ. 2.0 -1250 1600 Max. 2.4 10 --mcd Units V μA *7343-2UYC/H2/S400-AX Chip Rank Everlight Electronics Co., Ltd. Device Number : DLE-734-089 http\\:www.everlight.com Prepared date: 09-02-2005 Rev :2 Page: 3 of 5 Prepared by: Grace Shen EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Light Emitting Diode (5 mm Round LED,T-1 3/4) 7343-2UYC/H2/S400-AX Typical Electro-Optical Characteristics Curves Everlight Electronics Co., Ltd. Device Number : DLE-734-089 http\\:www.everlight.com Prepared date: 09-02-2005 Rev :2 Page: 4 of 5 Prepared by: Grace Shen EVERLIGHT ELECTRONICS CO.,LTD. Technical Data Sheet Light Emitting Diode (5 mm Round LED,T-1 3/4) 7343-2UYC/H2/S400-AX Label Form Specification EVERLIGHT CPN: P/N: RoHS 7343UYC/H2/S400-AX QTY： LOT NO： CAT: HUE: REF: CPN: Customer’s Production Number P/N : Production Number QTY: Packing Quantity CAT: Ranks of Luminous and Forward Voltage HUE: Ranks of Dominant Wavelength REF: Reference LOT No: Lot Number MADE IN TAIWAN: Production Place MADE IN TAIWAN Notes 1. Above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. 2. When using this product, please observe the absolute maximum ratings and the instructions for using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification sheets. 3. These specification sheets include materials protected under copyright of EVERLIGHT corporation. Please don’t reproduce or cause anyone to reproduce them without EVERLIGHT’s consent. EVERLIGHT ELECTRONICS CO., LTD. Office: No 25, Lane 76, Sec 3, Chung Yang Rd, Tucheng, Taipei 236, Taiwan, R.O.C Tel: 886-2-2267-2000, 2267-9936 Fax: 886-2267-6244, 2267-6189, 2267-6306 http:\\www.everlight.com Everlight Electronics Co., Ltd. Device Number : DLE-734-089 http\\:www.everlight.com Prepared date: 09-02-2005 Rev :2 Page: 5 of 5 Prepared by: Grace Shen
