AN-1032

AN-1032 Advanced Power Products Application Note 1032 July, 1999 Performance Restrictions Associated with 3.5 Watts SO-8 Power MOSFETs Alan Li, Sr. Applications Engineer In applications requiring high current and small footprint electronic switches, a Power MOSFET packaged in an SO-8 is usually the best choice. This is because the combination offers low onresistance and reasonable power handling. A second benefit is the numerous suppliers for this product. As a result, SO-8 Power MOSFETs are commonly found in applications such as notebook computer DC-DC converters, battery chargers, and disk drive motor controls. SO-8 packaged Power MOSFETs handle about one Watt under “typical” conditions (Figure 1), regardless of the silicon size. The thermal capability of any semiconductor is strongly related to the operating conditions, however users often overlook the importance of such criteria. In addition, the lack of an industry standard means that MOSFET manufacturers may mislead the power handling of SO-8 Power MOSFETs by two to four times their typical thermal capability. Users should also remember that current handling is proportional to power handling. By simply manipulating the power rating conditions, MOSFET manufacturers can tailor any current rating to any “non-typical” condition. Of particular concern is a claim circulating that 3.5 Watt SO-8 Power MOSFETs exist in the industry. This is another twist in addition to the existing ill-defined 2.5 Watt power rating. If users carefully read the fine print of the disclaimer on the datasheets, it reveals that 3.5 Watt power handling can only be achieved “when mounted on a 1 inch square copper board; t < 10 sec.” Such conditions are not only unrealistic, but also pose a potential hazard for those who design parts with this information. As a result, it is not uncommon to see SO-8 Power MOSFETs being destroyed when they smoke during lab experiments. The disclaimers are technically correct but unrealistic for two reasons. First, one square inch of board space is somewhat equivalent to the size of a typical CPU, (Figure 2). Realistically, no one can afford such precious space for a MOSFET switch in any portable electronics. Secondly, SO-8 Power MOSFETs reach thermal equilibrium in a few minutes. That means a 10 second operation is far from the worst case condition. As a general rule, SO-8 Power MOSFETs handle about one Watt under “typical” conditions (Figure 1). In order to calculate power handling rather than rely on datasheet specifications, users should be familiar with the parameter RθJA. Since TJ - TA = PD * RθJA (Equation 1), power handling can be calculated assuming the maximum allowable temperature, ambient temperature, and RθJA at a given condition are known. To facilitate users in proper thermal design, Fairchild Semiconductor publishes different RθJA specifications at various conditions. Figure 1. Typical Condition RθJA = 125 oC/W ¡ PD = 1 W Figure 2. 1 in2 2oz Copper PAD RθJA (10sec) = 36 oC/W ¡ PD(10sec) = 3.5 W RθJA = 50 oC/W ¡ PD = 2.5 W Equation 1. TJ - TA = PD * RθJA where: TJ = Junction Temperature TA =Ambient Temperature PD =Power Dissipation Be Aware That Under “Typical” Conditions, SO-8 Power MOSFETs Only Handle About One Watt. © 1999 Fairchild Semiconductor Corporation 1 AN1032 Rev. A TRADEMARKS The following are registered and unregistered trademarks Fairchild Semiconductor owns or is authorized to use and is not intended to be an exhaustive list of all such trademarks. ACEx™ CoolFET™ CROSSVOLT™ E2CMOSTM FACT™ FACT Quiet Series™ FAST® FASTr™ GTO™ HiSeC™ DISCLAIMER ISOPLANAR™ MICROWIRE™ POP™ PowerTrench™ QS™ Quiet Series™ SuperSOT™-3 SuperSOT™-6 SuperSOT™-8 TinyLogic™ UHC™ VCX™ FAIRCHILD SEMICONDUCTOR RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN TO IMPROVE RELIABILITY, FUNCTION OR DESIGN. FAIRCHILD DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED HEREIN; NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS. LIFE SUPPORT POLICY FAIRCHILD’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF FAIRCHILD SEMICONDUCTOR CORPORATION. As used herein: 1. Life support devices or systems are devices or 2. A critical component is any component of a life support device or system whose failure to perform can systems which, (a) are intended for surgical implant into be reasonably expected to cause the failure of the life the body, or (b) support or sustain life, or (c) whose support device or system, or to affect its safety or failure to perform when properly used in accordance with instructions for use provided in the labeling, can be effectiveness. reasonably expected to result in significant injury to the user. PRODUCT STATUS DEFINITIONS Definition of Terms Datasheet Identification Advance Information Product Status Formative or In Design Definition This datasheet contains the design specifications for product development. Specifications may change in any manner without notice. This datasheet contains preliminary data, and supplementary data will be published at a later date. Fairchild Semiconductor reserves the right to make changes at any time without notice in order to improve design. This datasheet contains final specifications. Fairchild Semiconductor reserves the right to make changes at any time without notice in order to improve design. Preliminary First Production No Identification Needed Full Production Obsolete Not In Production This datasheet contains specifications on a product that has been discontinued by Fairchild semiconductor. The datasheet is printed for reference information only.
