AN-5015

AN-5015 USB1T11A Transceiver and Specification Compliance AN-5015 Fairchild Semiconductor Application Note December 1999 Revised December 2000 USB1T11A Transceiver and Specification Compliance Introduction The Universal Serial Bus (USB) specification has become widely accepted as the preferred mechanism for low to medium speed serial data interfaces. Older connections like RS232 and parallel printer LPTx ports can only be connected to one device at a time. USB allows multiple devices to be attached to a single port enabling greater system flexibility. The USB specification also allows for the connection, immediate operation, and removal of these devices with the system running. With widespread use comes the need to develop low cost, specification compatible, interface devices. An USB implementation example is shown in Figure 1. related to driving and receiving differential signals on the USB cable. 2. Isolates the digital controller from the cable. Guaranteed ESD tolerance on the transceiver ensures the expensive controller will not be damaged by adverse signals on the cable. 3. Removes analog style signals from the digital controller. This allows the design of the digital controller to be optimized for USB logic functionality. Keeping the controller completely digital reduces the design “risk” and added cost of a mixed analog and digital design. Transceiver Block Diagram and Pinout FIGURE 1. USB with Integrated Transceiver Benefits of Standalone Transceiver Removing the transceiver function from the Digital Controller and Serial Interface Engine (SIE) has three main benefits. FIGURE 3. Functional Diagram and Pinout Transceiver Features 1. Converts USB differential voltages to digital logic signal levels. 2. Converts the D+ and the D− line to single ended logic outputs for SE0 (single-ended 0) detection. 3. Converts logic levels to different USB signals. FIGURE 2. USB with Standalone Transceiver 1. Removes signal integrity concerns from the digital controller. The standalone USB Transceiver is responsible for meeting all compliance and signal quality issues • • • • Runs at low or high speed Selectable output slope control Meets the USB 1.1 drive template Has low power standby mode 4. Small footprint at low cost. © 2000 Fairchild Semiconductor Corporation AN500357 www.fairchildsemi.com AN-5015 Backwards Compatibility to USB 1.0 The USB Revision 1.0 and USB Revision 1.1 have many subtle differences. The differences however minor do serve to reduce the ambiguity of the 1.0 specification. The Fairchild USB1T11A has been designed to be compliant with USB 1.1 and backwards compliant to revision 1.0 of the USB standard. USB 1.1 SYSTEM LEVEL GOALS 1. Provide hooks to make system software work better with both 1.0 and 1.1 Hardware. 2. Remove non-relevant information from the specification. USB 1.1 ELECTRICAL GOALS 1. Better define electrical tests and testing methodologies. 2. Clarify connection events. 3. Specify realistic loads for Low Speed Operation. 3. Remove redundant information. 4. Provide better definition and use of common terms in the specification. 5. Enhance the capabilities of USB in Revision 1.1. Breaking the electrical goals down to specific input and output specifications shows the similarities between the two USB specifications. The common mode input voltage for the differential receiver has been reduced from 0.8V − 2.5V to 0.8V to 2.3V. In addition, a crossover voltage range has been established for the differential outputs to maximize the reliability to USB signal transmission (see Figure 4). In order to be backward compatible with USB 1.0, the Fairchild USB1T11A specifies a common mode input range of 0.8 to 2.5 volts. FIGURE 4. USB Common Mode Voltage for Differential Receiver www.fairchildsemi.com 2 AN-5015 Backwards Compatibility to USB 1.0 (Continued) The differential output impedance of the CMOS buffers has been updated to include the series termination resistance. The USB 1.0 specification required buffer impedance from 3 − 15Ω and a series resistance of 27Ω to produce equivalent output impedance ranging from 30Ω to 42Ω. The USB 1.1 specification only requires the combined output buffer impedance and series resistance to fall within a range from 28Ω to 44Ω. Devices compliant to version 1.1 of the specification will recommend the value of series resistance to meet this specification. The reverse is also true, devices compatible to 1.1 are backward compatible to revision 1.0 if they can produce equivalent output impedance which meets the tighter 1.0 specification. See the output impedance equation and Figure 5 for the Fairchild USB1T11A transceiver. 6−18Ω Specified Output Impedance: Recommended Series Resistance: 24Ω Lowest Equivalent Output Impedance = 6Ω + 24Ω = 30Ω Highest Equivalent Output Impedance = 18Ω + 24Ω = 42Ω FIGURE 5. Output Impedance Compliance to USB Specifications 3 www.fairchildsemi.com AN-5015 Transceiver Compliance to USB 1.1 The following table has been extracted from USB Compliance Checklist version 1.05. Only checklist items relevant to the design and implementation of the USB transceiver are addressed in this document. In order to guarantee physical layer compliance, all relevant specifications are 100% production tested on the Fairchild USB1T11A and guaranteed in the datasheet. TABLE 1. USB Compliance Specifications ID ST1 ST2 ST3 ST4 ST6 LS1 LS2 LS3 LS4 FS1 FS2 FS3 FS4 FS5 Question Is the data line crossover voltage between 1.3 and 2.0V? Do all single ended receivers recognize 0.8V or below as a logic low? Do all single ended receivers recognize 2.0V or more as a logic high? Datasheet Specification VCR: 1.3V − 2.0V VSE: 0.8V (Logic Low) VSE: 2.0V (Logic High) Do all differential receivers have an input sensitivity of at least 200 mV between 0.8 and 2.5 VDI: 200 mV (min) volts common mode? Is the input impedance of D+ and D−, without termination and pull up resistors, more than 300kΩ? Are data line rise times between 75 ns and 300 ns when driving into any single ended, capacitive load between 200 and 450 pF? Are data line fall times between 75 ns and 300 ns when driving into any single ended, capacitive load between 200 and 450 pF? Are the rise and fall times matched to within 20% for J ≥ K transitions? Are the rise and fall times matched to within 20% for K ≥ J transitions? With series termination resistors, does the device’s source impedance remain within the bounds of Figure 8 and Figure 9? IOZ: 10 µA (max) tLR: 75 ns − 300 ns tLF: 75 ns − 300 ns tREM: 80 − 120% (slow) tREM: 80 − 120% (slow) ZDRV: 6 − 18Ω Are data line rise times between 4.0 and 20 ns when driving into a single ended 50 pF load? tR: 4 ns − 20 ns Are data line fall times between 4.0 and 20 ns when driving into a single ended 50pF load? tF: 4 ns − 20 ns Are the rise and fall times matched to within 10% for J ≥ K transitions? Are the rise and fall times matched to within 10% for K ≥ J transitions? tRFM: 90 − 110% (full) tRFM: 90 − 110% (full) For a complete listing of the Fairchild USB1T11A features and specifications please follow the link to the datasheet below: http://www.fairchildsemi.com/pf/US/USB1T11A.html#Datasheet Transceiver Compliance in Suspend Mode When directed by the digital controller, the USB1T11A transceiver will enter a suspend mode. In order to minimize device power consumption during suspend, the differential receiver must be shut down. In order to detect an end to USB suspend, the digital controller must monitor the state of VP and VM which remain active during the suspend state. www.fairchildsemi.com 4 AN-5015 Transceiver Performance Actual performance of the Fairchild USB Transceiver is outlined in the following graphs and waveforms. Note: 24Ω series output resistor FIGURE 9. Source Impedance Low State Note: In low speed testing, the downstream port included an additional 50 pf of load capacitance. Total CLOAD = 200 pF. Transceiver Comparison Actual performance and nearly identical product specifications should ease second source design considerations. However, the Fairchild USB1T11A has several advantages over similar USB transceivers. 1. Faster typical propagation delays 2. Slower edge rates 3. Lower conducted EMI 4. Enhanced ESD protection The faster propagation delays allow additional time for the digital controller to process incoming and outgoing data before it is delivered to the USB transceiver. FIGURE 6. 1.5Mb/sec 10’ Cable Driving Information Note: Due to transmission line or cable effects, the Rise and Fall time in High Speed mode is measured between 0.8 and 2.5V. FIGURE 7. 12Mb/sec 10’ Cable Driving Information FIGURE 10. Transceiver tPD Comparison Controlled output edge rates reduce the overall transmission line effects and minimize signal degradation on the cable. This results in improved signal characteristics at the differential receiver. Note: Includes 24Ω series output resistor. FIGURE 8. Source Impedance High State 5 www.fairchildsemi.com AN-5015 USB1T11A Transceiver and Specification Compliance Transceiver Comparison (Continued) ELECTROSTATIC DISCHARGE Electrostatic Discharge or ESD tolerance is especially important for USB transceivers. This type of device is connected directly to system I/O ports. Residing at the user interface often results in the need to absorb a transient ESD event as a USB function is attached or removed from the host system or USB hub. TABLE 2. Transceiver ESD Performance: Fairchild USB1T11A Philips PDIUSBP11A Mircrel MIC2550 4KV Minimum 2KV Minimum Not Specified The Fairchild USB Transceiver has already integrated effective ESD protection into the product. Therefore no external ESD protection is required for a robust USB interface implementation. FIGURE 11. Controlled Output Edge Rate EMI reduction at the system level is a major design challenge. USB components should work in harmony with the system to achieve the lowest possible level of EMI radiation ensuring that the entire system meets all FCC regulations. Although low device generated EMI can never guarantee low system EMI, using devices generating less EMI provides a solid foundation on which to build a system capable of passing FCC regulations. Conclusion The Fairchild USB1T11A transceiver provides a low cost, low risk, and backward compatible solution to the analog signaling requirements of an USB 1.1 design. Note: EMI measurements are taken at transceiver output driving 3m USB cable for a load. The fundamental frequency of the output is 1.0 MHz. FIGURE 12. Conducted EMI Fairchild does not assume any responsibility for use of any circuitry described, no circuit patent licenses are implied and Fairchild reserves the right at any time without notice to change said circuitry and specifications. LIFE SUPPORT POLICY FAIRCHILD’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT OF FAIRCHILD SEMICONDUCTOR CORPORATION. As used herein: 1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into the body, or (b) support or sustain life, and (c) whose failure to perform when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in a significant injury to the user. www.fairchildsemi.com 6 2. A critical component in any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness. www.fairchildsemi.com
