CONVERTER CARD PO-001
SERIAL DIGITAL TO 10 BIT VIDEO
The PO-001 converter card is a stand alone solution for single channel serial digital video to 10 bit parallel video conversion Using the Gennum chipset the module provides EDH insertion for SMPTE 259M compliant signals. The module can successfully receive a serial digital signal from up to 300m of cable. The PO-001 compliments the PI-001 10 bit parallel to SDI transmitter.
INPUT I/P impedance I/P return loss
SDI up to 540Mb/s 75 ohm 15dB min
OUTPUTS Output signal
CCIR Rec. 656 10 bit parallel video
SUPPLY Power: Current:
5V 300mA max
EDH OPTION Indications:
Controls:
EDH - Error detected Here EDA - Error detected already UES - Unknown Error status TRS - Insert: Bypass Mode:
(Note 1) (Note 1) (Note 1) (Note 2) (Note 2)
Note 1. These are accessible only through the serial interface SCL and SDA. Note 2. These are available only through the I/O interface see connector for details. CONNECTORS Input Output INDICATORS
75 ohm BNC socket 48 PIN Z-PAC 4 row x 12 on 2mm pitch Carrier Detected (Green) LED
© Faraday Technology. As part of continual product improvement the specifications, details and dimensions shown in this publication are subject to change without notice
Fara229p
Page 1 of 3
Aug-05(B)
Connector Pinout
1 +5V 13 +5V 25 NC 37 IO8 2 CLK 14 +5V 26 NC 38 IO9 3 D0 15 A0 27 NC 39 IO10 4 D1 16 A1 28 NC 40 IO11 5 D2 17 SDA 29 NC 41 IO12 6 D3 18 SCL 30 NC 42 NC 7 D4 19 RESET 31 NC 43 NC 8 D5 20 TRS INSERT 32 NC 44 NC 9 D6 21 BYPASS EDH 33 NC 45 NC 10 D7 22 GND 34 NC 46 ID0 11 D8 23 GND 35 NC 47 ID1 12 D9 24 GND 36 ID3 48 ID2
RESET BYPASS EDH TRS INSERT D0 to D9 CLK A0,A1 SCL,SDA ID0,ID1,ID2,ID3 IO8-IO12
When taken low resets the internal circuitry of the serial digital input processor. Internally pulled high: When high EDH packet is passed through unaltered. Internally pulled high: Pull low to disable TRS Blanking, ITU-601Clipping & TRS Insertion. Parallel Data Bus D0 LSB , D9 MSB Parallel Data clock Address lines to modify I2 c bus address. I2 c data and clock lines Card type identification code. Do not connect.
Card Type Identification code.
CARD TYPE PO-001 ID3 +5V ID2 +5V ID1 +5V ID0 +5V
Ordering code: PO-001A
Note: This item is NOT aqueous washable.
© Faraday Technology. As part of continual product improvement the specifications, details and dimensions shown in this publication are subject to change without notice
Fara229p
Page 2 of 3
Aug-05(B)
PACKAGE DETAIL
Faraday Technology Ltd. Croft Road Industrial Estate, Newcastle, Staffordshire ST5 0QZ. England. Fara229p
Tel: Fax: Email: Web site: Page 3 of 3
+ 44 (0)1782 661501 + 44 (0)1782 630101 sales@faradaytech.co.uk http://www.faradaytech.co.uk Aug-05(B)
