CP-P16-1S

Ferroxcube P cores and accessories COIL FORMERS General data for CP-P26/16 coil former PARAMETER Coil former material Maximum operating temperature SPECIFICATION P26/16 polybutyleneterephtalate (PBT), glass reinforced, flame retardant in accordance with “UL 94V-0” ; UL file number E45329 (R) 155 C, “IEC 60 085”, class F handbook, full pagewidth 0 10.8 0.15 0.5 0.4 2.7 12.8 0 0 20.9 0.15 0.2 0.15 11.7 0 0.6 0.5 MBE211 Dimensions in mm. Fig.3 Coil former CP-P26/16. Winding data for CP-P26/16 coil former NUMBER OF SECTIONS 1 2 3 2 3 WINDING AREA (mm2) 37.1 17.5 11 2 3 MINIMUM WINDING WIDTH (mm) 9.3 4.35 2.7 AVERAGE LENGTH OF TURN (mm) 52.6 52.6 52.6 TYPE NUMBER CP-P26/16-1S CP-P26/16-2S CP-P26/16-3S
