Ferroxcube
P cores and accessories
COIL FORMERS General data for CP-P14/8 coil former PARAMETER Coil former material Maximum operating temperature SPECIFICATION
P14/8
polybutyleneterephtalate (PBT), glass reinforced, flame retardant in accordance with “UL 94V-0” ; UL file number E45329 (R) 155 C, “IEC 60 085”, class F
handbook, full pagewidth
0 5.4 0.2 0.4 0.3
2.2
0 0 7.1 0.15 11.5 0.2
0.2 6.1 0
0.5
0.4
CBW601
Dimensions in mm.
Fig.3 Coil former CP-P14/8. Winding data for CP-P14/8 coil former NUMBER OF SECTIONS 1 2 2 WINDING AREA (mm2) 8.8 4.0 2 MINIMUM WINDING WIDTH (mm) 4.1 1.85 AVERAGE LENGTH OF TURN (mm) 28.9 28.9 TYPE NUMBER CP-P14/8-1S CP-P14/8-2S
