CP-P8-3S-A

Ferroxcube P cores and accessories General data for CP-P14/8-A coil former PARAMETER Coil former material Maximum operating temperature SPECIFICATION P14/8 acetal (POM), glass reinforced, flame retardant in accordance with “UL 94-HB” ; UL file number E66288(R) 105 C, “IEC 60 085”, class F handbook, halfpage 6.1 min 1.9 min 5.5 max 7.1 11.55 max MGB529 Dimensions in mm. Fig.4 Coil former CP-P14/8-A. Winding data for CP-P14/8-A coil former NUMBER OF SECTIONS 1 2 3 MINIMUM WINDING AREA (mm2) 9.4 8.65 6.6 NOMINAL WINDING WIDTH (mm) 4.5 4.0 3.6 AVERAGE LENGTH OF TURN (mm) 29.0 29.0 29.3 TYPE NUMBER CP-P14/8-1S-A CP-P14/8-2S-A CP-P14/8-3S-A
