04/02
Sketch with main dimensions Boxes with pins 0,4 x 0,6 mm, preferably for ISDN interface transducers. Available fully fitted only. Standard material: PPS - GV (Polyphenylensulfide UL94-V0). Special material on request. Pattern for X 1: Box for toroids for SMD mounting
237
b1 +0,2
b2 +0,2
b3 +0,3
h1 +0,2
h2 +0,2
h3 +0,2
l1 +0,2
l2 +0,2
X1 +0,2
1 X3 *
Type
Art. No.
8,8
11,5
14,4
5,5
6,6
7,6
8,7
9,9
3x2,54
2x4
VR-SMD 9/9-8
Wz 7767
3490
11,5
13,9
16,6
7,5
8
10
12
13,1
2x2,54 1x5,08 4x2,54
2x4
VR-SMD 11/12-8
Wz 7658
3369
11,5
13,9
16,6
7,5
8
10
12
13,1
2x5
VR-SMD 11/12-10
Wz 7664
3373
Sketch with main dimensions
Boxes with pins 0,4 x 0,6 mm, preferably for ISDN interface transducers. Available fully fitted only. Standard material: PPS - GV (Polyphenylensulfide UL94-V0). Special material on request.
Box for toroids for SMD mounting
b1 +0,2
b2 +0,2
b3 +0,3
h1 +0,2
h2 +0,2
h3 +0,2
l1 +0,2
l2 +0,2
X1 +0,2
1 X3 *
Type
Art. No.
12,4
15,2
18,3
7,6
8,1
10
28
29
8x2,54
2x9
VR-SMD 12/28-18
Wz 7612
3299
* 1
X3 = max. number of slots or terminals
