4703-12

Power Transformers Low Profile 4701 - 4705 LOW PROFILE Transformer for printed circuit mounting. · Five sizes: 2, 6, 12, 24 and 48 VA ratings. · Split bobbins for increased dielectric strength and low capacitive coupling. · 115/230 volts, 47/63 Hz primary windings. · CSA listed (LR 47366) and U.L. recognized (E100878). MECHANICAL Dimensions, Inches Size 4701 4702 4703 4704 4705 A 1.56 1.56 2.00 2.25 2.50 B 1.88 1.88 2.50 2.87 3.12 C 0.65 0.85 1.07 1.25 1.38 D 0.375 0.375 0.50 0.60 0.60 E 1.60 1.60 2.00 1.90 2.18 0.028 0.028 0.028 0.040 0.040 S X 0.041 X 0.041 X 0.041 X 0.040 X 0.040 ELECTRICAL SPECIFICATION Part No. 4701-05 4701-06 TLP4701-08 4701-10 4701-12 4701-15 4701-17 4701-28 4702-05 4702-06 4702-08 4702-10 4702-12 4702-15 4702-17 4702-28 4703-05 4703-06 4703-08 4703-10 4703-12 4703-15 4703-17 4703-28 VA 2 2 2 2 2 2 2 2 6 6 6 6 6 6 6 6 12 12 12 12 12 12 12 12 Parallel Volts Amps 5 6.3 8 10 12 15 17 28 5 6.3 8 10 12 15 17 28 5 6.3 8 10 12 15 17 28 0.50 0.40 0.30 0.25 0.20 0.17 0.15 0.09 1.20 0.90 0.70 0.60 0.50 0.40 0.34 0.20 2.40 1.80 1.40 1.20 1.00 0.80 0.68 0.40 Series Volts Amps 10 12.6 16 20 24 30 34 56 10 12.6 16 20 24 30 34 56 10 12.6 16 20 24 30 34 56 0.25 0.20 0.15 0.13 0.10 0.09 0.08 0.05 0.60 0.45 0.35 0.30 0.25 0.20 0.17 0.10 1.20 0.90 0.70 0.60 0.50 0.40 0.34 0.20 Part No. 4704-05 4704-06 4704-08 4704-10 4704-12 4704-15 4704-17 4704-28 4705-05 4705-06 4705-08 4705-10 4705-12 4705-15 4705-17 4705-28 VA 24 24 24 24 24 24 24 24 48 48 48 48 48 48 48 48 Parallel Volts Amps 5 6.3 8 10 12 15 17 28 5 6.3 8 10 12 15 17 28 4.80 3.80 3.00 2.40 2.00 1.60 1.40 0.85 9.60 7.60 6.00 4.80 4.00 3.20 2.80 1.70 Series Volts Amps 10 12.6 16 20 24 30 34 56 10 12.6 16 20 24 30 34 56 2.40 1.90 1.50 1.20 1.00 0.80 0.70 0.43 4.80 3.80 3.00 2.40 2.00 1.60 1.40 0.83 ISSUE: C FLATCSA 95/06/29 An ISO 9001 Registered Company 229 Colonnade Road, Nepean, Ontario, Canada K2E 7K3 Tel: (613) 226-1626 Fax: (613) 226-7124 www.filtran.com
