4723-18

Power Transformers International 4721 - 4726 HORIZONTAL SERIES Power Transformers for printed circuit mounting. • Six sizes: 1.1VA, 2.4VA, 6VA, 12VA, 20VA & 36VA ratings. • Split bobbins for increased dielectric strength. • 115/230 volts, 47/63 Hz primary windings. • CSA listed (LR 47366) and U.L. recognized (E100878). MECHANICAL Dimensions, Inches DOT AT PIN #1 P/N 4721 4722 4723 4724 4725 4726 DIMENSIONS L W 1.375 1.125 1.375 1.125 1.625 1.313 1.875 1.563 2.250 1.875 2.625 2.188 H 0.94 1.18 1.30 1.42 1.42 1.57 PIN SPACINGS A B C 0.25 0.25 1.20 0.25 0.25 1.20 0.25 0.35 1.28 0.30 0.40 1.41 0.30 0.40 1.60 0.40 0.40 1.85 ELECTRICAL SPECIFICATION Part No. 4721-05 4721-06 4721-08 4721-10 4721-12 4721-14 4721-18 4721-24 4722-05 4722-06 4722-08 4722-10 4722-12 4722-14 4722-18 4722-24 4723-05 4723-06 4723-08 4723-10 4723-12 4723-14 4723-18 4723-24 VA 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 6 6 6 6 6 6 6 6 Parallel Volts Amps 5 6.3 8 10 12 14 18 24 5 6.3 8 10 12 14 18 24 5 6.3 8 10 12 14 18 24 0.22 0.18 0.14 0.11 0.09 0.08 0.06 0.0046 0.50 0.40 0.30 0.24 0.20 0.17 0.13 0.10 1.20 1.00 0.80 0.60 0.50 0.40 0.34 0.25 Series Volts Amps 10 12.6 16 20 24 28 36 48 10 12.6 16 20 24 28 36 48 10 12.6 16 20 24 28 36 48 0.11 0.09 0.07 0.055 0.045 0.04 0.03 0.023 0.25 0.20 0.15 0.12 0.10 0.085 0.065 0.050 0.60 0.50 0.40 0.30 0.25 0.20 0.17 0.125 Part No. 4724-05 4724-06 4724-08 4724-10 4724-12 4724-14 4724-18 4724-24 4725-05 4725-06 4725-08 4725-10 4725-12 4725-14 4725-18 4725-24 4726-05 4726-06 4726-08 4726-10 4726-12 4726-14 4726-18 4726-24 VA 12 12 12 12 12 12 12 12 20 20 20 20 20 20 20 20 36 36 36 36 36 36 36 36 Parallel Volts Amps 5 6.3 8 10 12 14 18 24 5 6.3 8 10 12 14 18 24 5 6.3 8 10 12 14 18 24 2.40 2.00 1.60 1.20 1.00 0.84 0.70 0.50 4.00 3.20 2.50 2.00 1.60 1.40 1.10 0.80 7.20 5.70 4.50 3.60 3.00 2.60 2.00 1.50 Series Volts Amps 10 12.6 16 20 24 28 36 48 10 12.6 16 20 24 28 36 48 10 12.6 16 20 24 28 36 48 1.20 1.00 0.80 0.60 0.50 0.42 0.35 0.25 2.00 1.60 1.25 1.00 0.80 0.70 0.55 0.40 3.60 2.85 2.25 1.80 1.50 1.30 1.00 0.75 REV: D 4721.CHP 95/07/04 An ISO 9001 Registered Company 229 Colonnade Road, Nepean, Ontario, Canada K2E 7K3 Tel: (613) 226-1626 Fax: (613) 226-7124 www.filtran.com
