OC-192

PRODUCT BRIEF OC-192 MODULES Return to Zero (RZ) and Duo-Binary Extended Reach FEATURES  Full C and L Band Tunable  10Gb/s Serial Optical Interface  1550nm CW Laser with Lithium Niobate Modulator  Standard NRZ APD and Receive Side Circuitry 300 PIN MSA Compliant Footprint (3.5" x 4.5")  SONET OC-192/SDH STM-64 OVERVIEW Finisar is an industry leader in alternate modulation formats at 10Gb/s. Product offerings include Return to Zero (RZ) and Duo-Binary, along with our standard NRZ products. All of the products share a common mechanical footprint and electrical interface, making them fully interchangeable on the line card. The RZ modules are designed for long haul links that require exceptional OSNR performance. The RZ design leverages over 90% of the NRZ product family to provide a high reliability, low cost RZ solution. Duo-Binary modulation allows users to achieve 160km transmission performance in the same form factor as 80km NRZ products. This solution is not only cost competitive, but also eliminates the need for bulky dispersion compensating fiber. Both products are offered in the standard 3.5” x 4.5” x 0.53” MSA footprint. Using the same components on the electrical interface simplifies qualification of multiple modulation formats by providing a consistent board level interface. The RZ and Duo-Binary products are currently shipping in volume manufacturing.. DUO-BINARY BENEFITS  Overlay of 10Gb/s over Existing 2.5Gb/s Links  160km Links with Reduced Form Factor RZ BENEFITS  Improved OSNR Performance for Ultra Long Haul Systems RZ and Duo-Binary OC-192 Modules OPTICAL PERFORMANCE SPECIFICATIONS: RETURN TO ZERO (RZ) Parameter Dispersion Tolerance Operating Data Rate Sensitivity (Back to Back) RX Optical Power Range OSNR Back to Back BER = 1E-4 BER = 1E-7 BER = 1e-10 Fiber (+/- 500psec/nm) BER = 1E-4 BER = 1E-7 BER = 1e-10 Dispersion Path Penalty Output Power 1.0 15 18 20 2.0 5.0 dB/0.1nm dB/0.1nm dB/0.1nm dB dBm 13 16 18 dB/0.1nm dB/0.1nm dB/0.1nm -8.0 Min -500 9.953 Max 500 11.125 -24 -22.0 Units psec/nm Gb/s dBm dBm dB/0.1nm OPTICAL PERFORMANCE SPECIFICATIONS: DUO-BINARY Module Transmitter Parameter TX Spectral Range: C-Band TX Spectral Range: L-Band Channel Spacing Output Power Receiver RX Spectral Range Overload Receiver Sensitivity @ 0 ps/nm Receiver Sensitivity @ +/- 1500 ps/nm Receiver Sensitivity @ +/- 3200 ps/nm Data Rate BOL BER with OSNR 10.709 15 18.5 24 13.5 16.5 22 15 18.5 24 16 19.5 25 11.1 16 19.5 25 14.5 17.5 23 16 19.5 25 17 20.5 26 10-3 10-5 10-10 10-3 10-5 10-10 10-3 10-5 10-10 10-3 10 -5 Min 1528 1570 Typ Max 1561 1607 Units nm nm GHz dBm nm dBm dBm dBm dBm Notes 50 4 1290 -6 -4 -22 -23 -21 7 1610 0ps/nm -8 to -22 dBm +/-1500ps/nm -8 to -22dBm +/-3000ps/nm -8 to 22dBm +/-3200ps/nm -8 to -22dBm 10-10 1389 Moffett Park Drive Sunnyvale, CA 94089 Phone (US Toll Free): 888.746.6484 Phone Intl: 408.400.1000 Email: sales@finisar.com www.finisar.com ©2008 Finisar Corporation. All rights reserved. Finisar is a registered trademark of Finisar Corporation. Features and specifications are subject to change without notice. 08/08 12RZAAU4MALCB RevB 12DBAAU4MALCB
